| Projection System |
3LCD, 3-chip technology |
| Projection Method |
Front/rear wall mount |
| Driving Method |
Poly-silicon TFT Active Matrix |
| Pixel Number |
786,432 dots (1024 x 768) x 3 |
| Color Light Output |
3000 lumens |
| White Light Output |
3000 lumens (ISO 21118 standard) |
| Aspect Ratio |
4:3 |
| Native Resolution |
1024 x 768 (XGA) |
| Resize |
640 x 480 (VGA), 800 x 600 (SVGA), 1152 x 864 (SXGA), 1280 x 800 (WXGA), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3), 1280 x 768 (WXGA 60-1/470 and 480 only), 1360 x 768 (WXGA 60-2), 1440 x 900 (WXGA+), 1400 x 1050 (SXGA+), 1600 x 900 (WXGA++) |
| Lamp Type |
E-TORL 215 W UHE |
| Lamp Life |
Up to 4000 hours (ECO Mode)
Up to 3000 hours (Normal Mode) |
| Throw Ratio Range |
0.31 - 0.42 |
| Size (projected distance) |
55.9" to 93.2" (0.348 to 0.597 m) |
| Keystone Correction Manual |
Vertical ± 5 degrees
Horizontal ± 5 degrees |
| Mac Connectivity |
Projector is Mac compatible via USB, DVI to HDMI or VGA adapter (not included), DP to HDMI or VGA |
| Contrast Ratio |
Up to 3000:1 |
| Color Reproduction |
16.77 million colors |
| Lens Type |
No optical zoom/Manual focus |
| F-number |
1.80 |
| Focal Length |
3.71 mm |
| Zoom Ratio |
Digital zoom 1.0 - 1.35 |
| Display Performance |
NTSC: 560 lines
PAL: 560 lines (Depends on observation of the multi-burst pattern) |
| Input Signal |
NTSC/NTSC4.43/PAL/M-PAL/N-PAL/PAL60/SECAM |
| Interfaces |
HDMI x 1
Computer / Component video: D-sub HD 15 pin x 2
S-video: Mini DIN x 1
Composite video: RCA (Yellow) x 1
Audio in: RCA x 1 (L and R), Mini stereo x 2
USB connector: Type B x 1 (USB display, audio and mouse control)
USB connector: Type A x 1 (USB memory / document camera)
RJ-45 x 1
Serial: RS-232c x 1
Monitor Out: D-sub 15 pin x 1
Audio out: Mini stereo x 1
Microphone: Mini stereo x 1
Wireless LAN port: 802.11 b/g/n |
| Speaker |
16 W (mono) |
| Operating Temperature |
41 Deg. to 95 Deg.F (5 Deg. to 35 Deg.C) |
| Power Supply Voltage |
100 - 240 V ± 10%, 50/60 Hz |
| Power Consumption |
313 W (Normal Mode)
223 W (ECO Mode)
7.5 W Standby (Communication On)
0.2 W Standby (Communication Off)) |
| Fan Noise |
35 dB (Normal Mode)
28 dB (ECO Mode) |
| Security |
Kensington-style lock provision, padlock and security cable hole, password protect function |
| Operating Distance |
Front/rear: 19.7' (6 m) |
| Dimensions (W x D x H) |
Including feet: 14.4" x 14.7" x 7.1" (36.5 x 37.3 x 18.03 cm)
Excluding feet: 14.4" x 14.7" x 5.6" (36.5 x 37.3 x 14.2 cm) |
| Weight |
11.5 lbs / 5.21 kg |
