| Projection System |
Epson 3LCD technology |
| Projection Method |
Front/rear/ceiling mount |
| Lcd |
Three 0.7" wide, poly-silicon TFT active matrix |
| Resolution |
Native 720p (1280 x 720) |
| Aspect Ratio |
Native 16:9 (4:3 resize) |
| Contrast Ratio |
Up to 10,000:1 (in Dynamic Mode) |
| Lumens |
Up to 1600 lumens (in Dynamic Mode) |
| Video Processing |
Built-in Y/C separation and I/P conversion Powered by Pixelworks |
| Zoom |
Manual zoom Manual focus |
| Projection Lens |
F-number: 2.0 - 3.17 |
| Zoom Ratio |
1 - 2.1 |
| Screen Size (Projected Distance) |
100" (wide: 10.5' - tele: 22') |
| Lens Shift Range |
Vertical +/-100% Horizontal +/- 50% |
| Lamp Type |
170 W UHE lamp |
| Lamp Life |
Up to 3000 H (Lamp life results will vary depending upon mode selected, environmental conditions and usage) |
| Video Compatibility |
HDMI HDTV Component video S-video Composite video NTSC/PAL/SECAM Analog RGB D4/SCART |
| Video Input Signal |
NTSC NTSC4.43 PAL M-PAL N-PAL PAL60 SECAM 480i 480p 720p 1080i |
| Terminal Inputs |
HDMI 3 RCA (component) 1 RCA (composite) 1 Mini Din (S-video) 1 Mini D-Sub 9 pin (RS-232c) 1 Mini D-Sub 15 pin (analog RGB) 1 trigger out port |
| Image Size |
30 to 300 inches |
| Projection distance |
3.0 to 66.8 feet (0.93 to 20.35 m) at 16:9 3.7 to 81.7 feet (1.13 to 24.90 m) at 4:3 |
| Noise level |
26 to 33dB |
| Keystone correction |
Vertical: -15 o 415deg. |
| Lamp Type |
USE (Ultra High Efficiency). E-TORL |
| Power consumption |
170 W |
| Lamp life |
1700 to 3000 hours, depending on usage |
| Remote Control Range |
Approximately 30 feet (10 m) |
| Batteries |
AA x 2 |
| Temperature |
Operating: 41 to 95 deg.F (5 to 35 deg.C) Storage: 14 to 140deg.F (-10 to 60deg.C) |
| Humidity |
Operating: 20 to 80% RH, non-condensing Storage: 10 to 90% RH, non-condensing |
| Operating altitude |
0 to 7500 feet (0 to 2280 meters) |
| Power consumption |
Operating: 245W (100 to 120V), 240W (200 to 240V) Standby: 4W (100 to 120V), SW (200 to 240 V) |
| Power supply |
100 120 VAC,2.7A 200 to 240 VAC, 1.2 A |
| Rated frequency |
50/60 Hz AC |
| Dimensions |
4.9 x 16 x 12.2 " (124 x 406 x 309 mm) (not including adjustable feet & lens protrusion) |
| Weight |
11.9 lb (5.39 kg) |
