| Projection System |
Epson 3LCD, 3-chip optical engine |
| Projection Method |
Front / rear / ceiling mount |
| Driving Method |
Epson Poly-silicon TFT Active Matrix |
| Pixel Number |
480,000 dots (800 x 600) x 3 |
| White Light Output |
2500 lumens (ISO 21118 Standard) |
| Color Light Output |
2500 lumens |
| Aspect Ratio |
4:3 |
| Native Resolution |
800 x 600 (SVGA) |
| Resize |
640 x 480 (VGA), 1024 x 768 (XGA), 1152 x 864 (SXGA1), 1280 x 800 (WXGA), 1440 x 900 (WSXGA), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3), 1280 x 768 (WXGA60-1), 1360 x 768 (WXGA60-2), 1400 x 1050 (SXGA+) |
| Lamp Type |
E-TORL 200 W UHE |
| Lamp Life |
ECO mode: Up to 5000 hours
Normal mode: Up to 4000 hours |
| Throw Ratio Range |
1.45 - 1.96 (4:3) |
| Size (projected distance) |
30" - 350" (2.9' - 34.4') |
| Keystone Correction |
Manual: Vertical: ±30 degrees |
| USB Plug 'n Play |
Projector is compatible with PC and Mac computers |
| Contrast Ratio |
Up to 2000:1 |
| Color Reproduction |
16.77 million colors |
| Projection Lens Type |
Manual focus |
| F-number |
1.44 |
| Focal Length |
16.6 mm |
| Zoom Ratio |
Digital zoom 1.0 - 1.35 |
| Display Performance |
NTSC: 480 lines
PAL: 560 lines
(Depends on observation of the multi-burst pattern) |
| Input Signal |
NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM / SDTV / HDTV |
| Interfaces |
Computer / Component video: D-sub 15 pin x 1
S-video: Mini DIN x 1
Composite video: RCA (Yellow) x 1
Audio in: Stereo Mini x 1
USB connector: Type B x 1
Monitor out: D-sub 15 pin x 1
Audio out: Stereo Mini x 1 |
| Speaker |
1 W monaural |
| Operating Temperature |
41deg. to 95deg. F (5deg. to 35deg. C) |
| Power Supply Voltage |
100 - 240 V ±10%, 50 / 60 Hz |
| Power Consumption |
Normal mode: 280 W
Communication on: 2.6 W Standby
Communication off: 0.3 W Standby |
| Fan Noise |
ECO mode: 29 dB
Normal mode: 37 dB |
| Security |
Kensington-style lock provision
Padlock
Security anchor bar |
| Remote Control Operating Angle |
Right / Left: ±30 degrees
Upper / Lower: ±15 degrees |
| Remote Control Operating Distance |
19' (6 m) |
| Dimensions (W x D x H) |
Including feet: 11.6 x 9.0 x 3.1"/29.46 x 22.86 x 7.87 cm
Excluding feet: 11.6 x 9.0 x 3.0"/29.46 x 22.86 x 7.62 cm |
| Weight |
5.1 lb (2.31 kg) |
