| Printing Technology |
Advanced MicroPiezo TFP print head with ink repelling coating technology |
| Print Head |
8-channel, drop-on-demand, ink jet print head |
| Minimum Ink Droplet Size |
3.5 picoliters |
| Ink Type |
Epson UltraChrome K3 pigment-based ink |
| Ink Palette |
C, Lc, VM, VLm, Y, Lk, LLk + PK or MK |
| Ink Cartridge Configuration |
9 x individual ink cartridges |
| Compatible Ink Cartridges 1 |
Replacement Cartridges:
Photo Black: (T642100 - 150 ml), (T596100 - 350 ml), (T636100 - 700 ml)
Cyan: (T642200 - 150 ml), (T596200 - 350 ml), (T636200 - 700 ml)
Vivid Magenta: (T642300 - 150 ml), (T596300 - 350 ml), (T636300 - 700 ml)
Yellow: (T642400 - 150 ml), (T596400 - 350 ml), (T636400 - 700ml) |
| Compatible Ink Cartridges 2 |
Replacement Cartridges:
Light Cyan: (T642500 - 150 ml), (T596500 - 350 ml), (T636500 - 700 ml)
Vivid Light Magenta: (T642600 - 150 ml), (T596600 - 350 ml), (T636600 - 700 ml)
Light Black: (T642700 - 150 ml), (T596700 - 350 ml), (T636700 - 700 ml)
Matte Black: (T642800 - 150 ml), (T596800 - 350 ml), (T636800 - 700 ml)
Light Black: (T642900 - 150 ml), (T596900 - 350 ml), (T636900 - 700 ml) |
| Shelf Life |
Ink: 2 years from production date or 6 months after opening |
| Number of Nozzles |
8 x 360 nozzles - color and monochrome |
| Print Speed |
16.0" x 20.0" (406 x 508mm): from 1:53 to 7:14 / Normal is 3:47 20.0" x 30.0" (508 x 762mm): from 4:03 to 12:52 / Normal is 6:39 |
| Print Archival Life |
Color Up to 200 years, Black-and-White Over 200 years |
| Maximum Paper Width |
24.0" (610mm) |
| Maximum Printable Width |
24.2" (614mm) |
| Margins |
Left/Right: 0 to 3mm each (0.24", 610mm total) |
| Maximum Roll Print Length |
Limited by application, OS and driver/RIP used |
| Core Size |
User-adjustable roll media adapters (included) accept either 2" (51mm) or 3" (76mm) media cores |
| Maximum Media Roll Diameter |
6.0" (152mm) (when using a 3.0", 76mm core) |
| Borderless Photo Sizes |
BorderFree Roll Printing:
Left and right borderless "bleed" printing for the following roll media widths:
10" (254mm), 13" (330mm), 16" (406mm), 17" (686mm) and 24" (610mm)
Top and bottom edges can be automatically cut to any length when printing on roll media |
| Cutter |
Built-in rotary cutter, automatic and manual |
| Paper Sizes |
Sheet Paper:
Minimum: 8.3" x 11.0" (211 x 78mm)
Maximum: 24" (610mm) wide |
| Paper Types |
Epson and comparable third party photographic, fine art, proofing, signage, coated matte and coated gloss media |
| Media Thickness |
12 lb bond (46 gsm) up to 0.06" (1.5mm, 1000 gsm) poster board |
| Paper-Feed Method |
Auto-loading |
| Interfaces |
1 x Hi-Speed USB 2.0 (1.1 compatible)
1 x Ethernet port (10/100Base-T) |
| Network Capable |
Wired Ethernet 10/100Base-T |
| Operating Systems Supported |
Mac:
Tiger 10.4.9 or higher
Leopard 10.5 or higher (16-bit)
Snow Leopard 10.6 or higher (16-bit)
Windows:
XP, Vista and 7 (32 & 64-bit) |
| Status Display |
2.5"/64mm color LCD |
| Image Preview Display |
No |
| Front Panel Controls |
Yes |
| Acoustic Noise |
Approximately 45 dB(A) according to ISO 7779 |
| Power Requirements |
120VAC, 60Hz |
| Dimensions (W x D x H) |
54.0 x 27.0 x 48.0" (1372 x 686 x 1219mm) - including printer stand |
| Weight |
187 lb (85 kg) - including printer stand |
