| Print method |
Serial inkjet, 128 nozzles |
| Print resolution |
180 dpi x 180 dpi |
| Print font |
Font : A=12 x 24 dot/Font B=9 x 17 dot
Column capacity: Font A=40 cols/Font B=53 cols (roll receipt), Font A=62 cols/Font B=82 cols (validation station)
Special mode: Font A=43 cols/Font B=60 cols (roll receipt), Font A=67 cols/Font B=93 cols (validation station |
| Character size |
1.41 x 3.38/0.99 x 2.4mm (W x H) |
| Character set |
95 Alphanumeric, 37 International, 128 x 11 Graphic |
| Bar code |
UPC-A, UPC-E, JAN8 (EAN), JAN13 (EAN), 2 of 5 (ITF), Code39, Code93, Code128, CODABAR (NW7) |
| Characters per inch |
15 cpi (Font A)/20 cpi (Font B) |
| Interface |
USB, Dealer option: RS-232, Bi-directional parallel, Ethernet and Connect-It family |
| Data buffer |
4KB |
| Print speed |
Character: 14.3 lps (8 lines/inch)/graphic: 43mm/sec. (76mm width paper, full columns print) |
| Paper dimensions |
Receipt: 76mm (3.0")
Endorsement/Validation: 68.0 - 101.6(W) x 150.0 - 223.0(L)mm [2.7"-4.0"(W) x 5.9" - 8.8"(L)] |
| Paper thickness |
Receipt: 0.06 - 0.09mm
Endorsement/Validation: 0.09 - 0.14mm |
| Ink cartridge |
SJIC6, SJIC7(R), SJIC7(G), SJIC7(B) |
| Ink yield |
Up to 15,000,000 characters (2 colors combined) |
| Power |
24 VDC±10% |
| Power consumption |
Approx. 1 A (operating) |
| Reliability |
MTBF: 180,000 hours
MICR reliability: 1 million reads |
| Scanner Type |
Sheetfed scanner |
| Scanner: Grayscale Depth |
8-bit (256 gray levels) |
| Scanner: Optical/Interpolated Resolution |
200 |
| Printer: Dimensions (W x H x D) |
225 x 180 x 232mm {8.8" x 7.1" x 9.1"} (without feeder pocket)
390 x 180 x 232mm {15.4" x 7.1" x 9.1"} (with feeder pocket) |
| Printer: Weight |
Approx. 4.0 kg (4.5 kg with feeder pocket)
Approx. 8.82lbs (9.92lbs with feeder pocket) |
