| Viewable Image Area |
76.2 cm (30.0 in.) widescreen; diagonally measured |
| Screen Opening |
64.4 x 40.3 cm (25.4 x 15.9 in.) |
| Panel Type |
S-IPS (H2-IPS technology for improved energy efficiency) |
| Resolution |
2560 x 1600 |
| Aspect Ratio |
16:10 |
| Viewing Angle |
Up to 178deg. horizontal/178deg. vertical (10:1 minimum contrast ratio) |
| Brightness |
370 nits (cd/m2) |
| Contrast Ratio |
1000:1 |
| Dynamic Contrast Ratio |
3,000:1 |
| Response Time |
7 ms (gray to gray); 12 ms (on/off) |
| Pixel Pitch |
0.2505 mm |
| Backlight Lamp Life |
40,000 hours |
| Color Support |
1.07 billion colors |
| Color Gamut |
102% (CIE 1931) |
| Size vs. NTSC |
100% (CIE 1976) |
| Coverage of sRGB |
99% (CIE 1976) |
| Buttons or Switches |
Input select, brightness up, brightness down, power |
| User Controls |
Brightness, input selection, power |
| Horizontal Frequency |
100 kHz |
| Vertical Frequency |
60 Hz |
| Native Resolution |
2560 x 1600 @ 60 Hz |
| Preset VESA Graphic |
2560 x 1600 @ 60 Hz |
| Maximum Pixel ClockSpeed |
275 MHz |
| User Programmable Modes |
No |
| Anti-Glare |
Yes |
| Anti-Static |
Yes |
| Default Color Temperature |
6500 K |
| Self Powered USB 2.0 Hub |
One upstream, four downstream ports (cable included) |
| Input Connectors |
1 x DisplayPort connector, 1 x DVI-D connector, Dual-Link HDCP support on DisplayPort and DVI |
| Sync Input |
Separate synch |
| Video Cable |
1 x Dual-Link DVI-D to DVI-D, 1 x DisplayPort |
| Video Cable Lengths |
1.8 m (5.9 ft) |
| Input Power |
100 - 240 VAC, 50 or 60 Hz |
| Typical Power Consumption |
130W |
| Maximum |
185 W |
| Power Saving |
< 2 W |
| Power Cable Length |
1.8 m (5.9 ft) |
| Tilt Range |
-5deg. to + 35deg. vertical |
| Swivel Range |
45deg.L / 45deg.R |
| Height Adjustable |
Yes, 100 mm |
| Temperature - Operating |
5deg. to 35deg. C (41deg. to 95deg. F) |
| Temperature - Non operating |
-20deg. to 60deg. C (-4deg. to 140deg. F) |
| Humidity - Operating |
10% to 80% non-condensing |
| Humidity - Non operating |
5% to 95% |
| Altitude - Operating |
+0 to 5,000 m (16,404 ft) |
| Altitude - Non-operating |
+0 to 12,192 m (40,000 ft) |
| Dimensions (H x W x D) |
With Stand: 27.3 x 19.3-23.3 x 10.9" (69.4 x 48.9-58.9 x 27.6cm)
Without Stand: 27.3 x 17.9 x 3.4" (69.4 x 45.4 x 8.7cm) |
| Weight |
28.6 lb (13kg) |
