| Projector Display System |
0.65" 1-Chip DMD (DLP projector) |
| Native Resolution |
1920 x 1080 |
| Number of Pixels |
2,073,600 |
| Aspect Ratio |
16:9 |
| Brightness |
1300 ANSI Lumens |
| Contrast Ratio |
4000:1 |
| Color Wheel |
6-segment (RGBRGB) |
| System |
NTSC, NTSC 4.43, PAL, PAL-M, PAL-N, PAL-60, SECAM |
| HDTV Compatibility |
480i/p, 525i/p, 576i/p, 625i/p, 720p, 750p, 1080i, 1125i/60Hz, 1080i, 1125i/50Hz, 1080p/50Hz, 1080p/60Hz, 1080p/24Hz |
| Lens |
4 cluster-13 piece (all-glass lens) |
| F Number |
3.0 - 3.5 |
| Focal Length |
20.6 - 30.1 mm |
| Throw Ratio |
1.38 - 2.06 |
| Focus/Zoom Adjusting |
Focus: manual Zoom: manual |
| Recommended Projection Size |
Capable of projecting a 50 - 300" diagonal image (127 - 762 cm) |
| Keystone Correction |
Yes |
| Ceiling Mountable |
Yes |
| Rear Screen Projection |
The HC4000 has rear screen projection, but Mitsubishi recommends that you consult a specialist during installation |
| Projection Tilt Option |
Yes - adjustment feet |
| Input Terminals |
RGB: mini D-sub 15pin x 1 Video: RCA x 1, S-video x 1 Component Video: RCA x 3 Digital: HDMI 1.3 x 1 |
| Control Protocol |
Serial: Mini-DIN 8pin (RS232C) x 1 Trigger: DC 12 V, max. 200 mA (stereo mini jack) |
| Lamp (Bulb) |
230W |
| Lamp Life |
5000 hrs (low mode) |
| Scanning Frequency |
H: 15 - 80kHz V: 50 - 85Hz Dot-clock max: 170MHz |
| Fan Noise |
Standard mode: 31 dBA Low mode: 25 dBA |
| Remote Control |
Yes |
| Power Requirements |
AC 100 - 240 V, 50 / 60Hz |
| Power Consumption |
Standard mode: 340W Standby: 0.5W |
| Operating Temperature |
41 - 95deg.F (5 - 35deg.C) |
| Dimensions (W x H x D) |
13.6 x 5.1 x 10.6" (34.5 x 13 x 26.9 cm) |
| Weight |
7.7 lb (3.5 kg) |
