| Camera Type |
Digital camera with interchangeable lens |
| Lens Mount |
Nikon 1 mount |
| Picture Angle |
Approx. 2.7x lens focal length (Nikon CX format) |
| Effective Pixels |
10.1 million |
| Sensor Size |
13.2mm x 8.8mm |
| Image Sensor Format |
CX |
| Image Sensor Type |
CMOS |
| Total Pixels |
12 million |
| Dust-reduction system |
Image sensor cleaning |
| Image Area (pixels) |
Still Images (3:2 aspect ratio): 3872 x 2592, 2896 x 1944, 1936 x 1296
Smart Photo Selector (3:2 aspect ratio): 3872 x 2592, 2896 x 1944, 1936 x 1296
Movie Mode (16:9 aspect ratio): 3840 x 2160 (1080/60i), 1920 x 1080 (1080/30p), 1280 x 720 (720/60p)
Motion Snapshot (16:9 aspect ratio): 3840 x 2160 |
| File Format |
Compressed 12-bit NEF (RAW)
JPEG: JPEG-Baseline compliant with fine (approx 1:4), normal (approx 1:8), or basic (approx 1:16) compression
NEF (RAW) + JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats |
| Picture Control |
Standard, Neutral, Vivid, Monochrome, Portrait, Landscape, Selected Picture Control can be modified, User-customizable Settings |
| Storage Media |
SD, SDHC, SDXC |
| Card Slot |
1 Secure Digital (SD) |
| File System |
Compliant with DCF (Design Rule for Camera File System) 2.0
DPOF (Digital Print Order Format)
EXIF 2.3 (Exchangeable Image File Format for Digital Still Cameras)
PictBridge |
| Viewfinder |
LCD |
| Shutter type |
Electronic Shutter |
| Fastest Shutter Speed |
1/16,000 sec. in steps of 1/3EV |
| Slowest Shutter Speed |
1/3 second |
| Flash Sync Speed |
Up to 1/60 sec. |
| Bulb Shutter Setting |
Yes |
| Shutter Release Modes |
Single-frame [S] mode, Continuous, Electronic [Hi], Self-timer mode, Delayed remote, Quick Response Remote, Interval Timer Shooting |
| Frame Advance Rate |
Electronic [Hi]: Approx. 10, 30 or 60 fps
Other modes: Up to 5 fps (single AF or manual focus, S Shutter- priority auto or M Manual exposure mode, shutter speed 1/250 sec or faster and other settings at default values) |
| Shooting Speed at full resolution |
5 frames per second 10, 30 or 60 fps using Electronic (Hi) shutter |
| Self-timer |
2, 5, 10 sec. Timer duration electronically controlled |
| Remote Control Modes |
Delayed remote (2 sec), Quick-response remote |
| Exposure Metering System |
TTL metering using image sensor |
| Metering Method |
Matrix
Center-weighted: Meters 4.5 circle in center of frame
Spot: Meters 2 mm circle centered on select focus area |
| Exposure Modes |
Programmed Auto with flexible Program (P), Shutter-Priority Auto (S), Aperture-Priority Auto (A), Aperture-Priority (A), Manual (M), Scene Auto Selector |
| Scene Modes |
Portrait, Landscape, Night Portrait, Close-up, Auto |
| Shooting Modes |
Still Image (3:2), Smart Photo Selector (3:2), Movie (HD 16:9), Movie Slow Motion (8:3), Motion Snapshot (16:9) |
| Exposure Compensation |
±3 EV in increments of 1/3EV |
| Exposure Lock |
Luminosity locked at metered value with AE-L/AF-L button |
| ISO Sensitivity |
100-3200
6400 |
| Active D-Lighting |
On, Off |
| Autofocus System |
Hybrid autofocus (phase detection/contrast-detect AF), AF-assist illuminator |
| AF-area mode |
Single-point AF: 135 focus areas, Auto-area AF: 41 focus areas, Subject tracking, Face-priority AF |
| Focus Lock |
Focus is locked by pressing AE-L/AF-L button or lightly pressing shutter release button in (S) AF |
| Focus Modes |
Auto (AF)
Auto AF-S/AF-C selection (AF-A)
Single-servo AF (AF-S)
Continuous-servo (AF-C)
Full-time Servo (AF-F)
Manual Focus (MF) |
| Built-in Flash |
Yes |
| Flash Control |
i-TTL flash control using image sensor available |
| Flash Mode |
Fill-flash, Slow sync, Red-eye reduction, Slow sync with red-eye reduction, Rear curtain with sync, Rear curtain with slow sync |
| Flash Compensation |
-3 to +1 EV in increments of 1/3 EV |
| Flash-ready indicator |
Lights when built-in flash unit is fully charged |
| White Balance |
Auto, Incandescent, Fluorescent, Direct Sunlight, Flash, Cloudy, Shade, Preset Manual, All except preset manual with fine tuning |
| Movie Metering |
TTL exposure metering using main image sensor |
| Movie Metering method |
Matrix
Center-weighted: Meters 4.5 circle in center of frame
Spot: Meters 2 mm circle centered on select focus area |
| Movie File Format |
MOV |
| Movie Video Compression |
H.264/MPEG-4 Advanced Video Coding |
| Movie Audio recording format |
AAC |
| Movie Audio recording device |
Built-in stereo microphone; sensitivity adjustable
Optional external ME-1 stereo microphone |
| Movie |
HD: 1920 X 1080/60i
HD: 1920 X 108/30p
HD: 1280 x 720/60p
Slow-motion: 640x240/400fps
Slow-motion: 320x120/1200fps
Motion Snapshot: 1920x1080/60p (plays at 24p)
Audio file format: ACC
Movie file format: MOV |
| Monitor Size |
3.0 in. diagonal |
| Monitor Resolution |
460,000 Dots |
| Monitor Type |
TFT-LCD with brightness adjustment |
| Interface |
USB: Hi-speed USB
HDMI output: Type C mini-pin HDMI connector |
| Supported Languages |
Arabic, Chinese (Simplified and Traditional), Danish, Dutch, English, Spanish, Finnish, French, Italian, German, Indonesian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Swedish, Czech, Norwegian, Thai, Turkish |
| Daylight Savings Time Settings |
Yes |
| World Time Setting |
Yes |
| Battery Type |
EN-EL20 Lithium-ion Battery |
| Battery Life (shots per charge) |
230 shots (CIPA) |
| AC Adapter |
EH-5b AC Adapter
Requires EP-5C Power Supply Connector |
| Tripod Socket |
1/4 in. (ISO1222) |
| Operating Environment |
32 to 104 deg. F (0 to 40 deg. C) Less than 85% humidity (no condensation) |
| Dimensions (W x H x D) |
4.2 x 2.4 x 1.2 inches (106 x 61 x 29.8mm) |
| Weight |
8.3oz. (234g) |
