| Type |
Advanced Camera with Interchangeable Lenses |
| Lens Mount |
Nikon 1 mount |
| Picture Angle |
Approx. 2.7x lens focal length (Nikon CX format) |
| Effective Pixels |
10.1 million |
| Sensor Size |
13.2mm x 8.8mm |
| Image Sensor Format |
CX |
| Image Sensor Type |
CMOS |
| Total Pixels |
12.0 million |
| Dust-reduction System |
Dust Shield |
| Image Area (pixels) |
Still Images (3:2 aspect ratio) 3,872 x 2,592 2,896 x 1,944 1,936 x 1,296 Still images (aspect ratio 16:9) 3,840 × 2,160 (Motion Snapshot mode or 1,080/60i, 1,080/30p selected in advanced movie mode) 1,280 × 720 (720/60p, 720/30p selected in advanced movie mode) |
| File Format |
Compressed 12-bit NEF (RAW) JPEG: JPEG-Baseline compliant with fine (approx 1:4), normal (approx 1:8), or basic (approx 1:16) compression |
| Picture Control |
Standard Neutral Vivid Monochrome Portrait Landscape Selected Picture Control can be modified User-customizable Settings |
| Storage Media |
SD SDHC SDXC |
| Card Slot |
1 Secure Digital (SD) |
| File System |
Compliant with DCF (Design Rule for Camera File System) 2.0 DPOF (Digital Print Order Format) EXIF 2.3 (Exchangeable Image File Format for Digital Still Cameras) PictBridge |
| Viewfinder |
LCD |
| Lens Aperture |
Electronically controlled |
| Shutter Type |
Electronic Shutter |
| Fastest Shutter Speed |
1/16,000 sec. |
| Slowest Shutter Speed |
30 sec. |
| Flash Sync Speed |
Up to 1/60 sec. |
| Bulb Shutter Setting |
Yes |
| Shutter Release Modes |
Single-frame [S] mode Continuous Self-timer mode |
| Frame Advance Rate |
Approx. 5, 15, 30, or 60 fps |
| Continuous Shooting Speed at Full Res |
15 frames per second with AF; 30/60 fps with focus locked on first frame |
| Self-timer |
2, 5, 10 sec. Timer duration electronically controlled |
| Remote Control Modes |
WU-1b Wireless Mobile Adapter |
| Exposure Metering System |
TTL metering using image sensor |
| Metering Method |
Matrix Center-weighted: Meters 4.5mm circle in center of frame Spot: Meters 2mm circle centered on select focus area |
| Exposure Modes |
Programmed Auto with flexible Program (P) Shutter-Priority Auto (S) Aperture-Priority Auto (A) Manual (M) Scene Auto Selector |
| Scene Modes |
Portrait Landscape Night Landscape Night Portrait Close-up Auto |
| Shooting Modes |
Advanced movie mode (includes slow motion) Auto Photo mode Best Moment Capture mode (includes Slow View and Smart Photo Selector) Creative mode (including: P, S, A, M, Night Landscape, Night Portrait, Backlighting, Soft, Miniature Effect, and Selective Color) Motion Snapshot (16:9) |
| Exposure Compensation |
±3 EV in increments of 1/3EV |
| Exposure Lock |
Luminosity locked at detected value with AE-L/AF-L button |
| ISO Sensitivity |
100-6400 |
| Active D-Lighting |
On / Off |
| Autofocus System |
Hybrid autofocus (phase detection/contrast-detect AF) / AF-assist illuminator |
| AF-area Mode |
Single-point AF: 135 focus areas; the center 73 areas support phase-detection AF Auto-area AF: 41 focus areas Subject tracking Face-priority AF |
| Focus Lock |
Focus can be locked by pressing shutter-release button halfway (single AF) |
| Focus Modes |
Auto (AF) Auto AF-S/AF-C selection (AF-A) Single-servo AF (AF-S) Continuous-servo (AF-C) Full-time Servo (AF-F) Manual Focus (MF) |
| Built-in Flash |
Yes |
| Guide Number |
5/16 (m/ft ISO 100, 20°C/68°F) Approx. |
| Flash Control |
i-TTL flash control using image sensor available |
| Flash Mode |
Auto Auto with red-eye reduction Fill-flash Fill-flash with Slow sync Red-eye reduction Red-eye reduction with Slow sync Rear curtain sync Rear curtain with slow sync Slow sync with red-eye reduction Off |
| Flash Compensation |
-3 to +1 EV in increments of 1/3 EV |
| Flash-ready Indicator |
Lights when built-in flash unit is fully charged |
| White Balance |
Auto Incandescent Fluorescent Direct Sunlight Flash Cloudy Shade Preset Manual Underwater All except preset manual with fine tuning |
| Movie Metering |
TTL exposure metering using main image sensor |
| Movie Metering Method |
Matrix Center-weighted: Meters 4.5mm circle in center of frame Spot: Meters 2mm circle centered on select focus area |
| Movie File Format |
MOV |
| Movie Video Compression |
H.264/MPEG-4 Advanced Video Coding |
| Movie Audio Recording Format |
AAC |
| Movie Audio Recording Device |
Built-in stereo microphone; sensitivity adjustable |
| Movie |
HD: 1920 x 1080/60i HD: 1920 x 1080/30p HD: 1280 x 720/60p HD: 1280 x 720/30p Slow-motion: 640 x 240/400fps Slow-motion: 320 x 120/1200fps Motion Snapshot: 1,280 x 720/60p (plays at 24p) Audio file format: ACC Movie file format: MOV |
| Monitor Size |
3.0 in. diagonal |
| Monitor Resolution |
460,000 Dots |
| Monitor Type |
Monitor Type TFT-LCD with brightness adjustment |
| Interface |
USB: Hi-speed USB HDMI output: Type C mini-pin HDMI connector |
| Supported Languages |
Arabic Bengali Chinese (Simplified and Traditional) Czech Danish Dutch English Finnish French German Greek Hindi Hungarian Indonesian Italian Japanese Korean Norwegian Polish Portuguese (European and Brazilian) Romanian Russian Spanish Swedish Tamil Thai Turkish Ukrainian Vietnamese |
| Date and Time |
Yes |
| World Time Setting |
Yes |
| Battery |
EN-EL20 Lithium-ion Battery |
| Battery Life (shots per charge) |
220 shots (CIPA) |
| AC Adapter |
EH-5b AC Adapter Requires EP-5C Power Supply Connector |
| Tripod Socket |
1/4" |
| Operating Environment |
32 to 104°F (0 to 40°C) |
| Dimensions (WxHxD) |
4 x 2.4 x 1.2" (102 x 60.5 x 29.7mm) |
| Weight |
6.9 oz (197g) camera body |
| Included Lens |
Focal Length: 11-27.5mm / Comparable 35mm Focal Length: 30 - 74mm Aperture: Maximum: f/3.5 - 5.6 / Minimum: f/16 - 16 Angle of View: 72° - 32° Minimum Focus Distance: 1.0' (30.48 cm) Groups/Elements: 6/8 Diaphragm Blades: 7 Autofocus: Yes Image Stabilization: No Filter Thread: Front: 40.5 mm Dimensions (DxL): Approx. 2.26 x 1.22" (5.74 x 3.10 cm) Weight: 3 oz (85 g) |
