| Lens Mount |
Nikon 1 mount |
| Picture Angle |
Approx. 2.7x lens focal length (Nikon CX format) |
| Effective Pixels |
10.1 million |
| Sensor Size |
13.2mm x 8.8mm |
| Image Sensor Format |
CX |
| Image Sensor Type |
CMOS |
| Total Pixels |
12 million |
| Dust-reduction system |
Image sensor cleaning |
| Image Area (pixels) |
Still Images (3:2 aspect ratio) 3,872 x 2,592 2,896 x 1,944 1,936 x 1,296 Smart Photo Selector (3:2 aspect ratio) 3,872 x 2,592 2,896 x 1,944 1,936 x 1,296 Movie Mode (16:9 aspect ratio) 3,840 x 2,160 (1080/60i) 1,920 x 1,080 (1080/30p) 1,280 x 720 (720/60p) Motion Snapshot (16:9 aspect ratio) 3,840 x 2,160 |
| File Format |
Compressed 12-bit NEF (RAW) JPEG: JPEG-Baseline compliant with fine (approx 1:4), normal (approx 1:8), or basic (approx 1:16) compression NEF (RAW) + JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats |
| Picture Control |
Standard Neutral Vivid Monochrome Portrait Landscape Selected Picture Control can be modified User-customizable Settings |
| Storage Media |
SD SDHC SDXC |
| Card Slot |
1 Secure Digital (SD) |
| File System |
Compliant with DCF (Design Rule for Camera File System) 2.0 DPOF (Digital Print Order Format) EXIF 2.3 (Exchangeable Image File Format for Digital Still Cameras) PictBridge |
| Viewfinder |
Color LCD viewfinder, 0.47 inches(1.2cm) TFT LCD approx 1.44m dot with diopter adjustment function |
| Viewfinder Frame Coverage |
100% Approx. |
| Viewfinder Diopter Adjustment |
-3 to +1 m-1 |
| Lens Aperture |
Electronically controlled |
| Eye Sensor |
Camera switches to viewfinder display when it detects that viewfinder is in use |
| Shutter type |
Electronically-controlled vertical-travel focal plane mechanical shutter; electronic shutter |
| Fastest Shutter Speed |
Electronic Shutter: 1/16,000 sec. in steps of 1/3EV Mechanical Shutter: 1/4,000 sec. in steps of 1/3EV |
| Slowest Shutter Speed |
30 sec. in steps of 1/3EV with either Electronic or Mechanical Shutter |
| Flash Sync Speed |
Electronic shutter: 1/60 sec. Mechanical shutter: 1/250 sec. |
| Bulb Shutter Setting |
Yes |
| Shutter Release Modes |
Single-frame [S] mode Continuous Mechanical Electronic Electronic [Hi] Self-timer mode Delayed remote Quick Response Remote Interval Timer Shooting |
| Frame Advance Rate |
Electronic [Hi]: Approx. 10, 30 or 60 fps Other modes: Up to 5 fps (single AF or manual focus, S Shutter- priority auto or M Manual exposure mode, shutter speed 1/250 sec or faster and other settings at default values) |
| Top Continuous Shooting Speed |
5 frames per second 10, 30 or 60 fps using Electronic (Hi) shutter (at full resolution) |
| Self-timer |
2, 5, 10 sec. Timer duration electronically controlled |
| Remote Control Modes |
Delayed remote (2 sec) Quick-response remote |
| Exposure Metering System |
TTL metering using image sensor |
| Metering Method |
Matrix Center-weighted: Meters 4.5 circle in center of frame Spot: Meters 2 mm circle centered on select focus area |
| Exposure Modes |
Programmed Auto with flexible Program (P) Shutter-Priority Auto (S) Aperture-Priority Auto (A) Aperture-Priority (A) Manual (M) Scene Auto Selector |
| Scene Modes |
Portrait Landscape Night Portrait Close-up Auto |
| Shooting Modes |
Still Image (3:2) Smart Photo Selector (3:2) Movie (HD 16:9) Movie Slow Motion (8:3) Motion Snapshot (16:9) |
| Exposure Compensation |
±3 EV in increments of 1/3EV |
| Exposure Lock |
Luminosity locked at metered value with AE-L/AF-L button |
| ISO Sensitivity |
100-3200 6400 |
| Active D-Lighting |
On Off |
| Autofocus System |
Hybrid autofocus (phase detection/contrast-detect AF) AF-assist illuminator |
| AF-area mode |
Single-point AF: 135 focus areas Auto-area AF: 41 focus areas Subject tracking Face-priority AF |
| Focus Lock |
Focus is locked by pressing AE-L/AF-L button or lightly pressing shutter release button in (S) AF |
| Focus Modes |
Auto (AF) Auto AF-S/AF-C selection (AF-A) Single-servo AF (AF-S) Continuous-servo (AF-C) Full-time Servo (AF-F) Manual Focus (MF) |
| Flash Control |
i-TTL flash control using image sensor available with optional SB-N5 flash unit |
| Flash Mode |
Fill-flash Slow sync Red-eye reduction Slow sync with red-eye reduction Rear curtain with sync Rear curtain with slow sync |
| Flash Compensation |
-3 to +1 EV in increments of 1/3 EV |
| Flash-ready indicator |
Lights when optional flash unit is fully charged |
| Accessory Shoe |
Yes |
| Nikon Creative Lighting System (CLS) |
i-TTL flash control using image sensor available with optional SB-N5 flash unit |
| White Balance |
Auto Incandescent Fluorescent Direct Sunlight Flash Cloudy Shade Preset Manual All except preset manual with fine tuning |
| Movie Metering |
TTL metering using image sensor |
| Movie Metering method |
Matrix Center-weighted: Meters 4.5 circle in center of frame Spot: Meters 2 mm circle centered on select focus area |
| Movie File Format |
MOV |
| Movie Video Compression |
H.264/MPEG-4 Advanced Video Coding |
| Movie Audio recording format |
AAC |
| Movie Audio recording device |
Built-in stereo microphone; sensitivity adjustable Optional external ME-1 stereo microphone |
| Movie |
HD: 1920 X 1080/60i HD: 1920 X 1080/30p HD: 1280 x 720/60p Slow-motion: 640x240/400fps Slow-motion: 320x120/1200fps Motion Snapshot: 1920x1080/60p (plays at 24p) Audio file format: ACC Movie file format: MOV |
| Monitor Size |
3.0 in. diagonal |
| Monitor Resolution |
921,000 Dots |
| Monitor Type |
TFT-LCD with brightness adjustment |
| Interface |
USB: Hi-speed USB HDMI output: Type C mini-pin HDMI connector Accessory hot shoe used for designated accessories Video output: NTSC/PAL Audio input: Stereo mini-pin jack (3.5mm diameter) |
| Supported Languages |
Arabic Chinese (Simplified and Traditional) Danish Dutch English Spanish Finnish French Italian German Indonesian Japanese Korean Polish Portuguese Russian Spanish Swedish Czech Norwegian Thai Turkish |
| Time Settings |
Yes (Date, Time and Daylight Savings) |
| World Time Setting |
Yes |
| Battery / Batteries |
EN-EL15 Lithium-ion Battery |
| Battery Life (shots per charge) |
350 shots (CIPA) |
| AC Adapter |
EH-5b AC Adapter Requires EP-5B Power Supply Connector |
| Tripod Socket |
1/4 in. (ISO1222) |
| Operating Environment |
32 to 104deg.F (0 to 40deg.C) Less than 85% humidity (no condensation) |
| Dimensions (W x H x D) |
4.4 x 3.0 x 1.7" (11.18 x 7.62 x 4.32 cm) Kit Lens: 2.3 x 7.1" (5.84 x 18.03 cm) |
| Weight |
10.4 oz / 295 g (Body only) Kit Lens: 4.1 oz (116 g) |
