| Effective Pixels |
14.1 million |
| Image Sensor |
1/2.3-in. type CCD |
| Total Pixels |
14.48 million |
| Lens |
5x optical zoom, NIKKOR lens |
| Lens Focal Length |
5.0-25.0mm (angle of view equivalent to that of 28-140mm lens in 35mm [135] format) |
| Lens f/-number |
f/3.9-5.8 |
| Lens Construction |
13 elements in 9 groups |
| Digital Zoom |
Up to 4x (angle of view equivalent to that of 560mm lens in 35mm [135] format) |
| Vibration Reduction |
Combination of lens-shift and electronic VR (still pictures) Lens-shift (movies) |
| Autofocus (AF) |
Contrast-detect AF |
| Autofocus (AF) Focus range (from lens) |
Approx. 30cm (1 ft) to infinity (Wide) Approx. 50cm (1 ft 8in.) to infinity (Tele) Macro mode: Approx. 3cm (1.2in.) to infinity, zoom indicator positioned to the maximum (wide-angle position) |
| Autofocus (AF) Focus-area selection |
Face priority Auto (9-area automatic selection) Center Manual (focus area can be selected using the touch panel) Subject tracking |
| Monitor Size |
3 in. diagonal |
| Monitor Type |
TFT-LCD (touch panel) 5-level brightness adjustment |
| Monitor Resolution |
460,000-dots |
| Monitor Frame coverage (shooting mode) |
97% horizontal (Approx.) 97% vertical (Approx.) |
| Monitor Frame coverage (playback mode) |
100% horizontal (Approx.) 100% vertical (Approx.) |
| Storage Media |
SD memory card SDHC memory card SDXC memory card 79MB internal memory (approx.) |
| Storage File System |
DCF EXIF 2.2 DPOF compliant |
| Storage File formats |
Still pictures: JPEG Sound files (Voice Memo): WAV Movies: MOV (video:MPEG-4 AVC/H.264, audio: AAC monaural) |
| Image Size (pixels) |
4320 x 3240 (14M) 3264 x 2448 (8M) 2592 x 1944 (5M) 2048 x 1536 (3M) 1024 x 768 (PC) 640 x 480 (VGA) 3968 x 2232 (16:9) |
| ISO Sensitivity |
80 100 200 400 800 1600 3200 6400 Auto (auto gain ISO 80-800) Fixed range auto (ISO 80-200, 80-400) |
| Exposure Metering |
256-segment matrix, center-weighted (digital zoom less than 2x) Spot (digital zoom 2x or more) |
| Exposure Control |
Programmed auto exposure with motion detection Exposure compensation (-2.0 to +2.0 EV in steps of 1/3 EV) |
| Exposure Range (auto mode) |
[W]: 1 to 16.7 EV [T]: 2.1 to 17.9 EV |
| Shutter |
Mechanical and charge-coupled electronic shutter |
| Shutter Speed |
1/1500-2 sec. 4 sec. (when scene mode is set to Fireworks show) |
| Aperture |
Electronically-controlled ND filter (-2 AV) selection |
| Aperture Range |
2 steps (f/3.9 and f/7.8 [W]) |
| Self-timer |
Can be selected from 10 and 2 seconds duration |
| Built-in flash Range (approx.) |
[W]: 0.3 to 3.5m (1ft. to 11ft.) [T]: 0.5 to 2.5m (1ft. 8in. to 8ft. 2in.)(ISO sensitivity: Auto) |
| Built-in Flash Control |
TTL auto flash with monitor preflashes |
| Interface |
Hi-speed USB |
| Interface Data transfer protocol |
MTP PTP |
| Video Output |
NTSC PAL |
| I/O terminal |
Audio/video (A/V) output Digital I/O (USB) |
| Projection system |
Single lamp/single LCD panel |
| Projection LCD panel |
One 0.4-in reflective panel with an aspect ratio of 4:3 921,000-dot (approx.) |
| Projector lens |
21mm f/3.5, manual focus |
| Projector Light Source |
One high luminance white LED |
| Projector Image Size |
13 to 120cm (5 to 47-in.) |
| Projector Throw Distance |
Approx. 0.26 to 2.4m (10in. to 7ft. 10in.) |
| Projector Number of colors |
Full color (approx. 16.7 million colors) |
| Projector Brightness |
Up to 14 lumens |
| Projector Contrast ratio |
30:1 |
| Projector Resolution (output) |
VGA equivalent |
| Projector Endurance (battery life) |
Approx. 1 hour with EN-EL12 battery |
| Supported Languages |
Arabic Czech Chinese (Simplified and Traditional) Danish Dutch English Finnish French German Greek Hungarian Indonesian Italian Japanese Korean Norwegian Polish Portuguese Russian Spanish Swedish Thai Turkish |
| Power Sources |
One Rechargeable Li-ion Battery EN-EL12 (supplied) AC Adapter EH-62F (available separately) |
| Battery Life (shots per charge) |
Still pictures: Approx. 220 shots Movies: Approx. 1 hour 35 min. (HD 720p (1280 x720)) |
| Tripod Socket |
1/4 (ISO 1222) |
| Operating environment |
Temperature: 0 to 40deg. C (32 to 104deg. F) Temperature: When using the projector: 0 to 35deg. C (32 to 95deg. F) Humidity: Less than 85% (no condensation) |
| Dimensions (W x H x D) |
4.0 x 2.5 x 1.0in / 100.8 x 62.7 x 24.1mm (excluding projections) |
| Weight |
6.4oz / 180g (with battery and SD memory card) |
