| Lens Mount |
Nikon F bayonet mount |
| Picture Angle |
Nikon FX format |
| Effective Pixels |
24.3 million |
| Image Sensor |
CMOS sensor, 35.9mm x 24.0mm, Nikon FX format |
| Total Pixels |
24.7 million |
| Dust-Reduction System |
Image sensor cleaning |
| Dust-Off Reference Photo |
Yes |
| Image Area (pixels) |
FX-format: (L) 6,016 x 4,016 (M) 4,512 x 3,008 (S) 3,008 x 2,008 DX-format: (L) 3,936 x 2,624 (M) 2,944 x 1,968 (S) 1,968 x 1,312 |
| File Format Still Images |
JPEG: JPEG-Baseline Compliant; can be selected from Size Priority and Optimal Quality JPEG: JPEG-Baseline Compliant with fine (approx 1:4), Normal (approx 1:8) or Basic (approx 1:16) Compression NEF (RAW): Lossless compressed, compressed 12 or 14 bit |
| Picture Control |
Landscape Monochrome Neutral Portrait Standard User-customizable Settings Vivid |
| Storage Media |
SD SDHC SDXC |
| File System |
Compliant with DCF (Design Rule for Camera File System) 2.0 DPOF (Digital Print Order Format) EXIF 2.3 (Exchangeable Image File Format for Digital Still Cameras) PictBridge |
| Viewfinder |
Eye-level Pentaprism Single-Lens Reflex Viewfinder |
| Viewfinder Frame Coverage |
FX (36x24): 100% Horizontal and 100% Vertical Approx. DX (24x16): 97% Horizontal and 97% Vertical Approx. |
| Viewfinder Magnification |
0.70x Approx. |
| Viewfinder Eyepoint |
20.6mm (-1.0m»?) |
| Viewfinder Diopter Adjustment |
Built-in diopter adjustment (-3 to +1 m»?) |
| Focusing Screen |
Type B BriteView Clear Matte Mark VIII with AF Area Brackets (grid lines can be displayed) |
| Reflex Mirror |
Quick-return type |
| Lens Aperture |
Instant-return type |
| Depth-of-field Control |
Yes |
| Lens Compatibility at a Glance |
AF-S or AF lenses fully compatible Metering with AI lenses |
| Shutter type |
Electronically controlled vertical-travel focal-plane |
| Shutter Speed |
1/4000 to 30 sec. Bulb |
| Fastest Shutter Speed |
1/4000 sec. |
| Slowest Shutter Speed |
30 sec. |
| Flash Sync Speed |
Up to 1/200 sec. Synchronizes with shutter at 1/250s or slower |
| Top Continuous Shooting Speed |
5.5 frames per second (at full resolution) |
| Self-timer |
2, 5, 10, 20 sec. Timer duration electronically controlled |
| Exposure Metering System |
TTL exposure metering using 2,016-pixel RGB sensor |
| Metering Method |
Center-weighted: Weight of 75% given to 12mm circle in center of frame Matrix: 3D color matrix metering II (type G and D lenses); color matrix metering II (other CPU lenses) Spot: Meters 4mm circle (about 1.5% of frame) centered on selected focus point |
| Metering Range |
0 to 20 EV (3D color matrix or center-weighted metering) 0 to 20 EV (spot metering) |
| Exposure Modes |
Aperture-Priority (A) Manual (M) Programmed auto with flexible program (P) Shutter-Priority (S) |
| Exposure Compensation |
±5 EV in increments of 1/3, 1/2 or 1 EV |
| Exposure Bracketing |
2 or 3 frames in steps of 1/3, 1/2, 2/3, 1 or 2 EV |
| ISO Sensitivity |
ISO 100 - 6400 Lo-1 (ISO 50) Hi-1 (ISO 12,800) Hi-2 (ISO 25,600) |
| High ISO Noise Reduction |
Low Normal High Off |
| Autofocus System |
Nikon Multi-CAM 4800 autofocus sensor module with TTL phase detection |
| AF-area mode |
9, 21 or 39 point Dynamic-area AF Auto-area AF Single-point AF 3D-tracking (39 points) |
| Focus Lock |
Focus can be locked by pressing AE-L/AF-L button Focus can be locked by pressing shutter-release button halfway (single-servo AF) |
| Focus Modes |
Auto AF-S/AF-C selection (AF-A) Continuous-servo (AF-C) Face-Priority AF available in Live View only and D-Movie only Manual (M) with electronic rangefinder Normal area Single-servo AF (AF-S) Wide area |
| Flash Control |
TTL: i-TTL flash control using 2,016-pixel RGB sensor are available with built-in flash and SB-910, SB-900, SB-700, or SB-400; i-TTL balanced fill-flash for digital SLR is used with matrix and center-weighting metering, standard i-TTL flash for digital SLR with spot metering |
| Flash Sync Modes |
Front-curtain sync (normal) Rear-curtain sync Red-Eye reduction Red-Eye reduction with slow sync Slow sync |
| Flash Compensation |
-3 to +1 EV in increments of 1/3, 1/2 or 1 EV |
| Flash-ready indicator |
Lights when built-in flash or optional flash unit such as SB-910, SB-900, SB-400, SB-80DX, SB-28DX or SB-50DX is fully charged |
| White Balance |
Auto Choose color temperature (2500K-10000K) Cloudy Direct Sunlight Flash Fluorescent (7 types) Incandescent Preset manual (up to 4 values can be stored) Shade |
| White Balance Bracketing |
2 or 3 exposures |
| Live View AF-area mode |
Face-priority AF Wide-area AF Normal-area AF Subject-tracking AF |
| Movie Metering |
TTL exposure metering using main image sensor |
| Movie Maximum recording time |
20 minutes at highest quality 29 minutes 59 seconds at normal quality |
| Movie File Format |
MOV |
| Movie Video Compression |
H.264/MPEG-4 Advanced Video Coding |
| Movie Audio recording format |
Linear PCM |
| Movie |
HD 1,920x1,080 / 30 fps HD 1,920x1,080 / 25 fps HD 1,920x1,080 / 24 fps HD 1,280x720 / 60 fps HD 1,280x720 / 50 fps HD 1,280x720 / 30 fps HD 1,280x720 / 25 fps |
| Movie Audio |
Built-in microphone, monaural External stereo microphone (optional) |
| Monitor Size |
3.2 in. diagonal |
| Monitor Resolution |
921,000 Dots |
| Monitor Type |
Wide Viewing Angle TFT-LCD |
| Monitor Angle of View |
170-degree wide-viewing angle |
| Monitor Adjustments |
Brightness, 5 levels Brightness control using ambient brightness sensor |
| Playback Functions |
Auto Image Rotation Full-Frame and Thumbnail (4, 9, or 72 images or calendar) Highlights Histogram Display Image Comment Movie Playback Movie Slideshow |
| In-Camera Image Editing |
Color Balance Color Outline Color Sketch D-Lighting Distortion Control Edit Movie Filter Effects Fisheye Image Overlay Miniature Effect Monochrome NEF (RAW) Processing Perspective Control Quick Retouch Red-Eye Correction Resize Selective Color Side-by-Side Comparison Straighten Trim |
| Interface |
Accessory Terminal: Remote Cord: MC-DC2 (available separately); GPS unit: GP-1 (available separately) HDMI output: Type C mini-pin HDMI connector Headphone Connector Hi-speed USB Stereo Microphone Input |
| Wi-Fi Functionality |
Eye-Fi Compatible WU-1b Wireless Mobile Adapter |
| Save/Load Camera settings |
Yes |
| Total custom Settings |
50 |
| My Menu |
Yes with customization |
| Recent Settings |
Yes |
| Battery |
EN-EL15 Lithium-ion Battery |
| AC Adapter |
EH-5b AC Adapter Requires EP-5B Power Supply Connector |
| Operating Environment |
0-40 deg.C (+32-104 deg.F) |
| Lens: Focal Length Range |
28-300mm |
| Lens: Zoom Ratio |
10.7x |
| Lens: Maximum Aperture |
f/3.5 |
| Lens: Minimum Aperture |
f/22 |
| Lens: Format |
FX/35mm |
| Lens: Maximum Angle of View (DX-format) |
53deg. |
| Lens: Minimum Angle of View (DX-format) |
5deg.20' |
| Lens: Maximum Angle of View (FX-format) |
74deg. |
| Lens: Minimum Angle of View (FX-format) |
8deg.10' |
| Lens: Maximum Reproduction Ratio |
0.32x |
| Lens: Lens Elements |
19 |
| Lens: Lens Groups |
14 |
| Lens: Compatible Format(s) |
FX DX FX in DX Crop Mode 35mm Film |
| Lens: VR Image Stabilization |
Yes |
| Lens: Diaphragm Blades |
9 |
| Lens: Distance Information |
Yes |
| Lens: ED Glass Elements |
2 |
| Lens: Aspherical Elements |
3 |
| Lens: Super Integrated Coating |
Yes |
| Lens: Autofocus |
Yes |
| Lens: AF-S (Silent Wave Motor) |
Yes |
| Lens: Internal Focusing |
Yes |
| Lens: Minimum Focus Distance |
1.6 ft. (0.5m) 1.6 ft. (0.5m) throughout entire zoom range |
| Lens: Focus Mode |
Auto Manual |
| Lens: G-type |
Yes |
| Lens: Filter Size |
77mm |
| Lens: Accepts Filter Type |
Screw-on |
| Dimensions |
Camera: 5.6x4.4x3.2"/ 14.22x11.17x8.12cm (WxHxD) Lens: 3.26x4.5"/ 8.12x11.43 (Diameter x Length) |
| Weight |
Camera: 26.8 oz / 760g Lens: 28.2 oz / 800g |
