| Memory |
SD/SDXC/UHS-1 Eye-Fi, Class 6 recommended for video recording |
| Screen size |
17.3 mm (H) x 13.0 mm (V) |
| Lens Mount |
Micro Four Thirds Mount |
| Effective Pixels number |
12.3 million pixels |
| Image Pickup Unit: Product Type |
High speed Live MOS Sensor |
| Total no. of pixels |
Approx. 13.1 million pixels |
| Aspect Ratio |
1.33 (4:3) |
| Filter Array |
Primary color filter (RGB) |
| Dust Reduction |
Supersonic Wave Filter (dust reduction system for image sensor) |
| Recording (Still): Recording Format |
DCF, DPOF compatible/Exif, PRINT Image Matching III |
| Recording (Still): File Format |
RAW (12-bit lossless compression), JPEG, RAW+JPEG, MPO (3D still) |
| Recording (Still): Recording image size |
[RAW] 4032 x 3024 pixels [JPEG] 4032 x 3024 pixels - 640 x 480 pixels |
| Recording (Still): File Size |
RAW: 4032(H)x3024V) (approx. 1/1.5 lossless compressed) Approx. 13.8MB Set1(LF): 4032(H)x3024(V) (1/4 compressed) Approx. 5.9MB Set2(LN): 4032(H)x3024(V) (1/8 compressed) Approx. 2.7MB Set3(MN): 2560(H)x1920(V) (1/8 compressed) Approx. 1.1MB Set4(SN): 1024(H)x768(V) (1/8 compressed) Approx. 0.3MB |
| Recording (Movie): Recording Format |
AVCHD AVI Motion JPEG |
| Recording (Movie): Movie Mode |
AVCHD Format: Full HD Fine: 1920(H)x1080(V), 60i Recording, 20Mbps, Aspect 16:9 - Full HD Normal: 1920(H)x1080(V), 60i Recording, 17Mbps, Aspect 16:9 - HD Fine: 1280(H)x720(V), 60p Recording), 17Mbps, Aspect 16:9 - HD Normal: 1280(H)x720(V), 60p Recording, 13Mbps, Aspect 16:9 Frame rate of image sensor output is 30fps Motion-JPEG Format: HD: 1280(H)x720(V), 30fps (Some Art Filters are exceptional), Aspect 16:9 |
| Recording (Movie): Compression Ratio |
Motion-JPEG Format: 1/12(HD), 1/8(SD) |
| Recording (Movie): File Size |
AVCHD Format: Max 4GB Motion-JPEG Format: Max 2GB |
| Recording (Movie): Maximum Time |
AVCHD Format: Max 29min (Full HD Normal/HD Fine/HD Normal: 29min, Full HD Fine: 22min) Motion-JPEG Format: HD: 7min, SD: 14min (There are exceptions with select Art Filters) |
| Recording(Sound): Recording format |
AVCHD Format: Dolby Digital Motion-JPEG Format / Picture with Sound: Wave Format Base (Stereo PCM/16bit, 48kHz) |
| Recording (Sound): Maximum Time |
Picture with Sound: 30sec Movie: depend on Movie Recording Time |
| Mic/Speaker |
Stereo/Mono |
| Tele-converter effect |
x2 |
| Live View: Type |
Image Sensor (High Speed Live MOS) type |
| Field of view |
100% |
| Display Mode |
Normal Mode Grid Line Mode (4 types) Histogram Mode Magnified View Mode Comparable View Mode Level Gauge OFF Mode |
| Magnification Ratio |
x5, x7, x10 (Default), x14 |
| Monitor information |
Aperture value, Shutter speed, Auto Bracket, AE Lock, AF mode, IS, Shooting Mode, Battery Check, Myset, Internal Temperature Warning, Face / Eye Detection, Histogram, Number of storable still pictures, Record mode, ISO, Sequential shooting, Self-timer, White Balance, Metering Mode, AF confirmation mark, Exposure Compensation Value, Spot metering Area Flash Mode, Flash Status, Flash intensity Control, Super FPTouch panel condition, Focusing length, Tone control, Eye-Fi condition |
| Face Detection |
Max 8 frames of face detection can be displayed |
| AF |
High speed imager AF |
| Image stabilizer: System |
Built in (Imager shift image stabilizer) |
| Image stabilizer: Mode |
3 modes (IS1:2 dimensional activation, IS2:1 dimensional activation in landscape frame to vertical direction moving, IS3:1dimensional activation in portrait frame to vertical direction moving ), OFF |
| Image stabilizer: Manual Function |
input focal length 8, 10, 12, 16, 18, 24, 28, 30, 35, 40, 48, 50, 55, 65, 70, 75, 80, 85, 90, 100, 105, 120, 135, 150, 180, 200, 210, 250, 300, 350, 400, 500, 600, 800, 1000 |
| Image stabilizer: Shutter speed range |
2 - 1/4000 sec. (Not available when Bulb is selected) |
| Image stabilizer: Movie |
Shifting electronic image (so called Digital IS, IS1 mode only) |
| Monitor |
OLED, AF(Anti-Fingerprint) coating, Touch Panel |
| Monitor: Size |
3.0 inches 3:2 |
| Monitor: Total no. of pixels |
Approx. 614,000 dots |
| Monitor: Playback field of view |
100% |
| Monitor: Brightness control |
+2 levels and -2 levels |
| Monitor: Color temperature |
+3 levels and -3 levels |
| Monitor color |
VIVID (Default) / NATURAL |
| Focusing:AF system |
Imager Contrast Detection AF system When non High-speed imager AF compatible lens is used, it works as AF assist |
| Focus mode |
Single AF (S-AF) / Continuous AF (C-AF) / Manual Focus (MF) / S-AF + MF / AF tracking (C-AF + TR)C-AF and AF tracking are not available with non-Micro Four Thirds lenses. This is can be set in both recording mode, still and movie, separately |
| Focusing point |
35-area multiple AF with the contrast detection system (Auto, selectable in option) |
| Focusing point selection |
Auto from all 35 area, Single area from 35 area, Group Target area (9 area) from 35 area Auto from almost all area when Face detection is ON Free selection when Magnified View Mode is selected |
| AF lock |
Locked at first position of Shutter button in Single AF mode |
| Focus tracking |
Yes |
| Magnified Spot AF |
Yes |
| Manual Focus Assist |
When rotation of focus ring is detected under S-AF+MF or MF mode, LV is magnified automatically |
| Exposure Control (Still):Metering system |
TTL Image Sensor metering system (1) Digital ESP metering (324-area multi pattern metering) (2) Center weighted average metering (3) Spot metering (approx. 1% for the viewfinder screen. Highlight / shadow bases are available) |
| Exposure Control (Still): Metering range |
EV 0 - 20 (Digital ESP metering, Centre weighted average metering, Spot metering) |
| Exposure Control (Still): Exposure mode |
(1) iAuto (2) P: Program AE (Program shift can be performed) (3) A: Aperture priority AE (4) S: Shutter priority AE (5) M: Manual (6) Scene select AE (7) Art Filter |
| Scene select AE |
Portrait, e-Portrait, Landscape, Landscape + Portrait, Macro, Sport, Night Scene, Night + Portrait, Children, High Key, Low Key, DIS mode, Nature Macro, Candle, Sunset, Document, Panorama, Fireworks, Beach & Snow, Fisheye Conv, Wide Conv, Macro Conv, 3D |
| Exposure compensation |
±3 EV in 1/3, 1/2, 1 EV steps selectable |
| AE lock |
Yes (Using Fn1/Rec button is available) |
| Exposure bracketing |
2, 3, 5frames in 0.3,0.5, 0.7, 1EV steps selectable, 7frames in 0.3, 0.5, 0.7EV steps selectable |
| Metering standard value adjustment |
1/6 EV step, +/- 1EV range |
| Exposure Control (Movie): Exposure mode |
(1)P: Program AE (2) A: Aperture priority AE (3) S: Shutter speed priority AE (4)M:Manual (5) Art Filter |
| Color space |
sRGB, Adobe RGB |
| White Balance: Auto WB system |
High speed Live MOS sensor |
| Preset white balance |
6 settings (3000K - 7500K)Lamp (3000K), Fluorescent (4000K), Daylight (5300K), Flash (5500K), Cloudy (6000K), Shade (7500K) |
| Flash + WB |
OFF / AWB priority / Flash WB priority |
| White balance compensation |
±7 steps in each A-B/G-M axis (in Auto WB / Preset WB mode / One touch WB) |
| White balance bracketing |
3 frames in 2, 4, 6 steps selectable in each A-B/G-M axis |
| Picture Mode: Mode |
iEnhance, Vivid, Natural, Portrait, Muted, Monotone, Art Filter |
| Filter effect |
Yellow, Orange, Red or Green filter available for Monotone |
| Picture tone |
Sepia, Blue, Purple or Green tone available for Monotone |
| Gradation |
4 levels (Auto, High key, Normal, Low key) |
| Art Filter bracketing |
Yes |
| Noise Filter at High ISO setting |
OFF, LOW, STANDARD, HIGH |
| Noise Reduction at Slow shutter speed |
OFF, ON, AUTO |
| Shutter |
Computerized focal-plane shutter |
| Shutter speed |
60 - 1/4000 sec |
| Self-timer |
Operation time: 12 sec., 2 sec. (cancel available) |
| Remote cable release |
Available (Optional RM-UC1) |
| Drive mode |
Single-frame shooting, Sequential shooting, Self-timer |
| Sequential shooting speed |
Approx. 3 frames/sec. in sequential shooting |
| Built-in flash |
Yes |
| Compatible external flash |
E-system Flash(FL-50R, FL-36R, FL-50, FL-36, FL-20, FL-14, FL-300R) |
| External Flash control mode |
TTL Auto, Auto, Manual, FP-TTL-AUTO, FP-MANUAL |
| Flash intensity control |
Up to ±3 EV in 0.3, 0.5, 1 EV steps |
| Art Filter |
Pop Art, Soft Focus, Pale & Color, Light Tone, Grainy Film, Pin Hole, Diorama, Gentle Sepia, Cross Process, Dramatic Tone |
| Multi Exposure |
2 frames |
| Languages |
Japanese, English, French, German, Spanish, Italian, Japanese, Korean, Traditional Chinese, Simplified Chinese, Russian, Czech, Dutch, Danish, Polish, Portuguese, Swedish, Norwegian, Finnish, Croat, Slovenian, Hungarian, Greek, Slovakian, Turkish, Latvian, Estonian, Lithuanian, Ukrainian, Serbian, Bulgarian, Rumanian, Indonesian, Malay, Thai |
| Multi Aspect |
4:3(Default)/3:2/16:9/6:6/3:4 |
| Level Gauge |
Yes (H & V) |
| Image Editing (Erasing) |
Single frame, All, Selected frames(from Index) |
| Image Overlay |
Up to 3 RAW images |
| Input/Output: PC interface |
USB 2.0 High Speed for storage through Multi-connector(MTP mode is available) |
| TV interface |
HDMI (HD/Mono or Stereo Sound), VIDEO-OUT (SD/Mono Sound) |
| USB/Video connector |
Dedicated multi-connector (Video: NTSC/PAL selectable, Optional Remote cable RM-UC1, USB cable is available) |
| HDMI |
Mini HDMI type-C(1080i/720p/576p/480p) |
| Flash attachment |
Hot shoe |
| DC-in |
No |
| Power Requirements |
BLS-1 Li-ion battery |
| Sleep mode |
Yes (1, 3, 5 min., selectable) |
| Humidity |
30 - 90% (operation) / 10 - 90% (storage) |
| Dimensions |
4.8 x 2.7 x 1.4" / 12.2 x 6.9 x 3.5cm |
| Weight |
11.32 oz / 0.3kg (Body only) |
