| Lens Type |
Micro Four Thirds digital Lens |
| Memory |
SD/SDHC/SDXC/UHS-I Eye-Fi Class 6 recommended for Movie shooting |
| Lens Mount |
Micro Four Thirds |
| Effective Pixels |
12.3Mp |
| Screen Size |
3.0" (16 9) LCD, AR (anti-reflection) coating 0.7 x 0.5" / 17.3 x 13.0mm 460,000 pixels Playback field of view 100% Brightness control +7 levels and -7 levels Color temperature +7 levels and -7 levels |
| Live View |
Type Image Sensor (High Speed Live MOS) type Field of view 100% Display mode Normal mode; Grid Line mode (4 types); Histogram mode; Magnified View mode; Comparable View mode; Off mode Magnification ratio x5, x7, x10 (default), x14 |
| Magnification ratio |
x5, x7, x10 (default), x14 |
| Monitor information |
Aperture value, shutter speed, auto bracket, AE lock, AF mode, IS, shooting mode, battery check, myset, internal temperature warning, face/eye detection, histogram, number of storable still pictures, record mode, ISO, sequential shooting, self-timer, white balance, metering mode, AF confirmation mark, exposure compensation value, spot metering area, flash mode, flash status, flash intensity control, super FP, touch panel condition, focusing length, tone control, Eye-Fi condition |
| Face detection |
Max 8 frames |
| AF |
High speed imager AF |
| Sensor |
High Speed Live MOS sensor Total number of pixels: 13.1Mp Aspect ratio: 1 33 (4 3) Filter array: Primary color filter (RGB) Dust reduction: Supersonic Wave Filter |
| Aspect Ratio |
4:3(Default), 3:2, 16:9, 6:6, 3:4 Process: RAW: Aspect ratio is recorded as Exif data; JPEG: JPEG image is produced based on the aspect ratio |
| Recording Formats |
Still: DCF, DPOF compatible/Exif, PRINT Image Matching III Video: AVCHD, AVI Motion-JPEG Audio: AVHCD - Dolby Digital; Motion-JPEG format / Picture with Sound: Wave Format Base (Stereo PCM/16-bit, 48KHz) |
| File Format |
Still: RAW (12-bit lossless compression), JPEG, RAW+JPEG, MPO (3D) |
| Image Size |
Still: RAW: 4032 x 3024; JPEG: 4032 x 3024, 640 x 480 |
| File Size Recording(Still) |
RAW: 4032 (H) x 3024 (V) (approx. 1/1.5 lossless compressed) approx. 13.9MB Set 1 (LF): 4032 (H) x 3024 (V) (1/4 compressed) approx. 5.9MB Set 2 (LN): 4032 (H) x 3024 (V) (1/8 compressed) approx. 2.7MB Set 3 (MN): 2560 (H) x 1920 (V) (1/8 compressed) approx. 1.1MB Set 4 (SN): 1024 (H) x 768 (V) (1/8 compressed) approx. 0.3MB |
| AVCHD Format |
Full HD Fine: 1920 (H) x 1080 (V), 60i recording, 20Mbps, aspect 16:9 Full HD Normal: 1920 (H) x 1080 (V), 60i recording, 17Mbps, aspect 16:9 HD Fine: 1280 (H) x 720 (V), 60p recording), 17Mbps, aspect 16:9 HD Normal: 1280 (H) x 720 (V), 60p recording, 13Mbps, aspect 16:9 Frame rate of image sensor output is 30fps |
| Motion-JPEG Format |
HD: 1280 (H) x 720 (V), 30fps (some art filters are excepted), aspect 16:9 SD: 640 (H) x 480 (V), 30fps (some art filters are excepted), aspect 4:3 (VGA) |
| Compression Ratio |
Motion-JPEG format: 1/12 (HD), 1/8 (SD) |
| File Size Recording(Movie) |
Video: AVCHD: 4GB max; Motion-JPEG: 2GB max |
| Maximum Recording Time |
Picture with Sound: 30 seconds Movie: 29 minutes Full HD Normal, HD Fine, HD Normal: 29 minutes; Full HD Fine: 22 minutes; Motion-JPEG: HD: 7 minutes, SD: 14 minutes |
| Audio |
Mic/speaker: stereo/mono |
| Image Stabilizer System |
Built-in (imager shift image stabilizer) |
| Image Stabilizer Mode |
3 modes (IS1:2 dimensional activation, IS2:1 dimensional activation in landscape frame to vertical direction moving, IS3:1 dimensional activation in portrait frame to vertical direction moving ), OFF |
| Manual function |
Input focal length 8, 10, 12, 16, 18, 24, 28, 30, 35, 40, 48, 50, 55, 65, 70, 75, 80, 85, 90, 100, 105, 120, 135, 150, 180, 200, 210, 250, 300, 350, 400, 500, 600, 800, 1000 |
| Shutter speed range |
2 - 1/4000 seconds (Not available in bulb) IS for movie Shifting electronic image (Digital IS, IS1 modes) |
| AF system |
Imager Contrast Detection AF system (with AF compatible lens) |
| Focus mode |
Single AF (S-AF); Continuous AF (C-AF); Manual Focus (MF); S-AF + MF; AF tracking (C-AF + TR); C-AF and AF tracking are not available with non-Micro Four Thirds lenses |
| Advance AF |
Available |
| Focusing point |
35-area multiple AF with the contrast detection system (Auto, selectable in option) |
| Focusing point selection |
Auto from 35-areas; 9 Group Target areas; Auto when face detection is on; Free selection when Magnified View Mode is selected |
| Illuminator |
Available |
| AF lock |
Locked at first position of shutter button in Single AF mode |
| Focus tracking |
Available |
| Magnified Spot AF |
Available |
| Face priority AF/Eye Detect AF |
Available; Eye Detect AF Off; Near side eye priority mode; Right side eye priority mode; Left side eye priority mode |
| Manual focus assist |
When rotation of focus ring is detected under S-AF+MF or MF mode, LV is magnified automatically |
| Metering system |
TTL Image Sensor metering system (1) Digital ESP metering (324-area multi pattern metering) (2) Center weighted average metering (3) Spot metering (approx. 1% for the viewfinder screen. Highlight / shadow bases are available) |
| Metering range |
EV 0-20 (Digital ESP metering, center weighted average metering, spot metering, at normal temperature, 17mm f2.8, ISO 100) |
| Exposure mode |
(1) iAuto; (2) P: Program AE (Program shift can be performed); (3) A: Aperture priority AE; (4) S: Shutter priority AE; (5) M: Manual; (6) Scene select AE; (7) Art Filter; (8) Underwater wide / Underwater macro (Selectable from menu as a function on Rec/Fn button) |
| Scene select AE |
Portrait, ePortrait, Landscape, Landscape + Portrait, Macro, Sport, Night Scene, Night + Portrait, Children, High Key, Low Key, DIS mode, Nature Macro, Candle, Sunset, Document, Panorama, Fireworks, Beach & Snow, Fisheye Conv, Wide Conv, Macro Conv, 3D |
| ISO sensitivity |
AUTO: ISO 200-12800 (customizable, Default 200-1600) / Manual ISO 200-12800, 1/3 or 1 EV steps |
| Exposure compensation |
-/+ 3 EV in 1/3, 1/2, 1 EV steps selectable |
| Exposure bracketing |
2, 3, 5 frames in 0.3, 0.5, 0.7, 1 EV steps selectable, 7 frames in 0.3, 0.5, 0.7 EV steps selectable |
| Metering standard value adjustment |
1/6 EV step, +/- 1 EV range |
| White Balance: Auto WB system |
High Speed Live MOS sensor |
| White Balance: Preset white balance |
7 settings (3000K - 7500K), Lamp (3000K), Fluorescent (4000K), Daylight (5300K), Flash (5500K), Cloudy (6000K), Shade (7500K), Underwater WB |
| White Balance compensation |
-/+7 steps in each A-B/G-M axis (in Auto WB/Preset WB mode/One touch WB) |
| White Balance: CWB (Kelvin setting) |
1 setting can be registered at Kelvin temperature (2000-1400K) |
| White Balance: One-touch balance |
2 custom settings can be registered |
| White Balance: bracketing |
3 frames in 2, 4, 6 steps selectable in each A-B/G-M axis |
| Color Modes |
Color space: sRGB, Adobe RGB |
| Picture Modes |
iEnhance, Vivid, Natural, Portrait, Muted, Monotone, Art Filter |
| Adjustment parameter |
Contrast, Sharpness and Saturation level available in 5 steps for iEnhance, Vivid, Natural, Portrait and Muted, Contrast and Sharpness level available in 5 steps for Monotone, 3 effect levels are available in i-Enhance |
| Filter effect |
Yellow, orange, red, green filter available for Monotone |
| Picture tone |
Sepia, Blue, Purple, or Green tone available for Monotone |
| Gradation |
4 levels (Auto, High key, Normal, Low key) |
| Art filter bracketing |
Available |
| Noise |
Noise filter: At high ISO setting: Off, Low, Standard, High; At slow shutter speed: Off, On, Auto, On (effective when shutter speed is slower than 1 seconds); Auto (effective when shutter speed is slower than 4 seconds [at ISO 200 or higher] or 8 seconds [at lower than ISO 200]) |
| Shutter Type |
Computerized focal-plane shutter |
| Shutter speed |
60-1/4000 seconds; Bulb: Up to 30 minutes (selectable longest time in the menu, Default: 8 minutes) |
| Self-timer |
Operation time: 12 seconds, 2 seconds (cancel available) |
| Drive |
Drive mode Single-frame shooting, sequential shooting, self-timer Sequential shooting speed 4.1fps in sequential shooting (5.5fps in case of "I.S. Off") |
| Flash |
External flash Guide number: 10 (Fno/m) at ISO 200, 7 (Fno/m) at ISO 100 but ISO 100 is not available Mode: TTL-Auto, Manual (Full, 1/2, 1/4, 1/8, 1/16, 1/32, 1/64) Color temperature: 5500+/-400deg. K Wireless flash control: Available(4 channels, 4 groups) Compatible external flash: E-System Flash (FL-50R, FL-36R, FL-50, FL-36, FL-20, FL-14, FL-300R) |
| External flash control mode |
TTL Auto, Auto, Manual, FP-TTL-Auto, FP-Manual Flash mode of external flash Auto, red-eye reduction, red-eye reduction slow sync., slow sync at 1st curtain, slowsync at 2nd curtain, fill-in, off Synchronization speed 1/60-1/160; Super FP 1/125-1/4000 with external flash Flash intensity control Up to +/- 3 EV in 0.3, 0.5, 1 EV steps |
| Filter |
Mode: Pop Art, Soft Focus, Grainy Film, Pin Hole, Diorama, Dramatic Tone Variation/Effect: Available |
| Multi Exposure |
Number of pictures: 2 frames Functions: Auto gain, Live View, Exposing on Recorded picture |
| Playback |
Playback mode: Single-frame; Information display; Index display (4/9/25/100 frames, calendar); Close-up (2-14x); Movie (with sound, FF/REW/Pause); Picture rotation (manual); Slideshow (still, movie, still+movie, slide show with BGM, BGM+sound, sound); When camera is connected to HDTV with HDMI cable, 2 new slideshow effect can be selectable (still) Information display: Histogram (independent luminance/RGB available); highlight/shadow point warning, AF frame, shooting information |
| Menu Language |
Japanese, English, French, German, Spanish, Italian, Japanese, Korean, Traditional Chinese, Simplified Chinese, Russian, Czech, Dutch, Danish, Polish, Portuguese, Swedish, Norwegian, Finnish, Croat, Slovenian, Hungarian, Greek, Slovakian, Turkish, Latvian, Estonian, Lithuanian, Ukrainian, Serbian, Bulgarian, Rumanian, Indonesian, Malay, Thai |
| Editing |
Erasing function: Single frame, All, Selected frames (from index) Protect function: Single frame, Selected frames, All frames, Release protect (Single, All) RAW picture editing: RAW development based on settings of the camera (including Art filter) JPEG editing: Shadow adjustment, Red-eye fix, Cropping, Aspect, Monotone, Sepia, Saturation (color depth), Resize (producing another file, 1280 x 960, 640 x 480, 320 x 240), ePortrait |
| Connections |
USB 2.0 (for storage through multi-connector) HDMI mini type C Hot shoe Accessory port (AP2) |
| Power Requirements |
Battery: BLS-1 lithium-ion battery Sleep mode: 1, 3, 5 minutes, selectable Number of recordable pictures: 300 shots (CIPA test standard) With 50% flash light: With BLS-1 and Toshiba Class 6 SDHC 4GB card under CIPA test standard |
| Environmental |
Temperature: Operating: 0 to 40deg. F / -18 to 4.4deg. C; Storage: -20 to 60deg. F / -29 to 16deg. C Humidity: Operation: 30 to 90%; Storage: 10 to 90% |
| Construction |
Metal |
| Dimensions |
4.31 x 2.5 x 1.5" / 11.0 x 6.4 x 3.8cm |
| Weight |
Body: 7.65 oz / 0.2kg Battery and memory card: 9.34 oz / 0.3kg |
