Item Includes
Olympus E-PM1 Digital Camera - M.Zuiko MSC ED m14-42mm F3.5/5.6 II R Micro 4/3 Zoom (Silver) - USB/Video Multi Cable - BLS-1 Lithium-Ion Battery - Olympus FL-LM1 Flash - Lithium-Ion Battery Charger - Shoulder Strap - Olympus Viewer 2/ib Software CD-ROM - Instruction Manual - Warranty Card - Olympus Warranty
|
Description
The Olympus E-PM1 Digital Camera with 14-42mm Lens (Black) starts you out with everything you need to take great photographs, from day one. As the name states, you'll receive both the E-PM1 camera body and the Micro Four Thirds M.Zuiko MSC Digital ED m14-42mm zoom lens (black lens). In addition, a number of essential accessories come included as well, such as a lithium-ion battery and battery charger.
Whether you're simply looking to lighten your load when it comes to photographing or you're an avid fan of the Micro Four Thirds genre, Olympus's PEN series of cameras provide you with a more lightweight option than full-sized DSLR rigs, but with numerous bells and whistles that still provide flexibility and creativity, far beyond that of a point-and-shot. With the Micro Four Thirds lens mount, you can choose from a number of optional lenses for the E-PM1 to suit your particular shooting style.
At the center of the image making is the generous 3.0" LCD. Used for composition and review of your footage, not to mention navigating the menu and for features such as Live View, this big, bright display features 460K pixels and the platform with which to compose your next great shot or epic short film. Of course, the 12.3Mp sensor and the TruePic VI image processor are the heart of the camera, taking what you see on the LCD screen and turning it into memories that will last a lifetime.
In addition to shooting JPEG and RAW stills, along with 3D stills in the MPO format, the E-PM1 also shoots the already mentioned 1080/60i HD video. Up to 29 minutes of continuous footage can be captured with stereo sound. Video clips can be shot in AVCHD or AVI formats and the Direct HD Movie Button on the camera switches you from still to movie mode with just a touch.
The E-PM1 also boasts stunning low light performance with the Olympus AF Illuminator - an LED beam up to 10 feet for faster focusing in dark settings. The camera also features and ISO up to 12,800 and the ability to attach an external flash. Other noteworthy features include the FAST AF System which provides up to 35-points of focus for unbelievable accuracy, 5 frames per second shooting, multiple filter options and much more. |
Features
 |
Never Miss a Moment with the Small and Stylish Pen: The smallest and lightest PEN is available in six stylish colors - purple, pink, brown, white, silver and black - and features a new and simplified user interface as well as a streamlined button structure for superior ease-of-use |
|
Simplified Control: Operating the camera is more intuitive with the newly designed user interface. The innovative screen activates popular menu options such as Art Filters, iAuto, Scene Modes and Movie |
|
Excellent Shots - Effortlessly: The E-PM1 is also equipped with 23 Scene-Select modes for effortless picture taking, including new 3D mode, Fireworks, Sunset, Children, Macro and Panorama, to name a few. There are even 3 scene modes that are specific to shooting with Olympus' conversion lenses |
|
Three Inch, Bright Widescreen LCD: This 460 dot high-resolution screen is big and bright enough to let you shoot and share photos and HD video with ease |
|
Get Wireless: No need for cables or even a computer. Upload or email images directly from your camera with an optional PP-1 PENPAL or Eye-Fi card. The E-PM1 is also capable of recording stills and video to SD, SDHC, SDXC and UHS-I media cards |
|
12.3Mp: The new 12.3Mp sensor is optimized to maximize the performance of all mZuiko digital lenses in any shooting condition. Improvements in the sensor makes shooting in low light and Full HD movie recording possible |
|
Advanced Shadow Adjustment Technology: You no longer need to worry about the extreme contrast between dark and bright areas in your images |
|
Face Detection with Eye Detect: Nail the focus for every portrait photo, every time. The new face detection AF employs an "Eye Detect AF" that adjusts focus automatically on the subject's eyes during portrait shooting and can even be adjusted to focus on the right, left or near-side eye |
|
Full 1080 HD Video: Shoot up to 29 minutes of 1080 60i HD video and stereo sound in either AVCHD or AVI formats. A Direct HD Movie Button switches you from still to movie mode with just the press of a button |
|
In-Camera Art Filters: Six in-camera Art Filters (Pop Art, Soft Focus, Grainy Film, Pin Hole, Diorama and Dramatic Tone) can be used in all shooting modes as well as filming HD movies. The E-PM1 also includes bracketing up to seven images, each image with a different applied Art Filter |
|
Wide Variety of Lenses and Accessories: A range of interchangeable lenses, accessories and flashes are compatible with the E-PM1 to support all different types of photography needs |
|
New 3D Shooting: Add a new dimension to your photographs in any mode from macro to landscape with Olympus' 3D technology. By simply selecting the 3D Photo Mode, releasing the shutter and slowly panning, the camera will automatically take a second image from a slightly different perspective |
|
AF Illuminator: The addition of this super luminosity LED beam allows the camera to focus faster in low light up to almost 10 feet |
|
Increased ISO Sensitivity: Stunning low light photos are a click away with an increased ISO sensitivity to 12,800 |
|
Attachable Flash Included: This camera provides the flexibility to attach a flash to your camera via the accessory port, or leave it at home for maximum portability |
|
5 FPS Sequential Shooting: With the E-PM1 you can take up to five photos a second, allowing you to easily capture that perfect shot, especially when your subject is moving |
|
World's Fastest Auto Focus: The new FAST AF System is able to focus at an incredible speed and offers 35 separate focus points that are spread over nearly the entire sensor, which makes it possible for pin-point accurate focusing on small subjects wherever they appear in the frame |
|
Improved Color Reproduction: The new TruePic VI Image Processor, designed specifically for the Olympus PEN, features Real Color Technology for improved color reproduction (especially colors such as emerald green, yellow and gold) and color gradation |
|
Improved Lens Technology: High-precision engineering and an improved internal focusing mechanism have allowed the Olympus MSC (Movie+Still Compatible) lenses to auto focus quickly, smoothly and silently, perfect for stills and movies |
|
Fast Shutter Response: Never miss a shot again with the E-PM1's fast shutter response time of less than 60 milliseconds (60 - 1/40000 sec.). The TruePic VI feature allows for reduced shot-to-shot time by shortening the black-out time between shots |
|
Accessory Port: The E-PM1 incorporates a port for connecting accessories including flashes, MAL-1 Macro Light, EMA-1 Microphone adapter, PENPAL and the VF-2 viewfinder |
|
In-Camera Slideshow with Sound: Slideshows have never been easier or more fun to create. The E-PM1's enhanced playback functions allow you to employ effective fade-in/fade-out techniques, control the movie/still mix and speed, add captivating musical soundtracks and much more |
|
Professional Audio Sound Capture: Take videos that are able to capture uncompressed CD-quality 16-bit/44.1KHz Linear PCM stereo recording or AC3 Dolby Digital audio |
|
Easy Photo and Video Playback on Your HDTV: The E-PM1 makes sharing your content easier than ever. Using the HDMI output, just connect the E-PM1 to your HDTV with an HDMI cable (not included) and navigate the camera's menus from the comfort of your couch |
|
Multiple Exposure Shooting: A Multiple Exposure function enables you to be creative right in the camera. Multiple images can be captured and combined to create one unique image. The creative possibilities are endless |
Specifications
| Lens Type | Micro Four Thirds digital Lens |
| Memory | SD/SDHC/SDXC/UHS-I
Eye-Fi Class 6 recommended for Movie shooting |
| Lens Mount | Micro Four Thirds |
| Effective Pixels | 12.3Mp |
| Screen Size | 3.0" (16 9) LCD, AR (anti-reflection) coating
0.7 x 0.5" / 17.3 x 13.0mm
460,000 pixels
Playback field of view 100%
Brightness control +7 levels and -7 levels
Color temperature +7 levels and -7 levels |
| Live View | Type Image Sensor (High Speed Live MOS) type
Field of view 100%
Display mode Normal mode; Grid Line mode (4 types); Histogram mode; Magnified View mode; Comparable View
mode; Off mode
Magnification ratio x5, x7, x10 (default), x14 |
| Magnification ratio | x5, x7, x10 (default), x14 |
| Monitor information | Aperture value, shutter speed, auto bracket, AE lock, AF mode, IS, shooting mode, battery check, myset, internal temperature warning, face/eye detection, histogram, number of storable still pictures, record mode, ISO, sequential shooting, self-timer, white balance, metering mode, AF confirmation mark, exposure compensation value, spot metering area, flash mode, flash status, flash intensity control, super FP, touch panel condition, focusing length, tone control, Eye-Fi condition |
| Face detection | Max 8 frames |
| AF | High speed imager AF |
| Sensor | High Speed Live MOS sensor
Total number of pixels: 13.1Mp
Aspect ratio: 1 33 (4 3)
Filter array: Primary color filter (RGB)
Dust reduction: Supersonic Wave Filter |
| Aspect Ratio | 4:3(Default), 3:2, 16:9, 6:6, 3:4
Process: RAW: Aspect ratio is recorded as Exif data; JPEG: JPEG image is produced based on the aspect ratio |
| Recording Formats | Still: DCF, DPOF compatible/Exif, PRINT Image Matching III
Video: AVCHD, AVI Motion-JPEG
Audio: AVHCD - Dolby Digital; Motion-JPEG format / Picture with Sound: Wave Format Base (Stereo PCM/16-bit, 48KHz) |
| File Format | Still: RAW (12-bit lossless compression), JPEG, RAW+JPEG, MPO (3D) |
| Image Size | Still: RAW: 4032 x 3024; JPEG: 4032 x 3024, 640 x 480 |
| File Size Recording(Still) | RAW: 4032 (H) x 3024 (V) (approx. 1/1.5 lossless compressed) approx. 13.9MB
Set 1 (LF): 4032 (H) x 3024 (V) (1/4 compressed) approx. 5.9MB
Set 2 (LN): 4032 (H) x 3024 (V) (1/8 compressed) approx. 2.7MB
Set 3 (MN): 2560 (H) x 1920 (V) (1/8 compressed) approx. 1.1MB
Set 4 (SN): 1024 (H) x 768 (V) (1/8 compressed) approx. 0.3MB |
| AVCHD Format | Full HD Fine: 1920 (H) x 1080 (V), 60i recording, 20Mbps, aspect 16:9
Full HD Normal: 1920 (H) x 1080 (V), 60i recording, 17Mbps, aspect 16:9
HD Fine: 1280 (H) x 720 (V), 60p recording), 17Mbps, aspect 16:9
HD Normal: 1280 (H) x 720 (V), 60p recording, 13Mbps, aspect 16:9
Frame rate of image sensor output is 30fps |
| Motion-JPEG Format | HD: 1280 (H) x 720 (V), 30fps (some art filters are excepted), aspect 16:9 SD: 640 (H) x 480 (V), 30fps (some art filters are excepted), aspect 4:3 (VGA) |
| Compression Ratio | Motion-JPEG format: 1/12 (HD), 1/8 (SD) |
| File Size Recording(Movie) | Video: AVCHD: 4GB max; Motion-JPEG: 2GB max |
| Maximum Recording Time | Picture with Sound: 30 seconds
Movie: 29 minutes Full HD Normal, HD Fine, HD Normal: 29 minutes; Full HD Fine: 22 minutes; Motion-JPEG: HD: 7 minutes, SD: 14 minutes |
| Audio | Mic/speaker: stereo/mono |
| Image Stabilizer System | Built-in (imager shift image stabilizer) |
| Image Stabilizer Mode | 3 modes (IS1:2 dimensional activation, IS2:1 dimensional activation in landscape frame to vertical direction moving, IS3:1 dimensional activation in portrait frame to vertical direction moving ), OFF |
| Manual function | Input focal length 8, 10, 12, 16, 18, 24, 28, 30, 35, 40, 48, 50, 55, 65, 70, 75, 80, 85, 90, 100, 105, 120, 135, 150, 180, 200, 210, 250, 300, 350, 400, 500, 600, 800, 1000 |
| Shutter speed range | 2 - 1/4000 seconds (Not available in bulb)
IS for movie Shifting electronic image (Digital IS, IS1 modes) |
| AF system | Imager Contrast Detection AF system (with AF compatible lens) |
| Focus mode | Single AF (S-AF); Continuous AF (C-AF); Manual Focus (MF); S-AF + MF; AF tracking (C-AF + TR); C-AF and AF tracking are not available with non-Micro Four Thirds lenses |
| Advance AF | Available |
| Focusing point | 35-area multiple AF with the contrast detection system (Auto, selectable in option) |
| Focusing point selection | Auto from 35-areas; 9 Group Target areas; Auto when face detection is on; Free selection when Magnified View Mode is selected |
| Illuminator | Available |
| AF lock | Locked at first position of shutter button in Single AF mode |
| Focus tracking | Available |
| Magnified Spot AF | Available |
| Face priority AF/Eye Detect AF | Available; Eye Detect AF Off; Near side eye priority mode; Right side eye priority mode; Left side eye priority mode |
| Manual focus assist | When rotation of focus ring is detected under S-AF+MF or MF mode, LV is magnified automatically |
| Metering system | TTL Image Sensor metering system (1) Digital ESP metering (324-area multi pattern metering)
(2) Center weighted average metering
(3) Spot metering (approx. 1% for the viewfinder screen. Highlight / shadow bases are available) |
| Metering range | EV 0-20 (Digital ESP metering, center weighted average metering, spot metering, at normal temperature, 17mm f2.8, ISO 100) |
| Exposure mode | (1) iAuto; (2) P: Program AE (Program shift can be performed); (3) A: Aperture priority AE; (4) S: Shutter priority AE; (5) M: Manual; (6) Scene select AE; (7) Art Filter; (8) Underwater wide / Underwater macro (Selectable from menu as a function on Rec/Fn button) |
| Scene select AE | Portrait, ePortrait, Landscape, Landscape + Portrait, Macro, Sport, Night Scene, Night + Portrait, Children, High Key, Low Key, DIS mode, Nature Macro, Candle, Sunset, Document, Panorama, Fireworks, Beach & Snow, Fisheye Conv, Wide Conv, Macro Conv, 3D |
| ISO sensitivity | AUTO: ISO 200-12800 (customizable, Default 200-1600) / Manual ISO 200-12800, 1/3 or 1 EV steps |
| Exposure compensation | -/+ 3 EV in 1/3, 1/2, 1 EV steps selectable |
| Exposure bracketing | 2, 3, 5 frames in 0.3, 0.5, 0.7, 1 EV steps selectable, 7 frames in 0.3, 0.5, 0.7 EV steps selectable |
| Metering standard value adjustment | 1/6 EV step, +/- 1 EV range |
| White Balance: Auto WB system | High Speed Live MOS sensor |
| White Balance: Preset white balance | 7 settings (3000K - 7500K), Lamp (3000K), Fluorescent (4000K), Daylight (5300K), Flash (5500K), Cloudy (6000K), Shade (7500K), Underwater WB |
| White Balance compensation | -/+7 steps in each A-B/G-M axis (in Auto WB/Preset WB mode/One touch WB) |
| White Balance: CWB (Kelvin setting) | 1 setting can be registered at Kelvin temperature (2000-1400K) |
| White Balance: One-touch balance | 2 custom settings can be registered |
| White Balance: bracketing | 3 frames in 2, 4, 6 steps selectable in each A-B/G-M axis |
| Color Modes | Color space: sRGB, Adobe RGB |
| Picture Modes | iEnhance, Vivid, Natural, Portrait, Muted, Monotone, Art Filter |
| Adjustment parameter | Contrast, Sharpness and Saturation level available in 5 steps for iEnhance, Vivid, Natural, Portrait and Muted, Contrast and Sharpness level available in 5 steps for Monotone, 3 effect levels are available in i-Enhance |
| Filter effect | Yellow, orange, red, green filter available for Monotone |
| Picture tone | Sepia, Blue, Purple, or Green tone available for Monotone |
| Gradation | 4 levels (Auto, High key, Normal, Low key) |
| Art filter bracketing | Available |
| Noise | Noise filter: At high ISO setting: Off, Low, Standard, High; At slow shutter speed: Off, On, Auto, On (effective when shutter speed is slower than 1 seconds); Auto (effective when shutter speed is slower than 4 seconds [at ISO 200 or higher] or 8 seconds [at lower than ISO 200]) |
| Shutter Type | Computerized focal-plane shutter |
| Shutter speed | 60-1/4000 seconds; Bulb: Up to 30 minutes (selectable longest time in the menu, Default: 8 minutes) |
| Self-timer | Operation time: 12 seconds, 2 seconds (cancel available) |
| Drive | Drive mode Single-frame shooting, sequential shooting, self-timer
Sequential shooting speed 4.1fps in sequential shooting (5.5fps in case of "I.S. Off") |
| Flash | External flash
Guide number: 10 (Fno/m) at ISO 200, 7 (Fno/m) at ISO 100 but ISO 100 is not available
Mode: TTL-Auto, Manual (Full, 1/2, 1/4, 1/8, 1/16, 1/32, 1/64)
Color temperature: 5500+/-400deg. K
Wireless flash control: Available(4 channels, 4 groups)
Compatible external flash: E-System Flash (FL-50R, FL-36R, FL-50, FL-36, FL-20, FL-14, FL-300R) |
| External flash control mode | TTL Auto, Auto, Manual, FP-TTL-Auto, FP-Manual
Flash mode of external flash Auto, red-eye reduction, red-eye reduction slow sync., slow sync at 1st curtain, slowsync
at 2nd curtain, fill-in, off
Synchronization speed 1/60-1/160; Super FP 1/125-1/4000 with external flash
Flash intensity control Up to +/- 3 EV in 0.3, 0.5, 1 EV steps |
| Filter | Mode: Pop Art, Soft Focus, Grainy Film, Pin Hole, Diorama, Dramatic Tone
Variation/Effect: Available |
| Multi Exposure | Number of pictures: 2 frames
Functions: Auto gain, Live View, Exposing on Recorded picture |
| Playback | Playback mode: Single-frame; Information display; Index display (4/9/25/100 frames, calendar); Close-up (2-14x); Movie (with sound, FF/REW/Pause); Picture rotation (manual); Slideshow (still, movie, still+movie, slide show with BGM, BGM+sound, sound); When camera is connected to HDTV with HDMI cable, 2 new slideshow effect can be selectable (still)
Information display: Histogram (independent luminance/RGB available); highlight/shadow point warning, AF frame, shooting information |
| Menu Language | Japanese, English, French, German, Spanish, Italian, Japanese, Korean, Traditional Chinese, Simplified Chinese, Russian, Czech, Dutch, Danish, Polish, Portuguese, Swedish, Norwegian, Finnish, Croat, Slovenian, Hungarian, Greek, Slovakian, Turkish, Latvian, Estonian, Lithuanian, Ukrainian, Serbian, Bulgarian, Rumanian, Indonesian, Malay, Thai |
| Editing | Erasing function: Single frame, All, Selected frames (from index)
Protect function: Single frame, Selected frames, All frames, Release protect (Single, All)
RAW picture editing: RAW development based on settings of the camera (including Art filter)
JPEG editing: Shadow adjustment, Red-eye fix, Cropping, Aspect, Monotone, Sepia, Saturation (color depth), Resize (producing another file, 1280 x 960, 640 x 480, 320 x 240), ePortrait |
| Connections | USB 2.0 (for storage through multi-connector)
HDMI mini type C
Hot shoe
Accessory port (AP2) |
| Power Requirements | Battery: BLS-1 lithium-ion battery
Sleep mode: 1, 3, 5 minutes, selectable
Number of recordable pictures: 300 shots (CIPA test standard)
With 50% flash light: With BLS-1 and Toshiba Class 6 SDHC 4GB card under CIPA test standard |
| Environmental | Temperature: Operating: 0 to 40deg. F / -18 to 4.4deg. C; Storage: -20 to 60deg. F / -29 to 16deg. C
Humidity: Operation: 30 to 90%; Storage: 10 to 90% |
| Construction | Metal |
| Dimensions | 4.31 x 2.5 x 1.5" / 11.0 x 6.4 x 3.8cm |
| Weight | Body: 7.65 oz / 0.2kg
Battery and memory card: 9.34 oz / 0.3kg |
| | |
|
