| Image Sensor |
1/2.3" CMOS Sensor |
| Pixels number |
12 million pixels / Approx. 12.76 million pixels / 1.33 (4:3) - (Effective Pixels number, Total no. of pixel)/Total no. of pixels/Aspect ratio |
| Screen size (HxV) |
6.150x4.612mm / 0.24x0.18" |
| Filter array |
Primary color filter (RGB) |
| Lens Structure |
10 elements in 8groups |
| Aspheric Surfaces |
6 |
| Focal length (35mm equivalent) |
4.7-23.5mm (26mm to 130mm) |
| Maximum aperture |
1.8-2.7 |
| Optical zoom |
5x |
| Super Resolution Zoom |
2x |
| Imaging range |
W:10cm to infinity,T:30cm to infinity Super Macro:1cm to 60cm,Wide-angle edge fixing |
| Recording format (Still) |
DCF, DPOF compatible/Exif, PRINT Image Matching III |
| File format (Still) |
RAW (12-bit lossless compression), JPEG, RAW+JPEG |
| Recording image size (Still) |
[RAW] 3968 x 2976 pixels [JPEG] 3968 x 2976 pixels - 640 x 480 pixels |
| File Size (Still) |
RAW: 4032(H)x3024(V) (approx. 1/1.5 lossless compressed) Approx. 13.9MB Set1(LF): 4032(H)x3024(V) (1/4 compressed) Approx. 5.9MB Set2(LN): 4032(H)x3024(V) (1/8 compressed) Approx. 2.7MB Set3(MN): 2560(H)x1920(V) (1/8 compressed) Approx. 1.1MB Set4(SN): 10 |
| Image stabilizer System |
Built in (Imager shift image stabilizer) |
| Image stabilizer mode |
1 modes (IS:2 dimensional activation ), OFF |
| Live View display modes |
Image Exposure Level, WB, Shadow adjustment and face detect Grid Line Mode, Histogram Mode, Magnified View Mode, OFF Mode |
| Field of view |
100% |
| Display Mode |
Normal Mode, Grid Line Mode(4 types), Histogram Mode, Off |
| Monitor information |
Aperture value, Shutter speed, Auto Bracket, AE Lock, AF mode, IS, Shooting Mode, Battery Check, Internal Temperature Warning, Face Detection, Histogram, Number of storable still pictures, Record mode, ISO, Sequential shooting, Self-timer, White Balance, AF confirmation mark, Exposure Compensation Value, Spot metering Area Flash Mode, Flash Status, Flash intensity Control, Super FP, Focal length, Tone control, Eye-Fi condition, Super-ResZOOM, Battery check |
| Display of Face Detection |
Max 8 frames of face detection can be displayed |
| Monitor type |
3" Touch control with 920K dots |
| Touch function |
Touch shutter release, Touch Live Guide, AF area selection, Frame advance/backward, Enlargement playback, PhotoSession |
| Brightness control/Color temperature |
±2 levels / ±7 levels |
| Color setting |
Vivid / Natural |
| Focusing AF |
Imager AF |
| Focus mode |
Single AF (S-AF) / SuperMacro Mode |
| Advance AF |
Only movie mode is available |
| Face priority AF |
Available |
| Focusing point/Focusing point selection |
35-area multiple AF / All target, Single target |
| AF illuminator |
Yes |
| Exposure Control: Metering system |
Digital ESP metering, Center weighted average metering, Spot metering |
| Target frame linkage light measurement |
Available |
| Metering |
EV -3 - 17 (Digital ESP metering, Centre weighted average metering, Spot metering) |
| Exposure mode |
(1) i Auto (2) P: Programmed AE (3) A: Aperture priority AE (4) S: Shutter priority AE (5) M: Manual (6)Photo Story (7)Scene select AE (8) Art Filter |
| Scene select AE |
Portrait, e-Portrait, Landscape, Sport, Hand-HeldStarlight, Night, Night + Portrait, Sunset, documents, Panorama, Fireworks, Multiplex exposure, Beach & Snow, HDR |
| ISO sensitivity |
AUTO ISO 100 - 6400 (customizable, Default 100-1600) Manual ISO 100 - 6400, 1/3 EV steps |
| Exposure Compensation |
±3 EV in 1/3 EV steps |
| AE lock |
Locked at 1st release of shutter button (can be set to Fn1) |
| Shutter Type |
Lens shutter |
| Shutter speed |
1/2000 - 30 sec |
| Flash intensity control method |
TTL Auto, Auto, Manual |
| Built-in flash |
Available |
| Flash Mode |
Auto, Red-eye reduction, Fill-in, Off, Red-eye reduction slow sync., Slow sync, Full,1/2, 1/4, 1/8, 1/16, 1/32, 1/64 |
| Flash intensity control |
Up to ±3 EV in 0.3 EV step |
| Color Temperature |
5500±400deg.K |
| Compatible external flash |
FL-50R, FL-36R, FL-300R, FL600R |
| Control type |
Built-in flash |
| External Flash intensity type |
TTL Auto |
| Channel No. |
1ch |
| Group No |
1ch, 1Groups (External flash: 1group ) |
| Drive mode |
Single-frame shooting, Sequential shooting, High-speed shooting, BKT, Self-timer |
| Sequential shooting maximum speed |
5fps (Sequential shooting), 15fps (High-speed shooting) |
| Max. recordable pictures |
200shots (on sequential shooting) |
| Self-timer |
Operation time: 12 sec., 2 sec. (cancel available) |
| Exposure bracketing |
3 frames in 0.3/0.7/1.0EV steps selectable |
| Art Filter Mode |
Pop Art (I, II / a.b.c.d.e.) Soft Focus ( - / c.e.) Pale & Light Color (I, II / a.b.c.d.) Light Tone ( - / d.) Grainy Film (I, II / b.c.d.) Pin Hole (I, II, III / d.) Diorama ( - / d.) Cross Process (I, II / b.c.d.) Gentle Sepia ( - / a.b.c.d.) Dramatic Tone (I, II / b.c.d.e.) Key Line (I, II / a.b.c.d.e.) |
| Art Effect |
a. Soft Focus Effect b. Pin-Hole Effect c. White Edge Effect d. Frame Effect e. Star Light Effect |
| Photo Session |
Standard (Type I, II, III, IV) Speed (2 Pics, 4 Pics, 5 Pics) Zoom In/Out (Type I, II) Fun Frame (Instant, Film, Square) |
| Movie Recording format |
MOV(MPEG-4AVC/H.264) |
| Movie Mode |
Full HD: 1920(H)x1080(V), 30p(29.97fps)Recording 18Mbps, Aspect 16:9 HD: 1280(H)x720(V), 30p(29.97fps)Recording 9Mbps, Aspect 16:9 HS: 120fps/720p/24Mbps/20 HS: 240fps/432x324/16Mbps/20 |
| Movie Maximum Recording Time |
Full HD:29min, HD:29min |
| IS for Movie |
OK/Shifting electronic image (so called Digital IS, IS1 mode only) |
| AE Lock |
Available |
| Exposure Control(Movie) |
(1) i Auto (2) P: Programmed AE (3) A: Aperture priority AE (4) S: Shutter priority AE (5) M: Manual (6) C1: Custom1 AE 8) SCN: SCN AE (9) Art Filter: ART Filtr AE S mode and M mode: Shutter speed is limited in less than 1/30 sec. C1/ C2: Registered Mode is followed. |
| Movie File Size |
MOV Format: Max 4GB |
| Recording(Sound) format |
Wave Format (Stereo linear PCM/16-bit, Sampling frequency 48kHz) |
| Mic/Speaker |
Stereo/Mono |
| Mic function |
Wind Noise Reduction, Audio dubbing possible for still pictures (up to 30 sec.) |
| Sound: Maximum Recording Time |
Picture with Sound: 4sec. Movie: depend on Movie Recording Time |
| White Balance mode |
Auto WB, 7 Preset WBs, 2 Capture WBs, Custom WB(Kelvin setting) |
| White balance compensation |
±7 steps in each A-B/G-M axis |
| Preset white balance |
7 preset WBs (3000K - 7500K) - Sunny(5300K), Shadow(7500K), Cloudy(6000K), Incandescent(3000K), Fluorescent(4000K) |
| CWB (Kelvin setting) |
1 setting can be registered at Kelvin temperature, 2000K to 14000K. |
| One-touch white balance |
2 custom settings can be registered |
| Color space |
sRGB |
| Picture Mode |
Vivid, Natural, Muted, Portrait, Monotone, Art Filters |
| Gradation |
Auto, Normal, High Key, Low Key [except Art Flters] |
| Adjustment parameter |
4 levels (Auto, Normal, High key, Low key) |
| Filter effect |
Neutral, Yellow, Orange, Red, Green for Monotone |
| Noise Filter |
Off, Low, Standard, High (at High ISO setting) |
| Noise Reduction |
Off, On, Auto On: effective when shutter speed is slower than 1 sec. Auto: effective when shutter speed is slower than 4 sec. (at ISO 200 or higher) or 8 sec. (at lower than ISO200) (at Slow shutter speed) |
| Multi Exposure |
2 frames / Auto gain, Live View (Number of picture/Functions) |
| Multi Aspect: Aspect Ratio |
4:3(Default) / 3:2 / 16:9 / 1:1 |
| Multi Aspect: Process |
RAW: Aspect ratio is recorded as Exif data, JPEG: JPEG image is produced based on the aspect ratio |
| Playback mode |
Single-frame, Information display, Index display (4/9/25 frames), Enlargement (2x - 14x), Movie (with sound, FF/REW/Pause), Picture rotation (auto), Slideshow |
| Menu Languages |
39 languages selectable: Japanese, English, French, Germany, Spanish, Italian, Korean, Traditional Chinese, Arabic, Farsi, Russian, Czech, Danish, Polish, Dutch, Portuguese(por), Portuguese(bra), Norwegian, Finnish, Croatian, Slovenian, Simplified Chinese, Greek, Slovak, Turkish, Latvian, Estonian, Swedish, Lithuanian, Serbian, Rumanian, Indonesian, Vietnamese, Hungarian, Ukrainian, Bulgarian, Malay, Thai, Hebrew |
| HDMI |
Micro HDMI (Type-D) |
| PC interface |
USB2.0 Hi-Speed |
| TV interface |
HDMI (HD/Stereo Sound), VIDEO-OUT(SD/Mono Sound) |
| Battery |
Li-50B Li-ion battery (included) |
| Editing function |
RAW development, Gradation auto, Red-eye fix, Resize (1280x960, 640x480, 320x240), Trimming, Aspect, e-Portrait, Postrecording |
| RAW picture editing |
RAW development based on settings of the camera(including Art Filter) |
| JPEG editing |
Shadow adjustment, Red-eye fix, Trimming, Aspect, Black&White, Sepia, Saturation, Resize, e-portrait |
| Print function |
Print reservation (DPOF), Direct print (PictBridge compatible) |
| Operating Temperature |
0 - +40deg.C (operation) / -20 - +60deg.C (storage) |
| Operating Humidity |
30 - 90% (operation) / 10 - 90% (storage) |
| Dimensions (WxHxD) |
102.4x61.1x34.3mm / 4.03x2.40x1.35" (With CIPA guideline compliant, excluding protrusions) |
| Weight |
221g / 7.79oz (With CIPA with BLN-1 battery and Memory card) |
