| Memory |
SD Memory Card(SDHC/SDXC compatible) - 64GB |
| Screen size |
1/1.63" |
| Lens Structure |
11elements in 8groups |
| Lens -Aspheric |
6 sides |
| Focal length(35mm equivalent) |
6.0mm to 24.0mm(28mm to 112mm) |
| Maximum aperture |
1.8-2.5 |
| Optical zoom |
4x |
| Digital Zoom |
4x |
| Imaging range |
Normal:60cm to infinity,
Macro:W:10cm to infinity, T:30cm to infinity.
Super Macro:1cm to TBD, Wide-angle edge fixing |
| Total no. of pixels |
4072x2784 |
| Aspect ratio |
4:3 |
| Recording format (Still) |
DCF, DPOF compatible/Exif, PRINT Image Matching III |
| File format |
RAW (12-bit lossless compression), JPEG, RAW+JPEG |
| Recording image size |
[RAW] 3648 x 2736 pixels
[JPEG] 3648 x 2736 pixels - 640 x 480 pixels |
| File Size: RAW |
3648 x 2736 (approx. 1/1.5 lossless compressed) Approx. 17MB |
| File Size: large |
3648 x 2736 Fine (1/4 compressed) Approx. 5.5MB
3648 x 2736 Normal (1/8 compressed) Approx. 3.1MB |
| File Size: Middle |
3200 x 2400 Fine (1/4 compressed) Approx. 4.4MB
3200 x 2400 Normal (1/8 compressed) Approx. 1.9MB
2560 x 1920 Fine (1/4 compressed) Approx. 2.4MB
2560 x 1920 Normal (1/8 compressed) Approx. 1.3MB
1600 x 1200 Fine (1/4 compressed) Approx. 1MB
1600 x 1200 Normal (1/8 compressed) Approx. 0.5MB |
| File Size: Small |
1280 x 960 Fine (1/4 compressed) Approx. 0.7MB
1280 x 960 Normal (1/8 compressed) Approx. 0.4MB
1024 x 768 Fine (1/4 compressed) Approx. 0.5MB
1024 x 768 Normal (1/8 compressed) Approx. 0.3MB
640 x 480 Fine (1/4 compressed) Approx. 0.2MB
640 x 480 Normal (1/8 compressed) Approx. 0.2MB |
| Recording format (Movie) |
AVI Motion JPEG(30fps) |
| Movie Mode |
HD: 1280(H)x720(V) Aspect 16:9
SD: 640(H)x480(V) Aspect 4:3(VGA) |
| Compression Ratio |
1/12 |
| File Size |
Max 2GB(limited by AVI format) |
| Maximum Recording Time (Movie) |
HD: 7min, SD: 14min |
| Recording format (Sound) |
Wave Format Base
Stereo PCM/16bit, 44.1kHz |
| Maximum Recording Time |
Picture with Sound: 30sec
Movie: depend on Movie Recording Time |
| Live View Type |
Image Sensor type |
| Field of view |
1 |
| Display Mode |
Normal Mode
Grid Line + Histogram Mode
OFF Mode |
| Display of Face Detection |
Max 8 frames of face detection can be displayed |
| AF |
Imager AF |
| Image stabilizer |
Built in |
| Image stabilizer: Mode |
2 dimensional activation, OFF |
| Effective compensation range |
Approx.2EV steps |
| Shutter speed range |
2 - 1/2000 sec. (Not available when Bulb is selected) |
| IS for Movie |
Electronic Image Stabilization with Multi-Motion function |
| Monitor Type |
OLED |
| Monitor Size |
3.0 inches (3:2) |
| Monitor Total no. of pixels |
614,000dots |
| Playback field of view |
1 |
| Brightness control |
+2 levels and -2 levels |
| Focus mode |
Single AF (AF) / Manual Focus (MF) / Macro mode / SuperMacro mode / AF tracking (TR) |
| Focusing point |
11-area multiple AF with the contrast detection system (Auto, selectable in option) |
| Focusing point selection |
Auto from all 11 area, Single area from 11 area
Auto from almost all area when Face detection is ON
Free selection (from 225points) when Magnified View Mode is selected |
| AF illuminator |
Yes |
| Focus tracking |
Yes |
| Shooting Modes |
P (Program Auto), iAUTO, A (Aperture priority), S (Shutter priority), M (Manual shooting), C (Custom shooting), Low Light, Art Filter, SCN (Scene) |
| Metering system |
TTL Image Sensor metering system
(1) Digital ESP metering (324-area multi pattern metering) (2) Center weighted average metering (3) Spot metering |
| Metering range |
EV 0 - 17 |
| Exposure mode |
(1) i Auto (2) P: Programme AE (3) A: Aperture priority AE (4) S: Shutter priority AE (5) M: Manual (6) Low Light (7) Scene select AE (8) Art Filter |
| Scene select AE |
Portrait, e-Portrait, Landscape, Night Scene, Night + Portrait, Indoor, Self Portrait, Sport, Sunset, Fireworks, |
| ISO sensitivity |
AUTO: ISO 100 - 800 / Manual ISO 100 - 6400, 1/3 EV steps, Movie ISO 200-1600, Low light ISO 100-3200 |
| Exposure compensation |
±2 EV in 1/3EV steps |
| AE lock |
No |
| Exposure bracketing |
Yes |
| Auto WB system |
Yes |
| Preset white balance |
6 settings (3000K - 7500K)
Lamp (3000K), Fluorescent 1 (4000K), Fluorescent 2 (4500K), Daylight (5300K), Cloudy (6000K), Shade (7500K), Under Water Auto, One Touch WB |
| White balance compensation |
±7 steps in each A-B/G-M axis (in Auto WB / Preset WB mode / One touch WB) |
| CWB (Kelvin setting) |
1 setting can be registered at Kelvin temperature (2000K - 14000K) |
| One-touch white balance |
Yes |
| White balance bracketing |
3 frames in 2, 4, 6 steps selectable in each A-B/G-M axis. |
| Color space |
sRGB |
| Picture Mode |
Vivid, Natural, Portrait, Muted, Monotone |
| Adjustment parameter |
Contrast, Sharpness and Saturation level available in 5 steps for Vivid, Natural, Portrait and Muted
Contrast and Sharpness level available in 5 steps for Monotone. |
| Filter effect |
Yellow, Orange, Red or Green filter available for Monotone |
| Picture tone |
Sepia, Blue, Purple or Green tone available for Monotone |
| Gradation |
4 levels (Auto, High key, Normal, Low key) |
| Shutter speed |
60 - 1/2000 sec
Bulb: up to 16 min.
1/3 steps |
| Self-timer |
Operation time: 12 sec., 2 sec. (cancel available) |
| Remote cable release |
Yes (with optional RM-UC1 Remote cable.) |
| Drive mode |
Single-frame shooting, Sequential shooting, High-speed Sequential shooting1,High-speed Sequential shooting2,Self-timer |
| Sequential shooting speed |
Approx. 2 frames/sec. in sequential shooting |
| Max. recordable pictures |
RAW mode: Max. 8 frames. |
| On sequential shooting |
JPEG mode: Depends on compression ratio and no. of pixels (Large normal mode: approx. 23 with Toshiba Super High Speed type "Class 6" 4GB) |
| Built-in flash |
Yes |
| Compatible external flash |
E-system Flash(FL-36R, FL-20, FL-14,FL-50R)
FL-50R(Can only be used with wireless. Cannot attach to body) |
| Flash mode of External Flash |
Auto, Red-eye reduction, Red-eye reduction slow sync., Slow sync at 1st curtain, Slow sync at 2nd curtain, Fill-in, Off. |
| Flash intensity control |
Up to ±2 EV in 0.3 EV steps |
| Art Filter Mode |
Pop Art, Soft Focus, Grainy Film, Pin Hole, Diorama and Dramatic Tone |
| Multi Exposure Picture |
2 frames |
| Multi Exposure Functions |
Auto gain |
| Multi Aspect Ratio |
4:3/3:2/16:9/6:6 |
| Live Control - Information (shooting) |
Battery information, Shooting mode, Shutter speed, Aperture value, Exposure compensation value, ISO sensitivity, |
| Live Control - Live Guide |
Exposure compensation indicator, Exposure indicator, Flash intensity compensation indicator, Date, Auto BKT setting,
WB, Record mode, Flash Status, Image size, Drive mode, Flash intensity compensation value, Metering mode, Recordable still image number, Focusing mode, AF frame, IS activating mode, Face detection, My Mode,
Multi Exposure, Aspect Ratio |
| Live Guide |
Color saturation, Color image, Brightness, Blur Background, Shooting tips |
| Playback mode |
Single-frame
Information Display
Index Display(25 frames, Calendar)
Close-up (1.1 - 10X0
Movie (w/sound, FF/REW/Pause)
Slideshow (Still/Movie/Still+Movie, Slide show w/BGM/BGM+Sound/Sound) |
| Image Editing |
Erasing function: Single frame, All, Selected frames(from Index)
Protect function: Single frame
RAW picture editing: RAW development based on settings of the camera(including Art Filter)
JPEG editing: Shadow adjustment, Red-eye fix, Trimming, Monotone, Sepia, Saturation (color depth), Resize (producing another file, 1280x960, 640x480, 320x240), e-portrait |
| Input/Output |
PC interface: USB 2.0 High Speed for storage through Multi-connector(MTP mode is available)
TV interface: HDMI(HD/Stereo Sound), VIDEO-OUT(SD/Mono Sound)
USB/Video connector: Dedicated multi-connector (Video: NTSC/PAL selectable, Optional Remote cable RM-UC1, USB cable is available)
HDMI: Mini HDMI type-D
Flash attachment: Hot shoe
DC-in: Yes(Multi terminal)
Accessory attachment: Accessory port |
| Battery |
Li-50B (included) |
| Sleep mode |
Available (20sec, 1min, 3min, 5min) |
| No. of recordable pictures |
Approx. 320 shots |
| Operating Environment Temperature |
0 - 40 deg.C (operation) / -20 - 60 deg.C (storage) |
| Operating Environment Humidity |
30 - 90% (operation) / 10 - 90% (storage) |
| Dimensions (W x H x D) |
4.35 x 2.55 x 1.67" / 11.06 x 6.48 x 4.23 cm |
| Weight |
9.7 oz / 275g (body, battery and media) |
