| Camera Type | Digital Interchangeable Lens Camera |
| Intelligent Auto (iA) Mode | MEGA O.I.S.
Intelligent ISO Control
Face Detection
Intelligent Scene Selector
Light Detection
AF Tracking |
| Camera Effective Pixels | 12.1 Mega Pixels |
| Optical Image Stabilizer | MEGA O.I.S. |
| Image Sensor | 13.1 Total Mega Pixels
Live MOS Sensor
Primary Color Filter |
| Image Sensor Size | 17.3 x 13.0mm |
| Dust Reduction System | Supersonic wave filter |
| Focal Length | f=14mm to 45mm (35mm film camera equivalent 28mm to 90mm) |
| Lens Construction | 12 elements in 9 groups (1 Aspherical lens) |
| Aperture Type | 7 diaphragm blades / Circular aperture diaphragm |
| Aperture Range | f/3.5 (Wide) - f/5.6 (Tele)
Minimum Aperture f/22 |
| Mount | Micro Four Thirds mount |
| Closest Focusing Distance | 0.30m at all focal lengths |
| Maximum Magnification | Approx. 0.17x / 0.34x (35mm film camera equivalent) |
| Diagonal Angle of View | 75° (W)~27° (T) |
| Filter Size | 52mm (Diameter) / 2.05 in |
| Max. Diameter | 60mm (Diameter)/ 2.36 in |
| Overall Length (Lens only) | Approx. 60mm / 2.36 in (from the tip of the lens to the base side of the lens mount) |
| Weight (Lens only) | Approx. 195g / 6.88oz |
| Focus Type | Contrast AF system |
| Focus Mode | AFs/AFc/MF |
| Focus AF Detective Range | EV 0-18 (ISO100) |
| Focus AF mode | Face detection
Focus AF Tracking/23-area-focusing/1-area-focusing |
| AF/AE Lock | Yes (AF/AE LOCK button or Shutter button halfway pressed in AFs mode) |
| AF Assist Lamp | Yes |
| ISO Sensitivity | Auto / 100 / 200 / 400 / 800 / 1600 / 3200 / Intelligent ISO |
| White Balance | Auto / Daylight / Cloudy / Shade / Halogen / Flash / White Set 1,2 / Color temperature setting |
| White Balance Adjustment | Blue/Amber Bias
Magenta/Green Bias |
| Color Temperature Setting | 2500-10000K in 100K |
| White Balance Bracket | 3 exposures in blue/amber axis or in magenta/green axis |
| Exposure | Program AE
Aperture Priority AE
Shutter Priority AE
Manual |
| Exposure Compensation | 1/3 EV Step, ± 2 EV |
| Auto Bracketing (AE) | 3, 5, 7 frame, in 1/3 or 2/3 EV Step, ±2 EV |
| Light Metering System | 144-zone multi-pattern sensing system |
| Light Metering | Intelligent Multiple / Center-weighted / Spot |
| Metering Range | EV 0-18 (f/2.0 lens, ISO 100) |
| Scene Modes | SCN (Sunset / Party / Baby 1, 2 / Pet) |
| Advanced Scene Mode | Portrait mode: Normal, Soft Skin, Outdoor, Indoor, Creative
Scenery mode: Normal, Nature, Architecture, Creative
Sports mode: Normal, Outdoor, Indoor, Creative
Night Portrait: Night Portrait, Night Scenery, Illuminations, Creative |
| Shutter Speed/Shutter System | Type: Focal-plane shutter, Speed: 1/4000 ~ 60 and Bulb (up to approx. 4 minutes), Remote control with bulb function by DMW-RSL1 (Optional) |
| Self Timer | 2 seconds / 10 seconds / 10 seconds / 3 images |
| Recording Format | Still Image: JPEG(Design rule for Camera File system, based on Exif 2.21 standard), RAW, DPOF corresponding image with audio: JPEG (Design rule for Camera File system, based on Exif 2.21 standard) |
| Image Quality | Fine / Standard / RAW / RAW+Standard JPEG / RAW+Fine JPEG |
| Color Space | sRGB, Adobe RGB |
| 4:3 Aspect Ratio (Still Image) | 4000 x 3000 pixels
2816 x 2112 pixels
2048 x 1536 pixels |
| 3:2 Aspect Ratio (Still Image) | 4000 x 2672 pixels
2816 x 1880 pixels
2048 x 1360 pixels |
| 16:9 Aspect Ratio (Still Image) | 4000 x 2248 pixels
2816 x 1584 pixels
1920 x 1080 pixels |
| Burst Shooting Mode | 7 pics(when there are RAW file with the particular speed)
Unlimited consecutive shooting (when no RAW file) (depending on memory card size, batt. power, pic size & compression)
For 3 frames/sec (High speed) or 2 frames/sec (Low speed) |
| Protection/Erase | Protection: Single / Multi or Cancel
Erase: Single / Multi / All / Except FAVORITE |
| Built-in Flash Type/Mode | Type: TTL Built-in-Flash, GN11 (ISO100,m), Built-in Pop-up
Mode: Auto, Auto/Red-eye Reduction, Forced On, Forced On/Red-eye Reduction, Slow Sync., Slow Sync./Red-eye Reduction, Forced Off |
| X-Sync Speed | Less than 1/160 second |
| Flash Synchronization | 1st. Curtain Sync., 2nd Curtain Sync. |
| External Flash | Hot shoe (TTL Auto with FL360/FL500/FL220 (Optional)) |
| Viewfinder | Live View Finder(1,440,000 dots equiv)
Magnification: Approx. 1.4x/0.7x(35mm film camera equiv) w/50mm lens at infinity; -1.0 m-1
Field of view: approx. 100%
Eye point: approx. 17.5mm
Diopiter Adjust: -4.0 ~ +4.0 [m-1] |
| LCD Monitor | Free-angle 3.0 Low temperature Polycrystalline TFT LCD (460K dots)
3:2 Aspect/Wide viewing angle
Field of view: approx. 100% |
| Live View | Digital zoom: 2x, 4x
Extra optical zoom: Max. 2x (Not effective with full pixel recording. Magnification ratio depends on the recording pixels.)
Other functions: Highlight Display, Guide Lines (3 patterns), Real-time Histogram |
| Film Mode | Standard, Dynamic, Natural, Smooth, Vibrant, Nostalgic, WB/Standard, WB/Dynamic, WB/Smooth, My Film1, MyFilm2, Multi Film |
| Playback Mode | Single/12/30-thumbnail display
Calendar display
Zoomed playback
Image rotation(except RAW)
Slide show
Playback fav pictures
Resizing(selectable number of pixels)
Trimming/Protection
Aspect conversion
DPOF print setting |
| OSD Language | English, French, Spanish, Portuguese |
| Recording Media | SD Memory Card
SDHC Memory Card
Multimedia Card |
| Interface | Digital: USB 2.0 (High Speed)
Digital Video: MiniHDMI TypeC (1.3b corresponding)
Analog Video: NTSC/PAL Composite (switched by menu) |
| Direct Print | PictBridge Print size, Layout, Date setting is selectable |
| Color | Black |
| Power Supply | Li-ion Battery Pack (7.2V, 1250mAh)(Included)
Battery Charger/AC Adaptor (Input: 110-240V AC) (Optional DC cable (DMW-DCC3) is required) |
| Battery Life | Up to 330 images (LCD), up to 350 images (LVF) (CIPA Standard with LUMIX G VARIO 14-45mm/F3.5-5.6 ASPH./MEGA O.I.S.)* |
| Dimensions (H x W x D) | 3.29'' x 4.88'' x 1.78'' |
| Weight | 0.85 lbs |
| Warranty | Panasonic warranty |
| | |
