| Camera Type |
Digital Interchangeable Lens Camera |
| Recording Media |
SD memory card, SDHC memory card, MultiMediaCard |
| Image Sensor Size |
17.3 x 13.0 mm (in 4:3 aspect ratio) |
| Mount |
Micro Four Thirds mount |
| Image Sensor |
13.1 Total MegaPixels Live MOS Sensor Primary Color Filter |
| Camera Effective Pixels |
12.1 Mega Pixels |
| Dust Reduction System |
Supersonic wave filter |
| Recording Format (Still Image) |
JPEG(DCF, Exif 2.21), RAW, DPOF compatible |
| Recording Format (Still Image w/ Audio) |
JPEG(DCF, Exif 2.21) + Quicktime |
| Recording Format (Motion Image) |
AVCHD / QuickTime Motion JPEG |
| Aspect Ratio |
4:3, 3:2, 16:9, 1:1 (Multi-aspect recording except 1:1) |
| Image Quality |
RAW, RAW+Fine, RAW+Standard, Fine, Standard |
| Color Space |
sRGB, Adobe RGB |
| 4:3 Aspect Ratio (Still Image) |
4000 x 3000(L), 2816 x 2112(M), 2048 x 1536(S) |
| 3:2 Aspect Ratio (Still Image) |
4128 x 2752(L), 2928 x 1952(M), 2064 x 1376(S) |
| 16:9 Aspect Ratio (Still Image) |
4000 x 2248(L), 2816 x 1584(M), 1920 x 1080(S) |
| 1:1 Aspect Ratio (Still Image) |
2992 x 2992(L), 2112 x 2112(M), 1504 x 1504(S) |
| Motion Image (4:3 Aspect Ratio) |
QVGA : 320 x 240, 30fps / VGA : 640 x 480, 30fps |
| Motion Image (16:9 Aspect Ratio) |
WVGA : 848 x 480, 30fps |
| Motion Image (HD Movie) |
1280 x 720, 30fps |
| Motion Image (AVCHD) |
NTSC: [HD] 1280 x 720, 60p (sensor output is 30fps)(SH: 17Mbps, H: 13Mbps, L: 9Mbps) PAL: [HD] 1280 x 720, 50p (sensor output is 25fps)(SH: 17Mbps, H: 13Mbps, L: 9Mbps) |
| Focus Type |
Contrast AF system |
| Focus Mode |
AFs/AFc/MF |
| Focus AF mode |
Face detection / AF Tracking / 23-area-focusing / 1-area-focusing |
| Focus AF Detective Range |
EV 0-18 (F3.5 lens, ISO 100) |
| AF Assist Lamp |
Yes |
| AF/AE Lock |
AF/AE LOCK button or Shutter button halfway pressed in AFs mode |
| Focus Others |
Pre AF(Quick AF/Continuous AF),AF+MF, MF Assist(5x, 10x) |
| Light Metering System |
144-zone multi-pattern sensing system |
| Light Metering |
Intelligent Multiple / Center-weighted / Spot |
| Metering Range |
EV 0-18 (F2.0 lens, ISO 100) |
| Exposure |
Program AE, Aperture Priority AE, Shutter Priority AE, Manual |
| ISO Sensitivity |
Auto / 100 / 200 / 400 / 800 / 1600 / 3200 / Intelligent ISO |
| Exposure Compensation |
1/3 EV Step, ± 3 EV |
| Auto Bracketing (AE) |
3,5,7 frame, in 1/3 or 2/3 EV Step, ±2 EV |
| White Balance |
Auto / Daylight / Cloudy / Shade / Halogen / Flash / White Set 1,2 / Color temperature setting |
| White Balance Adjustment |
Blue/Amber Bias Magenta/Green Bias |
| Color Temperature Setting |
2500-10000K in 100K |
| White Balance Bracket |
3 exposures in blue/amber axis or in magenta/green axis |
| Shutter Speed/Shutter System |
Type: Focal-plane shutter, Speed: 1/4000 ~ 60 and Bulb (up to approx. 4 minutes) |
| Self Timer |
2 seconds / 10 seconds / 10 seconds / 3 images |
| Remote Control |
Remote control with bulb function by DMW-RSL1 (Optional) |
| Scene Modes |
Portrait/Soft Skin/Scenery/Architecture/Sports/Peripheral Defocus/Flower/Food/Objects/Night Portrait/Night Scenery/Illuminations/Baby 1,2/Pet/Party/Sunset |
| Movie Scene Mode |
Portrait/Soft Skin/Scenery/Architecture/Sports/Flower/Food/Objects/Low Light/Party/Sunset (Activated by selecting Still Image SCN mode then pressing Movie Button. Still Image SCN modes without corresponding Movie SCN mode is recorded in Normal mode or other related mode.) |
| Burst Shooting Mode |
3 frames/sec (High speed) or 2 frames/sec (Low speed) Number of recordable images: 7 images (when there are RAW files with the particular speed) Unlimited consecutive shooting (when there are no RAW files) (depending on memory card size, battery power, picture size, and compression) |
| Built-in Flash Type |
TTL Built-in-Flash, GN6.0 equivalent (ISO 100 ?m), Built-in Pop-up |
| Built-in Flash Mode |
Auto, Auto/Red-eye Reduction, Forced On, Forced On/Red-eye Reduction, Slow Sync., Slow Sync./Red-eye Reduction, Forced Off |
| X-Sync Speed |
Less than 1/160 second |
| Flash Output Adjustment |
1/3EV Step ±2EV |
| Flash Synchronization |
1st. Curtain Sync. , 2nd Curtain Sync. |
| External Flash |
TTL Auto with FL220/FL360/FL500 (Optional) |
| LCD Monitor |
Type: Low temperature Polycrystalline TFT LCD Monitor Size: 3.0inch / 3:2 Aspect / Wide viewing angle Pixels: 460K dots Field of view: Approx. 100% Brightness Adjustment: Auto, Power LCD, Manual (7 levels) |
| Live View |
Digital Zoom: 2x, 4x Extra Optical Zoom: Max.2x (Not effective with L size recording. Magnification ratio depends on the recording pixels and aspect ratio.) Other Functions: Guide Lines (3 patterns), Real-time Histogram |
| Film Mode |
Color: Standard / Dynamic / Nature / Smooth / Nostalgic / Vibrant Black and white: Standard / Dynamic / Smooth Others: My Film1 / My Film2 / Multi Film |
| Protection |
Single / Multi or Cancel |
| Erase |
Single / Multi / All / Except Favorite |
| Direct Print |
PictBridge compatible (Print size, Layout, Date setting is selectable) |
| OSD Language |
English, French, Spanish, Portuguese |
| Interface |
Digital: USB 2.0 (High Speed). Digital Video: miniHDMI TypeC. Video: Auto / 1080i / 720p / 480p (576p in PAL system) Audio: Dolby Digital Stereo Creator Audio video output: Monaural Type, NTSC/PAL Remote: 2.5mm |
| Microphone |
Monaural, Wind-cut: Off / Low / Standard / High |
| Speaker |
Yes |
| Power Supply |
ID-Security Li-ion Battery Pack (7.2V, 1250mAh) (Included) Battery Charger/AC Adapter (Input: 110-240V AC, DC Cable is required) |
| Battery Life |
CIPA Standard : Approx. 350 images(LCD) LVF : Approx. 430 images with 20mm |
| Included Software |
PHOTOfunSTUDIO 3.1 HD Edition SILKYPIX Developer Studio 3.0 SE USB Driver |
| Operating Temperature |
32°F to 104°F (0°C to 40°C) |
| Operating Humidity |
10% to 80% |
| Dimensions (H x W x D) |
119 x 71 x 36.3mm / 4.69 x 2.80 x 1.43 in |
| Weight |
Approx. 285g / 10.05 oz ?Body only? |
| Warranty |
Panasonic warranty |
