| Recording Media |
SD Memory Card, SDHC Memory Card, SDXC Memory Card |
| Image Sensor Size |
17.3 x 13.0 mm (in 4:3 aspect ratio) |
| Lens Mount |
Micro Four Thirds mount |
| Image Sensor Type |
Live MOS Sensor |
| Total Pixels |
13.06 Megapixels |
| Camera Effective Pixels |
12.10 Megapixels |
| Color Filter |
Primary color filter |
| Dust Reduction System |
Supersonic wave filter |
| Recording File Format |
Still Image: JPEG (DCF, Exif 2.3), RAW, DPOF compatible MPO (When attaching 3D lens in Micro Four Thirds System standard
Motion Image: AVCHD / QuickTime Motion JPEG |
| Aspect Ratio |
4:3, 3:2, 16:9, 1:1 |
| Image Quality |
RAW, RAW+Fine, RAW+Standard, Fine, Standard
MPO+Fine, MPO+Standard (When attaching 3D lens in Micro Four Thirds System standard) |
| Color Space |
sRGB, Adobe RGB |
| File Size (Pixels) Still Image |
[4:3] 4,000 x 3,000 (L), 2,816 x 2,112 (M), 2,048 x 1,536 (S), 1,600 x 1,200
[3:2] 4,000 x 2,672 (L), 2,816 x 1,880 (M), 2,048 x 1,360 (S), 1,600 x 1,064
[16:9] 4,000 x 2,248 (L), 2,816 x 1,584 (M), 1,920 x 1,080 (S), 1,600 x 904
[1:1] 2,992 x 2,992 (L), 2,112 x 2,112 (M), 1,504 x 1,504 (S), 1,440 x 1,440 (When attaching 3D lens in Micro Four Thirds System standard) |
| File Size (Pixels) Motion Image |
Motion JPEG: [4:3] VGA: 640 x 480, 30 fps / QVGA: 320 x 240, 30 fps
[16:9] WVGA: 848 x 480, 30 fps
[HD] 1,280 x 720, 30 fps |
| File Size (Pixels) AVCHD |
NTSC: [Full HD] 1,920 x 1,080, 60i (sensor output is 30p) (FSH: 17 Mbps, FH: 13 Mbps), [HD] 1,280 x 720, 60p (sensor output is 30p) (SH: 17 Mbps, H: 13 Mbps)
PAL [Full HD] 1,920 x 1,080, 50i (sensor output is 25p) (FSH: 17 Mbps, FH: 13 Mbps)
[HD] 1,280 x 720, 50p (sensor output is 25p) (SH: 17 Mbps, H: 13 Mbps) |
| Continuous Recordable Time |
AVCHD with picture quality set to [SH]: Approx. 160 min with H-FS014042 / Approx. 170 min with H-H014 |
| Actual Recordable Time |
AVCHD with picture quality set to [SH]: Approx. 130 min with H-FS014042 / Approx. 150 min with H-H014 |
| Focus Type |
Contrast AF system |
| Focus Mode |
AFS / AFC / MF |
| Focus AF Mode |
Face detection / AF Tracking / 23-area-focusing / 1-area-focusing/Pinpoint |
| Focus AF Detective Range |
EV 0 - 18 (ISO 100) |
| Focus AF Assist Lamp |
YES |
| Focus AF Lock |
Set the Fn button in custom menu to AF lock |
| Focus Others |
Quick AF, Continuous AF (during motion image recording), AF+MF, Touch shutter, Touch MF Assist |
| Light Metering System |
144-zone multi-pattern sensing system |
| Light Metering Mode |
Intelligent Multiple / Center Weighted / Spot |
| Metering Range |
EV 0 - 18 (F2.0 lens, ISO 100) |
| Exposure Mode |
Program AE / Aperture Priority AE / Shutter Priority AE / Manual |
| ISO Sensitivity |
Auto / Intelligent ISO / 100 / 200 / 400 / 800 / 1600 / 3200 / 6400 |
| Exposure Compensation |
1/3 EV Step, ±3 EV |
| AE Lock |
Set the Fn button in custom menu to AE lock |
| AE Bracket |
3,5 frame, in 1/3 or 2/3 EV Step, ±4/3 EV |
| White Balance |
Auto / Daylight / Cloudy / Shade / Halogen / Flash / White Set 1, 2 / Color temperature setting / Portrait / Beauty skin / Sport / Flower / Collection / Baby / Pet / defocus control |
| White Balance Adjustment |
Blue/amber bias, Magenta/green bias |
| Color Temperature Setting |
2,500 K - 10,000 K in 100 K |
| White Balance Bracket |
3 exposures in blue/amber axis or in magenta/green axis |
| Shutter Type |
Focal-plane shutter |
| Shutter Speed |
Still Images: 1/4000 - 60
Motion image: 1/16000 - 1/30 (NTSC) |
| Self Timer |
10 sec, 3 images / 2 sec / 10 sec |
| Still Image SCN Mode |
Portrait / Soft Skin / Scenery / Architecture / Sports / Peripheral Defocus / Flower / Food / Objects / /Night Portrait / Night Scenery / Illiminatioms / Baby1, 2 / Pet / Party / Sunset |
| Movie SCN Mode |
Portrait / Soft Skin / Scenery / Architecture / Sports / Flower / Food / Objects / Low-light / Party / Sunset |
| Burst Speed |
H: 3.8 frames/sec, M: 2.8 frames/sec (with Live View), L: 2 frames/sec (with Live View) |
| Number of Recordable Images |
7 images (when there are RAW files with the particular speed)
Unlimited consecutive shooting (when there are no RAW files)
(depending on memory card size, battery power, picture size, and compression) |
| Built-in-flash Type |
TTL Built-in-Flash, GN6.3 equivalent (ISO 160m), Built-in Pop-up |
| Flash Mode |
Auto, Auto / Red-eye Reduction, Forced On, Forced On / Red-eye Reduction, Slow Sync., Slow Sync. / Red-eye Reduction, Forced Off |
| Synchronization Speed |
Less than 1/160 second |
| Flash Synchronization |
1st. Curtain Sync. |
| LCD Monitor Type |
TFT LCD with Touch panel |
| Monitor Size |
3.0 inch / 3:2 Aspect / Wide-viewing angle |
| Pixels |
460,000 dots |
| Field of View |
Approx. 100% |
| Monitor Adjustment |
Brightness (7 levels), Color (7 levels) |
| Digital Zoom |
2x, 4x |
| Extra Tele Conversion |
Still image: Max.2x (Not effective with L size recording. Magnification ratio depends on the recording pixels and aspect ratio.)
Motion image: 3.1x (SH/H in AVCHD and HD/WVGA in Motion JPEG), 4.2x (VGA/QVGA inMotion JPEG) |
| Other Functions |
Guide Lines (3 patterns)
Real-time Histogram |
| My Color Mode |
(Still image & Motion image) Expressive / Retro / High key / Sepia / High Dyamic/ Miniature |
| Playback Mode |
Normal playback, 30-thumbnail display, 12-thumbnail display, Calendar display, Zoomed playback (16x Max.), Slideshow (duration & effect is selectable), Playback Mode (Normal/Picture/AVCHD/Motion JPEG/3D Play/Category/Favorite), Title Edit, Text Stamp, Video Divide, Resize, Cropping, Aspect Conversion, Rotate, Rotate Display, Favorite, Print set, Protect, Face Recognition Edit |
| Protection |
Single / Multi, Single in Burst Group / Multi in Burst Group, Cancel |
| Erase |
Single / Multi / All / Except Favorite |
| Direct Print |
PictBridge compatible (Print size, Layout, Date setting are selectable) |
| USB |
USB 2.0 High Speed |
| HDMI |
miniHDMI TypeC
Video: Auto / 1080i / 720p / 480p
Audio: Linear PCM |
| Audio Video Output |
Monaural Type, NTSC |
| Microphone |
Stereo, Wind-cut: Off / Low / Standard / High
Microphone level adjustable: Lv1 / Lv2 / Lv3 / Lv4 |
| Speaker |
Monaural |
| OSD Language |
English, German, French, Italian, Spanish, Polish, Czech, Hungarian, Russian, Chinese (Traditional), Chinese (Simplified), Dutch, Thai, Korean, Turkish, Portuguese, Arabic, Persian, Japanese, Swedish, Danish, Finnish, Greek |
| Battery |
Li-ion Battery Pack (7.2V, 940mAh) (Included) |
| Battery Life |
Approx. 320 images with H-FS014042
Approx. 340 images with H-H014 |
| Operating Temperature |
0 deg.C to 40 deg.C (32 deg.F to 104 deg.F) |
| Operating Humidity |
10% to 80% |
| Dimensions (W x H x D) |
4.24 x 2.64 x 1.28 inch / 107.7 x 67.1 x 32.5 mm (excluding protrusions) |
| Weight |
Approx. 7.94 oz / 225g Body Only (9.31 oz / 264g with battery) |
