| Camera Type |
Digital Single Lens Mirrorless camera |
| Recording Media |
SD Memory Card, SDHC Memory Card, SDXC Memory Card (Compatible with UHS-I standard SDHC / SDXC Memory Cards) |
| Image Sensor Size |
17.3 x 13.0 mm (in 4:3 aspect ratio) |
| Lens Mount |
Micro Four Thirds mount |
| Image Sensor |
Type: Live MOS Sensor Total Pixels: 17.20 Megapixels Camera Effective Pixels: 16.05 Megapixels Color Filter: Primary color filter Dust Reduction System: Supersonic wave filter |
| Recording File Format |
Still Image: JPEG (DCF, Exif 2.3), RAW MPO (When attaching 3D lens in Micro Four Thirds System standard) Motion Image: AVCHD Ver 2.0 compliant (AVCHD Progressive), MPEG4-AVC (H.264). (MOV, MP4) |
| Aspect Ratio |
4:3, 3:2, 16:9, 1:1 |
| Image Quality |
RAW, RAW+Fine, RAW+Standard, Fine, Standard MPO+Fine, MPO+Standard (When attaching 3D lens in Micro Four Thirds System standard) |
| Color Space |
sRGB, Adobe RGB |
| Still Image Resolution |
[4:3] 4,608 x 3,456 (L), 3,264 x 2,448 (M), 2,336 x 1,752 (S), 1,824 x 1,368 (When attaching 3D lens in Micro Four Thirds System standard)
[3:2] 4,608 x 3,072 (L), 3,264 x 2,176 (M), 2,336 x 1,560 (S), 1,824 x 1,216 (When attaching 3D lens in Micro Four Thirds System standard)
[16:9] 4,608 x 2,592 (L), 3,264 x 1,840 (M), 1,920 x 1,080 (S), 1,824 x 1,024 (When attaching 3D lens in Micro Four Thirds System standard) |
| Still Image Resolution cont. |
[1:1] 3,456 x 3,456 (L), 2,448 x 2,448 (M), 1,744 x 1,744 (S), 1,712 x 1,712 (When attaching 3D lens in Micro Four Thirds System standard) |
| Motion Image MOV NTSC |
[Full HD] 1,920 x 1,080, 30p (sensor output is 30p, 72Mbps (ALL-Intra)) [Full HD] 1,920 x 1,080, 24p (sensor output is 24p, 72Mbps (ALL-Intra)) [HD] 1,280 x 720, 60p (sensor output is 60p, 72Mbps (ALL-Intra)) [Full HD] 1,920 x 1,080, 60p (sensor output is 60p, 50Mbps (IPB)) [Full HD] 1,920 x 1,080, 30p (sensor output is 30p, 50Mbps (IPB)) [Full HD] 1,920 x 1,080, 24p (sensor output is 24p, 50Mbps (IPB)) |
| Motion Image MP4 NTSC |
[Full HD] 1,920 x 1,080, 30fps (sensor output is 30p, 20Mbps) [HD] 1,280 x 720, 30fps (sensor output is 30p, 10Mbps) [VGA] 640 x 480, 30fps (sensor output is 30p, 4Mbps) |
|
[Full HD] 1,920 x 1,080, 25fps (sensor output is 25p, 20Mbps) [HD] 1,280 x 720, 25fps (sensor output is 25p, 10Mbps) [VGA] 640 x 480, 25fps (sensor output is 25p, 4Mbps) |
| Motion Image AVCHD Progressive |
NTSC: [Full HD] 1,920 x 1,080, 60p (sensor output is 60p, 28Mbps) PAL: [Full HD] 1,920 x 1,080, 50p (sensor output is 50p, 28Mbps) |
| Motion Image AVCHD NTSC |
[Full HD] 1,920 x 1,080, 24p (sensor output is 24p, 24Mbps) [Full HD] 1,920 x 1,080, 60i (sensor output is 30p, 24Mbps) [Full HD] 1,920 x 1,080, 60i (sensor output is 60p, 17Mbps) |
| Continuous Record Time (Motion Image) |
AVCHD: Approx. 240 min with H-HS12035 / Approx. 220 min with H-VS014140 |
| Actual Record Time (Motion Image) |
AVCHD: Approx. 120 min with H-HS12035 / Approx. 110 min with H-VS014140 |
| Flicker Reduction |
[1/50] [1/60] [1/100] [1/120] / OFF |
| Time Code (Motion Image, except MP4) |
ON / OFF, Count Up: Rec Run / Free Run selectable, Time Code Mode: Drop Frame / Non-drop Frame selectable (NTSC only) |
| Wi-Fi |
IEEE 802.11b/g/n, 2412 MHz - 2462 MHz (11 ch), Wi-Fi / WPA / WPA2, Infrastructure mode |
| Viewfinder |
Type: OLED Live View Finder (1,744K dots equivalent) Field of View: Approx. 100% Magnification: Approx. 1.34x / 0.67x (35 mm camera equivalent) Eye Point: Approx. 21 mm from eyepiece lens Diopter Adjustment: -4.0 - +4.0 (dpt) Auto Eye Sensor: Yes |
| Focus |
Type: Contrast AF system Focus Mode: AFS (Single) / AFF (Flexible) / AFC (Continuous) / MF AF Mode: Face detection / AF Tracking / 23-area-focusing / 1-area-focusing / Pinpoint (Full area touch is available) AF Assist Lamp: YES (ON / OFF) AF Lock: Yes (AF/AE LOCK button) Others: Quick AF, Continuous AF (during motion image recording), AF+MF, Eye Sensor AF, Touch AF, Touch Pad AF, Touch shutter, Touch MF Assist, Shutter AF, Half Press Release |
| Light Metering System |
144-zone multi-pattern sensing system |
| Light Metering Mode |
Intelligent Multiple / Center Weighted / Spot |
| Metering Range |
EV 0 - 18 (F2.0 lens, ISO100 equivalent) |
| Exposure Mode |
Program AE / Aperture Priority AE / Shutter Priority AE / Manual |
| ISO Sensitivity |
Auto / Intelligent ISO / 200 / 400 / 800 / 1600 / 3200 / 6400 / 12800 (Changeable to 1/3, 1 EV step) (Extended ISO125 - less under 200, ISO more over 12800 - 25600 available) (Up to ISO3200 in Auto) |
| Exposure Compensation |
1/3 EV Step, ±5 EV (±3 EV for motion image) |
| AE Lock |
AF/AE LOCK button |
| AE Bracket |
3, 5, 7 frames, in 1/3, 2/3 or 1 EV Step, single / burst |
| White Balance |
White Balance: Auto / Daylight / Cloudy / Shade / Incandescent / Flash / White Set 1, 2 / Color temperature setting White Balance Adjustment: Blue/amber bias, Magenta/green bias Color Temperature Setting: 2,500 K - 10,000 K in 100 K White Balance Bracket: 3 exposures in blue/amber axis or in magenta/green axis |
| Shutter |
Type: Focal-plane shutter Shutter Speed: Still Images: 1/4,000 - 60 and Bulb / Motion Images: 1/16,000 - 1/30 (NTSC), 1/16,000 - 1/25 (PAL) Self Timer: 10 sec, 3 images after 10 sec, 2 sec Remote Control: Remote control with Bulb function by DMW-RSL1 (Optional) |
| Scene Guide Still Image |
Clear Portrait / Silky Skin / Backlit Softness / Clear in Backlight / Relaxing Tone / Sweet Child's Face / Distinct Scenery / Bright Blue Sky / Romantic Sunset Glow / Vivid Sunset Glow / Glistening Water / Clear Nightscape / Cool Night Sky / Warm Glowing Nightscape / Artistic Nightscape / Glittering Illuminations / Clear Night Portrait / Soft Image of a Flower / Appetizing Food / Cute Dessert / Freeze Animal |
| Scene Guide Motion Image |
Clear Portrait / Silky Skin / Backlit Softness / Clear in Backlight / Relaxing Tone / Sweet Child's Face / Distinct Scenery / Bright Blue Sky / Romantic Sunset Glow / Vivid Sunset Glow / Clear Nightscape / Cool Night Sky / Warm Glowing Nightscape / Artistic Nightscape / Clear Night Portrait / Appetizing Food / Cute Dessert / Freeze Animal Motion / Clear Sports Shot / Monochrome |
| Burst Shooting |
SH: 20 frames/sec (4M) H: 6 frames/sec M: 4 frames/sec (with Live View) L: 2 frames/sec (with Live View) |
| Flash |
Built-in Flash: TTL Built-in-Flash, GN12.0 equivalent (ISO100 · m), GN17.0 (ISO200 · m), Built-in Pop-up (Reference) Flash Mode: Auto, Auto / Red-eye Reduction (when iA, iA+), Forced ON, Forced ON / Red-eye Reduction, Slow Sync., Slow Sync. / Red-eye Reduction Sync Speed: Less than 1/160 second Flash Output Adjust: 1/3 EV Step ±3 EV Flash Sync: 1st Curtain Sync., 2nd Curtain Sync Sync for Flash Dimming and Exposure Compensation: Yes (ON / OFF) Flash Sync Socket: Yes |
| Monitor |
Type: OLED monitor with static touch control Monitor Size: Free-angle 3.0 inch (7.5 cm) / 3:2 Aspect / Wide-viewing angle Pixels: 614K dots Field of View: Approx. 100% Monitor Adjustment Brightness (7 levels), Color (7 levels), Red-Green (11 levels), Blue-Yellow (11 levels) |
| Live View |
Digital Zoom: 2x, 4x Extra Tele Conversion: Still Image: Max. 2x (Not effective with L size recording. Magnification ratio depends on the recording pixels and aspect ratio.) / Motion Image: 2.4x, 3.6x, 4.8x (Magnification ratio depends on the recording quality and aspect ratio.) Other Functions: Guide Lines (3 patterns) / Real-time Histogram |
| Level Gauge |
Yes |
| Vertical Shooting Detection |
Yes |
| Photo Style |
Still Image and Motion Image: Standard / Vivid / Natural / Monochrome / Scenery / Portrait / Custom |
| Creative Control Still Image |
Expressive / Retro / High Key / Low Key / Sepia / Dynamic Monochrome / Impressive Art / High Dynamic / Cross Process / Toy Effect / Miniature Effect / Soft Focus / Star Filter / One Point Color |
| Creative Control Motion Image |
Expressive / Retro / High Key / Low Key / Sepia / Dynamic Monochrome / Impressive Art / High Dynamic / Cross Process / Toy Effect / Miniature Effect / One Point Color |
| Creative Video Mode Exposure Mode |
Program AE / Aperture-Priority / Sutter-Priority / Manual Exposure |
| Creative Video Mode Slow and Fast Motion |
40% / 48% / 80% (Records 0.4 times, 0.48 times, 0.8 times slower) 160% / 200% / 300% (Records 1.6 times, 2.0 times, 3.0 times faster) (1,920 x 1,080, 24p, 24Mbps in MOV, MP4, AVCHD) |
| Playback Mode |
Normal playback, 30-thumbnail display, 12-thumbnail display, Calendar display, Zoomed playback (Max. 16x), Slideshow (All / Picture Only / Video Only / 3D / Category Selection / Favorite, duration & effect is selectable), Playback Mode (Normal / Picture / Video / 3D Play / Category / Favorite), Title Edit, Text Stamp, Video Divide, Resize, Cropping, Rotate, Favorite, DPOF Print Set, Protect, Face Recognition Edit |
| Image Protection / Erase |
Protection: Single / Multi, Cancel Erase: Single / Multi / All / Except Favorite |
| Print |
Direct Print: PictBridge compatible |
| USB |
USB 2.0 High Speed |
| HDMI |
mini HDMI TypeC Video: Auto / 1080p / 1080i / 720p / 480p (576p in PAL system) Audio: Dolby Digital |
| Audio Video Output |
Monaural Type, NTSC / PAL, NTSC only for North America |
| Remote Input |
2.5mm for remote |
| External Microphone Input |
3.5mm for external microphone |
| Headphone Output |
3.5mm for headphone |
| Microphone |
Stereo, Wind-cut: OFF / Low / Standard / High / Auto |
| Speaker |
Monaural |
| OSD Language |
English, German, French, Italian, Spanish, Polish, Czech, Hungarian, Russian, Chinese (Traditional), Chinese (Simplified), Dutch, Thai, Korean, Turkish, Portuguese, Arabic, Persian, Japanese, Swedish, Danish, Finnish, Greek, Vietnamese |
| Battery |
Li-ion Battery Pack (7.2V, 1,860mAh) (Included) Battery Charger |
| Battery Life |
Approx. 540 images with H-HS12035 Approx. 500 images with H-VS014140 |
| Operating Temperature |
32 to 104°F (0 to 40°C) |
| Software |
PHOTOfunSTUDIO 8.5 PE SILKYPIX Developer Studio 3.1 SE LoiLoScope (trial version) |
| Dimensions |
5.23 x 3.68 x 3.23" (132.9 x 93.4 x 82.0mm) excluding protrusions |
| Weight |
Approx. 19.40 oz (550g) SD card, Battery, Body Approx. 16.58 oz (470g) Body only Approx. 30.16 oz (855g) SD card, Battery, H-HS12035 lens included Approx. 35.62 oz (1,010g) SD card, Battery, H-VS014140 lens included |
