| Camera Type |
Digital HybridILC |
| Sensor |
Type: 1/2.3"Backlit CMOS w/ primary color filter Effective pixels: 12.4MP Total pixels: 12.76MP |
| JPEG Recorded Resolution |
[4:3] 12M (4000x3000), 9M (3456x2592), 5M (2688x2016), 3M (1920x1440) [3:2] 10M (4000x2664), 8M (3456x2304), 5M (2688x1792), 2M (1920x1280) [16:9] 9M (4000x2248), 6M (3456x1944), 4M (2688x1512), 2M (1920x1080) [1:1] 9M (2992x2992), 6M (2592x2592), 4M (2016x2016), 2M (1440x1440) |
| RAW Recorded Resolution |
[4:3] 12M (4000x3000) |
| Movie Recorded Resolution |
Full HD (1920x1080, 16:9, 30fps), HD (1280x720, 16:9, 30fps), VGA (640x480, 4:3, 30fps) Quality Levels: RAW (12bit): DNG, JPEG: Best, Better, Good RAW and JPEG simultaneously recordable |
| LCD Monitor |
Type: 3.0-inch TFT color LCD monitor, wide angle viewing LCD resolution: 460,000 dots Adjustable: Brightness and Color Field of View: approx. 100% Display info: Grid display (4x4 Grid, Golden Section, Scale display), Bright/dark area warning, Histogram |
| Focus System |
Type: Contrast detection AF Autofocus Method: Face Detection, Tracking, AF Select (25 Points), Select, Spot Focus Method: AF / MF Switching Brightness Range: EV1 to 18 (ISO100) AF Assist Light: Dedicated LED Lamp Manual Focus Assist: OFF/x2/x4 |
| Flash |
Type: Built-in retractable P-TTL flash Guide number: approx. 4.9 (ISO100/m) / approx. 7 (ISO200/m) Angle of view: coverage: wide angle-lens, equivalent to 28mm in 35mm format Flash modes: P-TTL, Red-eye Reduction, Slow-speed Sync, Trailing Curtain Sync Sync Speed: Lens shutter: 1/2000 seconds, Electronic shutter: 1/13 seconds Flash Exposure Compensation: -2.0 to +1.0 EV |
| Storage Media |
Removable memory: SD, SDHC, SDXC |
| Interfaces |
Ports: USB 2.0 (high-speed compatible) / AV output terminal, HDMI output terminal (Type D) Video out: NTSC, PAL USB Connection: MSC / PTP |
| Image Stabilization |
Still: Sensor shift Shake Reduction |
| Metering System |
Type: TTL image sensor metering, segment metering, center-weighted metering, spot metering
Exposure compensation: EV1 - 17 (ISO 100, F1.9 lens), +2EV using the Electronic Shutter setting or using the built-in ND filter |
| ISO Sensitivity |
AUTO: ISO 100 to 6400 (1/3 EV steps) Bulb mode: up to ISO 1600 |
| White Balance |
AutoTTL by CMOS image sensor Preset: Daylight, Shade, Cloudy, Fluorescent Light (D: Daylight Color, N: Daylight White W: Cool White, L: Warm White), Tungsten, Flash, CTE, Manual Manual: Configured on the monitor Fine Adjustment: Adjustable ±7 steps on A-B axis or G-M axis |
| Shutter |
Type: Lens shutter: 1/2000 - 30 seconds (1/3EV step, 1/8000 - 30 seconds when Electronic Shutter setting is enabled), Bulb Shooting at 1/8000 - 2 seconds with Electronic Shutter and Bulb shooting are not available when using a lens that has no lens shutter. |
| Mode Selection |
Auto Picture, Program, Manual, USER, Movie, Blur Correction, Av, Tv, Scene: (Portrait, Landscape, Macro, Moving Object, Night Scene Portrait, Sunset, Blue Sky, Night Scene, Night Scene HDR, Night Snap, Forest, Surf & Snow, HDR, Backlight Silhouette, Kids, Pet, Quick Macro, Food, Candlelight, Stage Lighting, Museum) |
| Green Simplified Mode |
Yes |
| Face Detection |
Yes |
| Digital Filters |
Image Tone: (Bright, Natural, Portrait, Landscape, Vibrant, Radiant, Muted, Bleach Bypass, Reversal Film, Monochrome, Cross Processing) |
| Dynamic Range Adjustment |
Highlight and Shadow correction |
| Interval Shooting |
Shooting interval: 1 sec. to 24 hr., Start Interval setting: immediately from the set time. Number of shots: up to 999 images |
| Drive Modes |
Single frame, Continuous (Hi, Lo), Self-timer (12s, 2s), Remote Control (0 sec., 3 sec., continuous), Auto Bracketing (3 frames, remote control) Continuous Shooting: Approx. 5 fps, JPEG (12M / Best / Continuous Hi): up to 5 frames,, approx. 1.5 fps, JPEG (12M / Best / Continuous Lo): up to 100 frames Self-timer: Yes (12 sec, 2 sec) Remote control: Yes |
| Playback Modes |
Playback View:Single frame, multi-image display (4, 9, 20, 42, 90 segmentation), display magnification (up to 16x, scrolling and quick magnification available), rotating, histogram (Y histogram, RGB histogram), bright/dark area warning, detailed information |
| Playback Filters |
Monochrome, Toy Camera, High Contrast, Shading, Slim, HDR, Invert Color, Extract Color, Color, Water Color, Posterization, Fish-eye, Retro, Soft, Sketch Filter, Miniature, Frame Composite, Starburst, Base Parameter Adjustment |
| Playback RAW Developement |
File Format (JPEG), Aspect Ratio, Color Space, Custom Image, White Balance, Sensitivity, High-ISO NR, Shadow Correction, Distortion Correction |
| Playback Edit |
Resize, Cropping (aspect ratio adjustment available), Index, Movie Editing (divide or deleteselected frames), Capturing a JPEG still picture from a movie, Red-eye Edit, Saving buffer as a RAW file |
| File Formats |
Resize, Cropping (aspect ratio adjustment available), Index, Movie Editing (divide or deleteselected frames), Capturing a JPEG still picture from a movie, Red-eye Edit, Saving buffer as a RAW file |
| File Formats |
Still: RAW (DNG), JPEG (Exif 2.3), DCF2.0 compliant Movie: MOV AVC/H.264(.mov) Sound: Built-in monaural microphone |
| Computer Requirements |
Windows: Windows XP/Vista/7, USB port Mac: MacOS-X 10.4, 10.5, 10.6, USB port (For device connectivity. Bundled software requirements may vary) |
| Language Support |
English, French, German, Spanish, Portuguese, Italian, Dutch, Danish, Swedish, Finnish, Polish, Czech, Hungarian, Turkish, Greek, Russian, Korean, Traditional Chinese, Simplified Chinese, and Japanese |
| Body Construction |
Reinforced polycarbonate plastic |
| Battery |
Battery: Rechargeable Lithium-ion Battery D-LI68 Number of recordable images: approx. 250 images (with 50% flash usage), approx. 270 images (without flash usage) |
| Operating Temperature |
32 to 104°F (0 to 40°C) |
| Dimensions WxHxD |
4 x 2.3 x 1.3" (102 x 58 x 33mm) |
| Weight |
6.35 oz (180g) without battery 7 oz (200g) loaded and ready |
| Specs for 02 Lens |
Focal length: 5-15mm (27.5-83.0mm equiv) Mount: Q-mount AOV: 6.0-29.0° Blades: 5 MOD: 11.8" (entire zooming range) Max Magnification: Approx 0.06X Objective cap: Lens Front Cap O-LC40.5 Aperture ring: n/a Diaphragm control: Fully automatic Lens construction: 8 elements in 7 groups Aperture: F2.8-4.5 Minimum aperture: F8 Filter Diameter: 40.5mm Dimensions: 1.9 x 1.9" Weight: 3.4 oz
|
