| Self-timer |
Off / 10sec. / 2sec./ portrait 1 / portrait 2 |
| Shutter Speeds |
iAuto (2" - 1/1600) / Program Auto (1" - 1/1600) |
| Burst Mode |
Approx. 10 fps at 16.2MP (Maximum 10 shots) |
| AF Modes |
9 points AF (Under Face Undetected) / Center Weighted AF / Spot AF/ Flexible Spot AF (touch) |
| AF Illuminator |
Auto / Off |
| Diopter Adjustment |
No |
| Anti Motion Blur |
Yes |
| Embedded GPS |
Yes |
| Sweep Panorama |
Intelligent Sweep Panorama / 3D Sweep Panorama / Sweep Multi Angle |
| Face Detection |
8 Faces (Auto / Touch - Selected Face Memory / Child Priority / Adult Priority/ Off) |
| Smile Shutter technology |
Yes |
| Image Stabilization |
Optical SteadyShot Image Stabilization |
| In-Camera Editing |
Trimming / Red Eye Correction / Unsharp Masking |
| Intelligent Auto |
Yes |
| Shooting Tips |
Yes |
| Background Defocus |
Yes |
| Waterproof |
No |
| Dustproof |
No |
| Shockproof |
No |
| Superior Auto |
Yes |
| Tracking Focus |
Off / Auto |
| Blink Detection |
Yes |
| Flash Modes |
Auto / On / Slow Syncro / Off |
| Flash Coverage |
ISO Auto: Approx. 0.08m-Approx. 5.1m (Approx. 0.26'-Approx. 16.73') (W) / Approx. 0.5m-Approx. 4.0m (Approx. 1.64'-Approx. 13.12') (T), ISO3200: up to Approx. 7.2m (Approx. 23.62) (W) / Approx. 5.7m (Approx. 18.70') (T) |
| Media Type |
Optional "Memory Stick Duo" (No movie recording), optional "Memory Stick PRO Duo" (Mark 2 only for movie recording), optional "Memory Stick PRO-HG Duo", optional SD Memory Card (Class 4 or higher), optional SDHC Memory Card (Class 4 or higher), optional SDXC Memory card (Class 4 or higher) |
| Still Image Mode |
JPEG |
| Still Image Max Effective Resolution |
Approx. 16.2 Megapixels |
| Still Image Size 16:9 |
12M (4,608 x 2,592) / 2M (1,920 x 1,080) |
| Still Image Size 3:2 |
No |
| Still Image Size 4:3 |
16M (4,608 x 3,456), 10M (3,648 x 2,736), 5M (2,592 x 1,944), VGA (640 x 480), 3D: 16M (4,608 x 3,456) / 16:9 (12M) (4,608 x 2,592) |
| Panorama Still Image Size |
2D: 7,152 x 1,080 (238deg) / 4,912 x 1,080 (163deg) / 4,912 x 1,920 (172deg) / 3,424 x 1,920 (120deg), 3D: 7,152 x 1,080 (238deg) / 4,912 x 1,080 (163deg) / 4,912 x 1,920 (172deg) / 3,424 x 1,920 (120deg) / 1,920 x 1,080 (64deg) |
| Sweep Multi Angle Image Size |
1,920 x 1,080 (15views) |
| Video Format |
AVCHD 60i / 60p / MP4 |
| Video Mode |
1,920 X 1,080 (PS) Approx. 28Mbps Approx. 60fps Progressive 1,920 X 1,080 (FX) Approx. 24Mbps Approx. 60fps interlace 1,920 X 1,080 (FH) Approx. 17Mbps Approx. 60fps interlace 1,440 X 1,080 (HQ) Approx. 9Mbps Approx. 60fps interlace 1,440 x 1,080 Approx. 12Mbps Approx. 30fps, Progressive 1,280 x 720 Approx. 6Mbps Approx. 30fps, Progressive 640 x 480 (VGA) Approx. 3Mbps Approx. 30fps, Progressive |
| Photo Capture from Movie |
Yes |
| Dual Record |
Yes |
| Audio Format |
Dolby Digital (AC-3) / MPEG-4 AAC-LC |
| Microphone/Speaker |
Stereo / Mono |
| Memory Card Slot |
MS Duo and SD/SDHC/SDXC Compatible |
| SD Output |
Yes |
| HD Output |
HDMI / Component (1080i) |
| USB Port(s) |
Yes - Multi Use Terminal |
| Party Shot Compatible |
Yes |
| TransferJet |
Send: Yes (Single / Select, U2 Version), Receive: Yes (U2 Version) |
| PictBridge Compatible |
No |
| Imaging Sensor |
1/2.3" (7.77mm) "Exmor R" CMOS sensor |
| Processor |
BIONZ |
| Pixel Gross |
16.8MP |
| Effective Picture Resolution |
16.2MP |
| Color Filter System |
RGB primary color filters |
| LCD Type |
3.5" OLED XtraFine with TruBlack technology (1,229,760 pixels) |
| Angle Adjustment |
No |
| Brightness Control |
5 steps |
| Histogram |
No |
| Grid Display |
Yes (Off / On) |
| Software |
Supplied Software: Windows PMB (Picture Motion Browser) Ver. 5.5, PMB Portable |
| Metering Modes |
Multi Pattern / Center Weighted / Spot |
| Exposure Compensation |
Plus / Minus 2.0EV, 1 / 3EV step |
| Scene Mode(s) |
High Sensitivity / Twilight / Twilight Portrait / Soft Snap / Landscape / Beach / Snow / Fireworks / Hi-Speed Shutter / Underwater/ Gourmet / Pet / Soft Skin / Handheld Twilight / Anti Motion Blur / Backlight Correction HDR |
| D-Range Optimizer |
Standard |
| ISO |
Auto / 125 / 200 / 400 / 800 / 1600 / 3200 |
| Noise Reduction |
Clear RAW NR / NR Slow Shutter |
| White Balance Mode |
Auto / Daylight / Cloudy / Fluorescent 1 (White Fluorescent Lighting) / Fluorescent 2 (Natural White Fluorescent Lighting) / Fluorescent 3 (Day White Fluorescent Lighting) / Incandescent / Flash / One Push |
| Battery Type |
LITHIUM ION NP-BN1 3.6V |
| Battery Capacity |
Typical: 2.3Wh (630mAh), minimum: 2.2Wh (600mAh) |
| Power Requirements |
AC Adaptor: AC 100V to 240V, 50/60 Hz, 70mA |
| Power Consumption (in Operation) |
Approx. 1.0W |
| Red-Eye Reduction |
Auto / On / Off |
| Erase/Protect |
Single / Select / Date / Folder / AVCHD |
| Media/Battery Indicator |
Yes / Yes |
| Power Save Mode |
Standard / Stamina / Off |
| Lens Type |
Carl Zeiss Vario-Tessar |
| Aperture |
iAuto (F3.5-F6.3 (W)) / Program Auto (F3.5-F6.3 (W)) |
| Aperture (Max.) |
F3.5 (W)-4.6 (T) |
| Optical Zoom |
4x |
| Digital Zoom |
Smart Zoom / Precision Digital Zoom / Off |
| Smart Zoom Technology |
10M: Approx. 5.1x (Total), 5M: Approx. 7.1x (Total), VGA: Approx. 28x (Total), 16:9 (2M): Approx. 9.6x (Total) |
| Focal Length (35mm equivalent) |
Still 16:9: 27-108mm / Still 4:3: 25-100mm / Movie 16:9: 27-108mm / Movie 4:3: 33-132mm |
| Filter Diameter |
No |
| Lens Construction |
12 elements in 10 groups (including 6 aspheric elements,1 prism) |
| Minimum Focus Distance |
iAuto(W:-1cm(0.39'') to Infinity, T:-50cm(1.64') to Infinity)/Program Auto(W:-8cm(0.26') to Infinity, T:-50cm(1.64') to Infinity) |
| Aspheric Elements |
6 |
| HD Output |
HDMI |
| Dimensions (W x H x D) |
3 7/8" x 2 3/8" x 23/32" (97.0mm x 58.5mm x 17.8mm) |
| Weight |
5.2 oz (147g)
4.6oz. (131g) (Main unit only) |
