| Camera type |
Interchangeable-lens digital camera with built-in flash |
| Lens compatibility |
Sony A-mount lenses, operation with Minolta/Konica Minolta lenses confirmed |
| Image sensor Type |
APS-C size (23.5 x 15.6 mm), Exmor APS HD CMOS sensor with primary color filters |
| Number of pixels (effective) |
Approx. 16.1 megapixels |
| Number of pixels (total) |
Approx. 16.7 megapixels |
| Image sensor aspect ratio |
'3:2 |
| Anti-dust system |
Charge protection coating on Low-Pass Filter and Image Sensor-Shift mechanism |
| Recording format: Still |
JPEG (DCF Ver. 2.0, Exif Ver. 2.3, MPF Baseline compliant), RAW (Sony ARW 2.3 format), 3D MPO (MPF Extended compliant) |
| Image size: Still (3:2 aspect ratio) |
L: 4912 x 3264 (16M), M: 3568 x 2368 (8.4M), S: 2448 x 1624 (4.0M) |
| Image size: Still (16:9 aspect ratio) |
L: 4912 x 2760 (14M), M: 3568 x 2000 (7.1M), S:2448 x 1376 (3.4M) |
| Image size: Still (Sweep Panorama) |
Wide: horizontal 12,416 x 1,856 (23M), vertical 5,536 x 2,160 (12M), Standard: horizontal 8,192 x 1,856 (15M), vertical 3,872 x 2,160 (8.4M) |
| Image size: Still (3D Sweep Panorama) |
Wide: 7152 x 1080 (7.7M), Standard: 4912 x 1080 (5.3M), 16:9: 1920 x 1080 (2.1M) |
| Image quality modes |
RAW, RAW & JPEG, JPEG Fine, JPEG Standard |
| Picture Effect |
11 modes (15 effects): Posterization (Color, B/W), Pop Color, Retro Photo, Partial Color (R,G,B,Y), High Contrast Monochrome, Toy Camera, Soft High-key, Soft Focus, HDR Painting, Rich-tone Monochrome, Miniature |
| Creative Style |
Standard, Vivid, Portrait, Landscape, Sunset, B/W (Contrast -3 to +3 steps, Saturation -3 to +3 steps, Sharpness -3 to +3 steps) |
| Dynamic range functions |
Off, Dynamic Range Optimizer (Auto/Level), Auto High Dynamic Range: Off, Auto Exposure Difference, Exposure Difference Level (1-6 EV, 1.0 EV step) |
| Color space |
sRGB, Adobe RGB |
| Recording format: Movie |
AVCHD 2.0 (Progressive) / MP4 |
| Video compression |
MPEG-4 AVC (H.264) |
| Audio recording format |
Dolby Digital (AC-3) / MPEG-4 AAC-LC |
| Image size (movie): NTSC |
AVCHD: 1920 x 1080 (60p/28Mbps/PS, 60i/24Mbps/FX, 60i/17Mbps/FH, 24p/24Mbps/FX, 24p/17Mbps/FH) MP4: 1440 x 1080 (30fps/12Mbps), VGA: 640 x 480 (30fps/3Mbps) |
| Image size (movie): PAL |
AVCHD: 1920 x 1080 (50p/28Mbps/PS, 50i/24Mbps/FX, 50i/17Mbps/FH, 25p/24Mbps/FX, 25p/17Mbps/FH) MP4: 1440 x 1080 (25fps/12Mbps), VGA: 640 x 480 (25fps/3Mbps) |
| Media |
Memory Stick PRO Duo, Memory Stick PRO-HG Duo, SD memory card, SDHC memory card, SDXC memory card |
| Slot |
Memory Stick Duo/ SD memory card |
| Noise reduction |
"Long exposure NR: On/Off, available at shutter speeds longer than 1 sec. High ISO NR: High/Normal/Low |
| Multi frame noise reduction |
Auto/ISO 100 to 25600 |
| White balance mode |
Auto WB, Daylight, Shade, Cloudy, Incandescent, Fluorescent (Warm white/Cool white/Day white/Daylight), Flash, C. Temp 2500 to 9900K, C Filter G7 to M7, 15-step, Custom, AWB micro adjustment |
| Two-axis fine adjustment |
Available in all modes |
| Bracketing |
3 frames, H/L selectable |
| Focus Type |
TTL phase-detection AF |
| Focus sensor |
CCD line sensors |
| Focus point |
15 points (3 points cross type) |
| Sensitivity range |
EV -1 to 18 (at ISO100 equivalent with F2.8 lens attached) |
| Focus mode |
Autofocus, Manual Focus |
| AF mode |
Single-shot AF (AF-S), Continuous AF (AF-C), Automatic AF (AF-A) selectable |
| Focus area |
Wide (auto,15 points), Zone, Spot, Local |
| Metering type |
1200-zone evaluative metering |
| Metering sensor |
Exmor APS HD CMOS sensor |
| Metering sensitivity |
EV -2 to EV 17 (at ISO 100 equivalent with F1.4 lens attached) |
| Metering Modes |
Multi segment, Center weighted, Spot |
| Exposure modes |
iAUTO, Flash Off, Superior Auto, Scene Selection, Sweep Panorama, 3D Sweep Panorama, Continuous Advance Priority AE, Movie, Programmed AE (P), Aperture priority (A), Shutter-speed priority (S), Manual (M) |
| Scene Selection |
Portrait, Landscape, Macro, Sports Action, Sunset, Night Portrait, Night View, Hand-held Twilight |
| Exposure compensation |
±3.0 EV (1/3 EV steps) |
| AE bracketing |
Bracket: Cont., Bracket: Single, with 1/3 EV, 2/3 EV increments, 3 frames |
| AE lock |
Available with AE lock button. AE is also locked when focus is locked in multi-segment metering mode |
| ISO sensitivity (Exposure Index) |
ISO 100-16000 equivalent, AUTO (ISO 100-3200 ) |
| Viewfinder Type |
SVGA 1.2 cm (0.46 type) electronic viewfinder (color), Xtra Fine |
| Viewfinder: Total number of dots |
1,440,000 dots equivalent |
| Effective number of dots |
Maximum: 1,440,000 dots equivalent, Standard: 1,253,280 dots equivalent |
| Viewfinder: Brightness control |
Auto / Manual (3 steps between -1 and +1) |
| Viewfinder: Field coverage |
100% |
| Magnification |
Maximum: Approx. 1.04x, Standard: Approx. 0.97x |
| Diopter adjustment |
-4.0 to +3.0 m-1 |
| Eye point |
"Maximum: 23.1mm from the eyepiece, 18 mm from the eyepiece frame at -1 diopter (CIPA standard) Standard: 25.2 mm from the eyepiece, 20.1mm from the eyepiece frame at -1 diopter (CIPA standard) |
| Viewfinder Display |
Histogram Display, Graphic Display, Digital Level Gauge, Shooting Data Display, Simple Display, Grid Line |
| Real-time image adjustment display |
Exposure Comp, White Balance, Creative Style |
| LCD Type |
Xtra Fine, 7.5 cm (3.0 type) TFT drive with TruBlack technology |
| LCD: Total number of dots |
921,600 dots |
| LCD: Brightness control |
Auto/Manual (5 steps between -2 and +2) |
| LCD: Field coverage |
100% |
| Adjustable angle |
Tilt angle: Downward 180 degrees. Rotation angle: Leftward 270 degrees from the position in which the LCD monitor is facing forward |
| Display Selector (finder/LCD) |
Auto/Manual |
| LCD Display |
Histogram Display, Graphic Display, Digital Level Gauge, Shooting Data Display, Simple Display, Shooting Information For Viewfinder, Grid Line |
| LCD: Real-time image adjustment display |
Exposure Comp, White Balance, Creative Style |
| Focus Magnifier |
4.8x, 9.5x |
| Peaking MF |
Yes (Level: High/Mid/Low/Off, Color: White/Red/Yellow) |
| Zoom |
Clear Image Zoom: Still images 2x Smart Zoom (still images) M: 1.4x, S: 2x Digital Zoom (still images) 4x Digital Zoom (movie) 4x |
| Shutter Type |
Electronically controlled, vertical-traverse, focal-plane type |
| Shutter speed |
1/4000 second to 30 seconds, Bulb |
| Flash sync. speed |
1/160 second |
| Electronic front curtain shutter |
Yes, On/Off |
| SteadyShot INSIDE: System |
For still images: Image Sensor-Shift mechanism, For movies: Electronic |
| SteadyShot capability |
For still images: Approx. 2.5-4.5 EV decrease in shutter speed (varies according to shooting conditions and lens used) |
| Flash Type |
Auto popup, built-in |
| Guide No. |
10 (in meters at ISO 100) |
| Coverage |
FOV coverage up to 18 mm (in the focal length) |
| Control |
ADI flash / Pre-flash TTL |
| Compensation |
±2.0 EV (1/3 EV steps) |
| Flash Bracketing |
1/3 EV, 2/3 EV steps, 3 frames |
| Modes |
Flash off, Autoflash, Fill-flash, Rear sync., Slow Sync., Red-eye reduction (On/Off) |
| Recycling time |
Approx. 3 sec |
| External flash |
Sony alpha System Flash compatible with Auto-lock accessory shoe |
| Wireless control |
Yes (wireless flash with lighting ratio control) |
| Drive modes |
Single Shot, Continuous (Hi/Lo), Self-timer (10/2 sec. delay), Bracketing (Cont., Single, White Balance), Remote Control (with optional RM-DSLR1) |
| Continuous shooting speed |
Hi: Maximum 8 frames per second, Lo: Maximum 3 frames per second Tele-zoom Continuous Advance Priority AE: Maximum 12 images per second Continuous Advance Priority AE: Maximum 10 images per second |
| Max. continuous shots |
Tele-zoom Continuous Advance priority AE: Fine: 23 images, Standard: 25 Continuous Advance Priority AE mode: Fine: 23 images, Standard: 27 images, RAW & JPEG: 18 images, RAW: 21 images Continuous shooting: Fine: 25 images, Standard: 29 images, RAW & JPEG: 19 images, RAW: 21 images |
| Playback mode |
Single (with or without shooting information), RGB histogram and highlight/shadow warning, 4/9-frame index view, Enlarged display mode (L: 13.6x, M: 9.9x, S: 6.8x), Auto Review (10/5/2 sec, Off), Image orientation (On/Off), Slideshow, Panorama scrolling, Folder selection (still), Forward/Rewind (movie), Delete, Protect |
| PC interface |
Hi-speed USB (USB 2.0): Mass-storage, MTP |
| HD output |
HDMI mini connector (Type-C), BRAVIA Sync (link menu), PhotoTV HD |
| Other interface |
Sync. Terminal, Auto-lock accessory shoe, Microphone jack, DC IN terminal, Remote terminal |
| Compatible OS (USB connection) |
Windows XP SP3, Windows Vista SP2, Windows 7 SP1, Mac OS X (10.3-10.6) |
| Microphone |
Built-in stereo microphone or ECM-ALST1 / ECM-CG50 (sold separately) |
| Speaker |
Built-in, monaural, volume settings in 8 steps |
| Print Compatible standards |
Exif Print, Print Image Matching III, DPOF setting |
| Battery |
Rechargeable battery pack NP-FM500H |
| Still images |
Approx. 550 shots with viewfinder and 590 shots with LCD monitor (CIPA standard) |
| Movies |
Approx. 180 min. with viewfinder and 180 min. with LCD monitor |
| Operating temperature |
0deg.C to 40deg.C (32deg.F to 104deg.F) |
| Dimensions |
Approx. 132.1 x 97.5 x 80.7 mm (5-1/4 x 3-7/8 x 3-1/4 in.) |
| Weight |
With battery and Memory Stick PRO Duo: Approx. 618 g (1 lb 5.7 oz) Body only: Approx. 539 g (1 lb 2.9 oz) |
