| Frequency Range (-10 dB) |
34 Hz - 20 kHz |
| Frequency Response (±3 dB) |
40 Hz - 18 kHz |
| Coverage Pattern |
60deg. x 60deg., rotatable waveguide |
| Directivity Factor (Q) |
14.5 |
| Directivity Index (DI) |
11.6 dB |
| Crossover Modes |
Bi-amp/Passive switchable |
| Passive Crossover Frequency |
1.4 kHz |
| Transducer Power Rating (AES) |
LF: 1000 W (4000 W peak), 2 hrs
750 W (3000 W peak), 100 hrs
HF: 100 W (400 W peak), 2 hrs |
| Long-Term System Power Rating (IEC) |
Passive mode: 600 W (2400 W peak), 100 hrs |
| Maximum SPL |
Bi-amp mode:
LF: 128 dB-SPL cont avg (134 dB peak)
HF: 134 dB-SPL cont avg (140 dB peak)
Passive mode:
124 dB-SPL cont avg (130 dB peak) |
| System Sensitivity (1W @ 1m) |
Passive mode: 96 dB SP |
| Transducers: Low Frequency Driver |
1 x JBL 2265H 380 mm (15 in) Differential Drive driver with 75 mm(3 in) dual voice coil |
| LF Nominal Impedance |
8 ohms |
| LF Sensitivity |
98 dB SPL (1W @ 1m within operational band) |
| Transducers: High Frequency Driver |
JBL 2432H, 38 mm (1.5 in) exit compression driver, 75 mm (3 in) voice coil |
| HF Nominal Impedance |
8 ohms |
| HF Sensitivity (1W @ 1m) |
114 dB SPL |
| Waveguide |
PT-H66HF-1 |
| Enclosure |
Trapezoidal with 15 degree side angles, 16 mm (5/8 in) exterior grade 11-ply Finnish birch plywood |
| Suspension Attachment |
15 points (4 top, 4 bottom, 2 each side, 3 rear), M10 threaded hardware |
| Grille |
Powder coated 14 gauge perforated steel, with acoustically transparent black foam backing |
| Input Connector |
NL4 Neutrik Speakon and CE-compliant covered barrier strip terminals. Barrier terminals accept up to 5.2 sq mm (10 AWG) wire or max width 9 mm (.375 in) spade lugs. Speakon in parallel with barrier strip for loop-through |
| Environmental Specifications |
Mil-Std 810; IP-x3 per IEC529 |
| Dimensions (H x W x D) |
781 x 420 x 503 mm / 30.8 x 16.5 x 19.8 inches |
| Weight |
27.2 kg (60 lb) |
