| Form Factor |
Micro tower |
| Processor |
AMD Phenom II X4 B97 / 3.2 GHz |
| Processor: Number of Cores |
Quad-Core |
| Processor: 64-bit Computing |
Yes |
| Processor: Installed Qty |
1 |
| Processor: Max Supported Qty |
1 |
| Cache |
L2 - 4 x 512KB |
| Processor Main Features |
HyperTransport |
| Cache Memory: Type |
L3 cache |
| Cache Memory: Installed Size |
6MB |
| Cache Per Processor |
6MB |
| Chipset Type |
AMD 785G |
| RAM: Installed Size |
4GB / 16GB (max) |
| RAM: Technology |
DDR3 SDRAM - non-ECC |
| RAM: Memory Speed |
1333 MHz |
| RAM: Memory Specification Compliance |
PC3-10600 |
| RAM: Form Factor |
DIMM 240-pin |
| RAM: Configuration Features |
2 x 2GB |
| Storage Controller: Type |
1 x Serial ATA - integrated |
| Storage Controller: Interface Type |
Serial ATA-300 |
| Hard Drive |
1 x 500GB - standard - Serial ATA-300 - 7200 rpm - Native Command Queuing (NCQ) |
| Optical Storage: Type |
DVD±RW (±R DL) / DVD-RAM - Serial ATA |
| Optical Storage: Read Speed |
40x (CD) / 16x (DVD) |
| Optical Storage: Write Speed |
40x (CD) / 16x (DVD±R) / 12x (DVD±R DL) |
| Optical Storage: Rewrite Speed |
32x (CD) / 6x (DVD-RW) / 8x (DVD+RW) / 12x (DVD-RAM) |
| Graphics Controller: Type |
Integrated |
| Graphics Processor |
ATI Radeon HD 4200 shared video memory (UMA) |
| Graphics Controller: Digital Video |
DisplayPort |
| Audio Output: Type |
Sound card - integrated |
| Audio Output: Sound Output Mode |
Stereo |
| Audio Output: Max Sample Rate |
192 kHz |
| Audio Output: Compliant Standards |
High Definition Audio |
| Input Device |
Mouse, keyboard |
| Keyboard Interface |
USB |
| Mouse: Technology |
Optical |
| Mouse: Interface |
USB |
| Networking |
Network adapter - integrated |
| Networking: Ethernet Controller(s) |
Broadcom BCM5761 |
| Networking: Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| Networking: Remote Management Protocol |
DMI 2.0, ASF 2.0 |
| Networking: Compliant Standards |
IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x |
| Expansion Bays |
2 (total) / 1 (free) x front accessible - 5.25" x 1/2H
1 (total) / 1 (free) x front accessible - 3.5" x 1/3H
2 (total) / 1 (free) x internal - 3.5" x 1/3H |
| Expansion Slot(s) |
4 (total) / 2 (free) x memory - DIMM 240-pin
1 (total) / 1 (free) x PCI - full-height
2 (total) / 2 (free) x PCI Express x1 - full-height
1 (total) / 1 (free) x PCI Express x16 - full-height
1 (total) / 0 (free) x processor - Socket AM3 |
| Interfaces 1 |
10 x Hi-Speed USB - 4 pin USB Type A ( 4 front, 6 rear )
1 x audio - line-in - mini-phone stereo 3.5 mm
1 x audio - line-out - mini-phone stereo 3.5 mm
1 x headphones - output - mini-phone stereo 3.5 mm ( 1 in front )
1 x microphone - input - mini-phone stereo 3.5 mm ( 1 in front )
1 x mouse - generic - 6 pin mini-DIN (PS/2 style)
1 x keyboard - generic - 6 pin mini-DIN (PS/2 style) |
| Interfaces 2 |
1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45
1 x serial - RS-232 - 9 pin D-Sub (DB-9)
1 x display / video - VGA - 15 pin HD D-Sub (HD-15)
1 x audio / video - DisplayPort - 20 pin DisplayPort
1 x parallel |
| Compliant Standards |
ACPI, RoHS, WEEE |
| Power: Device Type |
Power supply |
| Power: Voltage Required |
AC 120/230 V ( 50/60 Hz ) |
| Power: Power Provided |
320 Watt |
| OS Provided |
Microsoft Windows 7 Professional 64-bit Edition (Upg to Win 8 Professional at $14.99) |
| Microsoft Office Preloaded |
Includes a pre-loaded image of select Microsoft Office 2010 suites. Purchase an Office 2010 Product Key Card or disc to activate preloaded software on this PC. |
| OS Certified |
Red Hat Enterprise Linux, SUSE Linux Enterprise Desktop 11 |
| EPEAT Compliant |
EPEAT Gold |
| ENERGY STAR Qualified |
Yes |
| Min Operating Temperature |
50 deg.F |
| Max Operating Temperature |
95 deg.F |
| Humidity Range Operating |
10 - 90% (non-condensing) |
| Embedded Security |
Trusted Platform Module (TPM 1.2) Security Chip |
| Dimensions (W x D x H) |
7 x 17 x 14.8" (17.8 x 43.18 x 37.5 cm) |
| Weight |
20.5lbs (9.3 kg) |
