| Image Device |
3-CCD, 1/4" progressive sensors with diagonal offset technology |
| Signal System |
HQ mode, 1920 x 1080 (35 Mb/s VBR, MPEG-2 MP@HL)
1080/60i, 1080/50i, 1080/30p, 1080/25p, 1080/24p, 720/60p, 720/50p, 720/30p, 720/25p, 720/24p
SP mode, 1440 x 1080 (CBR, 25 Mb/s, MPEG-2 MP@H-14)
1080/60i, 1080/50i
SP mode, 1280 x 720 (CBR, 19 Mb/s, MPEG-2 MP@H-14/HL)
720/60p, 720/50p, 720/30p, 720/25p, 720/24p
SD Video, 720 x 480 (DV compression, 25 Mb/s, 4:1:1, 8-bit)
480/60i |
| Video Codec |
MPEG-2 Long GOP |
| File Format |
QuickTime for Final Cut Pro (HD/SD)
MP4 (HD)
AVI type 2 (SD) |
| Lens |
Fujinon 10x lens, 3.7-37mm (39-390mm 35mm equivalent) f/1.8-2.8 |
| Filter Diameter |
46mm (no hood)
Screw pitch: 0.75mm
72mm (hood attached - filters only; no tele converters or wide converters)
Screw pitch: 0.75mm |
| Built-in Filters |
Neutral Density: 1/10, Off |
| Stabilization |
Optical image stabilizer |
| Sync System |
Internal synchronization (built-in SSG) |
| Minimum Illumination |
5 lux (typical, 1920 x 1080 mode, f/1.8, +18 dB, with 16-frame accumulation) |
| LCD Monitor |
2.8", 230,000 pixels, 16:9, color |
| Viewfinder |
0.24", LCOS, 260,000 pixels, 16:9, color |
| Memory Card Slot |
2x SDHC (Class 6/10) / SDXC |
| Shutter Speed Range |
1/3.75-1/10000, EEI |
| Gain Selection |
0 dB, 3 dB, 6 dB, 9 dB, 12 dB, 15 dB, 18 dB, LoLux, AGC |
| Maximum Recording Time |
With 2x 64GB SDXC cards in 35 Mb/s mode: Approx. 400 minutes |
| Audio Signal Format |
Linear PCM 2-channel, 48 kHz/16-bit |
| Input and Output Connectors |
Composite Video Out (480i, 4:3/16:9): 1x 3.5mm mini jack
Component Video Out (480i/720p/1080i): 1x multi-pin cable
HDMI Out (480i/720p/1080i): 1x HDMI Type A
Analog Audio In: 2x XLR, mic (+48V) / line
Analog Audio Out: 1x 3.5mm mini jack
Headphone Out: 1x 3.5mm mini jack
Remote Control In: 1x 3.5mm mini jack
USB 2.0: 1x USB Mini-B |
| Power Requirements |
7.8V DC (with battery)
11V DC (with AC adapter) |
| Power Consumption |
7.8W (with VF and LCD screen backlight set to Standard) |
| Operating Temperature |
32 to 104 Deg.F (0 to 40Deg.C) |
| Storage Temperature |
-4 to 122Deg.F (-20 to 50Deg.C) |
| Operating Humidity |
30-80% |
| Storage Humidity |
Under 85% |
| Dimensions (W x H x D) |
5.5 x 7.1 x 14.5" (13.8 x 17.9 x 36.6 cm) |
| Weight |
3.1 lb (1.4 kg) including battery, microphone, cards |
