Kingston Technology E100 Specifications

  • Capacity

    200GB

  • Form Factor

    2.5"

  • Interface

    SATA Rev. 3.0 (6Gb/s)
    SATA Rev. 2.0 (3Gb/s)
    SATA Rev. 1.0 (1.5Gb/s)

  • Security

    Self-encrypting drive

  • Sequential Reads

    SATA Rev. 3.0: 535MB/s
    SATA Rev. 2.0: 270MB/s

  • Sequential Writes

    SATA Rev. 3.0: 500MB/s
    SATA Rev. 2.0: 255MB/s

  • Sustained Random 4k Read/Write

    59,000/72,000 IOPS

  • Maximum Random 4k Read/Write

    59,000/73,000 IOPS

  • Power Consumption

    Idle: 0.5W (TYP)
    Read: 1.2W (TYP)
    Write: 3.1W (TYP)

  • Storage temperature

    -40 - 85deg.C

  • Operating temperature

    0 - 70deg.C

  • MTBF

    10,000,000 Hrs

  • Total Bytes Written (TBW)

    857TB

  • Dimensions

    69.9 x 100 x 7 mm / 2.75" x 3.94" x 0.28"

  • Weight

    96.6 g / 3.41 oz

About Kingston Technology E100

The Kingston Technology SSDNow E100 200 GB Enterprise-Class E100 Internal SSD is ideal for mission-critical environments such as datacenters, which need to be up and running 24 hours a day, 7 days a week. E100 combines impressive endurance and reliability with power fail support to ensure uninterrupted operation.

E100 offers 10x endurance over typical client SSDs, with 30K program/erase cycles on E100 vs. 3K program/erase cycles on client SSDs. It features a SF-2500 enterprise class processor, DuraWrite for maximum read/write performance and endurance and RAISE for advanced error correction.

E100's power fail support uses Tantalum capacitors so existing writes are committed and/or retired during a power loss to prevent any data loss. The capacitors can hold a charge at temperatures up to 85 degrees. Additionally, the drive shuts down properly during unexpected power interruptions.

With read/write performance delays often associated with large data sets, E100 helps solve these IO latency bottlenecks in servers. It enables larger enterprise virtualization projects by increasing the number of virtual systems supported using the existing hardware infrastructure.

Kingston Technology E100 Features

  • Boost performance, productivity and endurance
  • Power Fail support for data integrity protection on critical server applications
  • Higher IOPS for multi-user environments
  • Data Integrity Protection featuring DuraClass Technology
  • RAISE for advanced data reliability
  • Self-encrypting drive
  • DuraWrite optimizes writes to extend endurance

Key Features

  • Boost performance, productivity and endurance
  • Power Fail support for critical server applications
  • Higher IOPS for multi-user environments
  • Data Integrity Protection featuring DuraClass Technology
  • RAISE for advanced data reliability
  • Self-encrypting drive
