| Magnification | 10 x |
| Front lens diameter | 42 mm |
| Exit pupil | 4.2 mm |
| Twilight factor | 20.5 |
| Field of view at 1,000 m | 110 m |
| Field of view at 1,000 yds | 331 ft |
| Eye-relief | 15.6 mm |
| Objective angle of view | 6.3° |
| Close focusing distance | Approx. 5.6 m/18.4 ft |
| Diopter compensation | ± 3.5 diopters |
| Distance measurement Range | 10 m to approx. 1,300 m/10 yds to approx. 1,400 yds |
| Distance measurement Accuracy | ± 1 m/yd up to 350 m/380 yds
± 2 m/yds up to 700 m/763 yds
± 0.5 % beyond 700 m/763 yds |
| Read-outs | LED display with four digits, easily legible in any light |
| Eyepieces for eyeglass wearers | Yes |
| Sliding eyecups | Yes, removable, with two click stops |
| Adjustable interpupillary distance | 56-74 mm |
| Focusing | Internal focusing via central focusing device |
| No. of lens elements (each side) | 7, with Leica AquaDura coating |
| Prism system | Roof prism with phase correction coating P40 |
| Watertightness | Watertight to a depth of 5 m/16.5 ft |
| Housing | Die-cast aluminium, nitrogen-filled |
| Meter / Yard selector | No |
| Laser | Eye-safe invisible laser according to EN and FDA class1 |
| Laser beam divergence | 2.5 x 0.5 mrad |
| Measuring time | Max. approx. 1.4 s |
| Measuring mode | Scanning mode |
| Power supply | 1 x 3V/Lithium-type C2R |
| Battery lifetime | Approx. 2,000 measurements at 20°C/68°F |
| Neopren carrying strap, contoured | Included |
| Dimensions (W x H x D) | 125 x 168 x 70 mm / 4-7/8 x 6-5/8 x 2-3/4 in |
| Weight | Approx. 945 g/33.3 oz incl. batteries |
| Warranty | Leica warranty |
| | |
