| Magnification | 15 x |
| Front lens diameter | 56 mm |
| Exit pupil | 3.7 mm |
| Twilight factor | 28.2 |
| Field of view at 1,000 m | 75 m |
| Field of view at 1,000 yds | 225 ft |
| Eye-relief | 15.5 mm |
| Objective angle of view | 4.3° |
| Close focusing distance | Approx. 5.9 m/19.4 ft |
| Diopter compensation | ± 4 diopters |
| Distance measurement Range | 10 m to approx. 1,300 m/10 yds to approx. 1,400 yds |
| Distance measurement Accuracy | ± 1 m/yd up to 366 m/400 yds
± 2 m/yds up to 732 m/800 yds
± 0.5 % beyond 732 m/800 yds |
| Read-outs | LED display with four digits, easily legible in any light |
| Eyepieces for eyeglass wearers | Yes |
| Sliding eyecups | Yes, removable, with two click stops |
| Adjustable interpupillary distance | 56-74 mm |
| Focusing | Internal focusing via central focusing device |
| No. of lens elements (each side) | 7, with AquaDura coating |
| Prism system | Roof prism with phase correction coating P40 |
| Watertightness | Watertight to a depth of 5 m/16.5 ft |
| Housing | Die-cast aluminium, nitrogen-filled |
| Meter / Yard selector | No |
| Laser | Eye-safe invisible laser according to EN and FDA class1 |
| Laser beam divergence | 2.5 x 0.5 mrad |
| Measuring time | Max. approx. 1.4 s |
| Measuring mode | Scanning mode |
| Power supply | 1 x 3V/Lithium-type C2R |
| Battery lifetime | Approx. 2,000 measurements at 20°C/68°F |
| Neopren carrying strap, contoured | Included |
| Dimensions (W x H x D) | 134 x 210 x 70 mm / 51/4 x 71/8 x 25/8 in |
| Weight | Approx. 1,300 g / 45.9 oz incl. batteries |
| Warranty | Leica warranty |
| | |
