| Magnification |
8 x |
| Front lens diameter |
42 mm |
| Exit pupil |
5.3 mm |
| Twilight factor |
18.3 |
| Geometric light value |
17.64 |
| Field of view at 1000 m |
126 m |
| Field of view at 1000 yds |
322 ft |
| Objective angle of view |
7.2Deg. |
| Eye-relief |
15.5 mm |
| Close focusing limit |
3.5 m/11.5 ft |
| Diopter compensation |
± 4 diopters |
| Eyepieces for eyeglass wearers |
Yes |
| Eye cup |
Removable, with 4 detent positions |
| Adjustable interpupillary distance |
55-75 mm |
| Focusing |
Internal focusing using center spindle |
| Number of lenses (per side) |
10, with HDC multi-layer coating |
| Prism system |
Roof prism system with P40 phase correction coating and HLS HighLux system |
| Water tightness |
Impermeable to press water up to 5 m deep |
| Housing |
Cast magnesium with nitrogen filling |
| Dimensions (W x H x D) |
121 x 142 x 67 mm (4.8 x 5.6 x 2.6 in) |
| Weight |
810 g (28.6 oz) |
