| Screen Size (Class) |
32" class (31.5" measured diagonally) |
| Native Display Resolution |
1366 x 768 |
| Dynamic Contrast Ratio |
60000:1 |
| Viewing Angle |
178deg./178deg. |
| Color Reproduction |
10 Bit |
| Response Time (G to G) |
4ms |
| True Viewing Angle |
Yes |
| Life Span (Typical) |
60,000 hrs |
| Analog |
Yes |
| ATSC/NTSC/Clear QAM |
Yes |
| MPEG4 |
Yes |
| Aspect Ratio |
16:9 |
| Aspect Ratio Correction |
6 Modes (16:9/Just scan/Set by program/4:3/Zoom/Cinema Zoom) |
| Color Temperature Control |
3 Modes (Cool/Medium/Warm) |
| Picture Status Mode |
7 Modes (Vivid/Standard/Cinema/ Sport/Game/Expert 1/Expert 2) |
| Just Scan (0% over scan) |
HDMI: 1080i/1080p/720p
Component: 1080i/1080p/720p
RF/DTV: 1080i/720p |
| 24p Real Cinema (24p 5:5/2:2 Pull down) |
Yes |
| Eye Care (Anti Dazzling) |
Yes |
| Expert Mode/ ISF Ready |
Yes |
| Picture Wizard |
Yes |
| AV Mode (Cinema/Game/Sport) |
Yes |
| xvyCC |
Yes |
| DTV Signal Strength |
Yes |
| Audio Output |
10W x 2 |
| Invisible Speaker System Details |
1 Way 2 Speaker |
| Dolby Digital 5.1 Decoder |
Yes |
| Surround System Type |
Infinite Sound |
| Bass/Treble/Balance Controls |
Yes |
| Auto Volume Leveler |
Yes |
| EZ Sound Mode/SSM |
5 Modes |
| Clear Voice II |
Yes |
| XD Engine |
Yes |
| Energy Saving Modes |
Yes (Backlight Control, Video Mute) |
| EPG(SI) |
Yes (Pro:Centric) |
| Yes (Pro:Centric) |
Yes HDMI/Component (60/30/24p), RGB (WXGA) |
| A/V Input Navigation |
Yes |
| Input Labeling/Sub-title |
Yes |
| LG SIMPLINK (HDMI CEC) |
Yes |
| Parental Control w/V-Chip |
Yes |
| Key Lock/Child Lock |
Yes |
| Customizable Closed Caption/Sub-title |
Yes |
| Splash Image - Logo (on start up) |
Yes |
| Multi Remote IR code (Bed1/2/3/4) |
Yes |
| Auto-Sensing RJP compatible |
Yes (with select RJP versions) |
| Bed 1/Bed 2/ Bed 3/ Bed 4 Control |
Yes |
| TVLink-Protocol (Tuner, Loader) |
Yes |
| USB Cloning (USB Link Loader) |
Yes |
| 1080p Source Input |
HDMI: 60p/30p/24p
Component: 60p/30p/24p
RGB: WXGA |
| Quick View (Flashback) |
Yes |
| e-Streamer |
Yes (for shop mode) |
| OSD Language |
4 (English/Spanish/French/Korean) |
| Quick Menu (Round Type-8 menus) |
Yes (Aspect Ratio/SAP/ Picture Mode/ Sound Mode/Audio/Sleep Timer/Ch Add/USB Eject) |
| Alvin UI |
Yes |
| Function Menu |
Yes |
| Installation Menu |
Yes (v2.6) |
| Auto Tuning/Programming |
Yes |
| Channel Add/Delete |
Yes |
| Favorite Channel Programming |
Yes |
| Auto/Manual Clock |
Yes |
| On/Off Timer |
Yes |
| Sleep Timer |
Yes |
| Auto Off/Auto Sleep |
Yes (When no video is present) |
| RF In (Antenna/Cable) |
1 |
| L/R Audio/Composite Video In |
1 (rear), 1 (side) |
| HD Component Video In |
1 (Y, Pb, Pr) + L/R Audio |
| Digital Audio Out (Optical) |
1 |
| HDMI/HDCP Input (V1.3 with Deep Color) |
1 (side), 1 (rear) |
| RGB In (D-Sub 15pin) - PC |
1 (1920 x 1080) |
| PC Audio Input |
1 |
| RS-232c In (Control/Service) |
1 |
| USB 2.0 Input |
1 (side) Media Host (JPEG, MP3), Cloning and Service |
| Remote Control Port In |
1 |
| RJ45 (for RJP interface - non PIP) |
1 |
| Swivel Stand (degrees) |
+20deg./-20deg. |
| Top Side Mounting Screw |
Yes |
| TORX Security Screw (2 each) |
Yes |
| Power Indicator |
Yes (on/off) |
| Fire Retardant Cabinet Material |
Yes |
| Kensington Security System Slot |
Yes |
| VESA Mount Compatible |
Yes |
| Remote Control |
Yes |
| Voltage, Hz |
100V - 240V, 50/60 Hz |
| Stand-by Mode (typ.) |
0.2W (EPA 4.0) |
| Power Consumption Max |
180W |
| Power Consumption Typical |
78W |
| Dynamic Power Savings |
Yes |
| Static Power Savings |
Yes |
| RoHS Compliant |
Yes |
| UL, cUL, NOM |
Yes |
| Dimensions (W x H x D) |
TV without stand: 31.5" x 19.9" x 2.9"/80.01 x 50.54 x 7.36 cm
TV with stand: 31.5" x 21.9" x 8.1"/80.01 x 55.62 x 20.57 cm |
| Weight |
TV without stand: 17.9 lbs/8.11kg
TV with stand: 20.1 lbs/9.11kg |
