Lorex Eco Blackbox3 Stratus 4 Channel 960H Network 500GB DVR, Up to 4TB Maximum Capacity, H.264 Video Compression

See all Lorex items
SKU: LRXH03045G MFR: LH03045G
Lorex Blackbox3: Picture 1 thumbnail Lorex Blackbox3: Picture 2 thumbnail Lorex Blackbox3: Picture 3 thumbnail Lorex Blackbox3: Picture 4 thumbnail

Our Price

Buy more and save
Quantity Discount

The quantity discount will be reflected in your shopping cart

About Lorex Blackbox3

Watch over your world from anywhere in the world delivering true peace of mind with Lorex Eco Blackbox3 Stratus 4 Channel 960H Network 500GB DVR. Featuring Stratus Connectivity innovative hassle-free cloud connection, this device allows you to quickly and easily remotely connect to your smartphone, tablet, PC or Mac. Download the free App, scan the QR code and start viewing your world securely online. Compatible with iOS and Android devices.

It is optimized for use with 960H compatible cameras. Industry leading 960H (960x480) recording resolution ensures high quality live-viewing and recording. A 34% increase over standard D1 resolution (DVD quality) and a 500% increase over CIF, gives a sharper, undistorted image with a true-to-life aspect ratio with no stretched image. The DVR is also backwards compatible and supports different camera inputs: standard resolution and 960H.

The Record in real-time to the specialty 100% duty-cycle hard drive is designed for surveillance, providing weeks or even months of reliable video. Customize the recording settings to fit your needs. Record at 960H (960x480) for highest resolution or set to a lower resolution for extended recording time.

It connects the ECO BlackBox3 to a TV, PC, or CCTV monitors with industry standard HDMI, VGA & BNC inputs. The intuitive interface with simple icons allows for easy & efficient security DVR programming.

Lorex Blackbox3 Features

  • Tablet / smartphone viewing and playback
  • Lorex Stratus Connectivity - 3 step setup
  • Superior 960H Resolution - 34% more detailed and true-to-life images
  • HDMI cable included for simple connection to HDTVs
  • 24/7 security-grade hard drive
  • Instant email alerts with snap shot attachment
  • Continuous, scheduled and motion recording
  • Advanced mobile apps with live viewing, playback, video recording and snap shot
  • PC and Mac compatible
  • H.264 video compression
  • 3 video outputs (HDMI, VGA and BNC) to connect multiple monitors
  • Pentaplex operation - view, record, playback, back up & remotely control the system simultaneously
  • PTZ cameras supported (RS485) remotely control through App
  • Accurate time stamps with NTP & Daylight Savings Time
  • Automatic firmware upgrade over the Internet ensures your system is secure and up to date

Lorex Blackbox3 Specifications

Operating System
Linux (embedded)
Pentaplex Operation
Simultaneous View, Record, Playback, Backup & Remote Monitoring
Number of Channels
Input & Output
Video IN: 8 x 1Vpp, CVBS, 75 ohms, BNC
Video OUT: 2 x BNC
Audio IN: 1 Line in(RCA), G.711
Audio OUT: 1 line out(RCA), G.711
USB Port: 1 at the back, 1 at the front
Alarm IN: Without Alarm
Video Output: 800 x 600, 1024 x 768, 1280 x 1024, HDMI (1920x1080)
PTZ Control
RS-485 Pelco D & P Protocol
Live Display
1, 4,
Live Display Speed
120 NTSC, 100 PAL
On / Off
System Navigation
USB mouse, IR remote controller
Motion Area Setting
Adjustable grid (10 x 15) NTSC
Adjustable grid (12 x 15) PAL
Sensitivity Levels
Firmware Upgrade
Via USB device & network
User Authority
By user group
Time Synchronization
Auto time sync by NTP server
Video Compression
Audio Compression Format
Recording Resolution
NTSC: 360 x 240 (CIF), 720 x 240 (HD1), 720 x 480 (D1))
PAL: 360 x 288 (CIF), 720 x 288 (HD1), 720 x 576 (D1)
Recording Speed
240 / 200 (NTSC / PAL) at CIF, 120 / 100 (NTSC / PAL) at HDI, 60 / 50 (NTSC / PAL) at D1
Recording Resolution Setting
Per camera for different resolutions (CIF / 2CIF / D1)
Recording Quality Control
3 levels
Recording Schedule
By hour, by day, by recording mode, by motion, by channel
Pre Recording
Maximum 10 sec
Post Recording
Maximum 5 minutes
WatchDog, auto-recovery after power failure
Covert Video
Playback Channel
1 to 8 adjustable
Playback Speed
Variable: 16 x (maximum)
Playback Players
Backup Player
By time & event
Log Search
Up to 1,000,000 lines for motion detected, configuration changes, connects / disconnects and video loss
Audio Play
Up to 1 HDD (SATA)
Maximum Capacity
Up to 2 TB
Backup Media
USB Flash Drive & HDD
Backup File Format
H.264 file (AVI generator included)
Easy Connect
Lorex Auto Port Forward Wizard
Supported Operating Systems
WindowsXP, Vista, 7; Mac OSX Snow Leopard 10.6; or above
Remote Software
Client Software (PC) & Safari (Mac)
Email Notification
Text with snapshot
Instant Smart Phone Compatibility
iPad, iPhone, Android
System Configuration
Full setup configuration over network
Lorex DDNS
Programmable by user
Network Protocol
Network Interface
10/100-Base-TX, RJ-45
Network Speed Control
48 Kb to 8 Mb/sec
Power Consumption
Approximately 15 W (HDD pre-installed)
Supply Voltage
100 to 240 VAC, 12 VDC, 2 A, 50/60 Hz
Operating temperature
32deg. - 104deg. F /0deg. - 40deg. C
10 -90% NC
Dimensions (W x D x H)
11.80 x 8.60 x 1.90" (299.72 x 218.44 x 48.26mm)
2.20lbs (1kg)
