| DVR: Operating System |
Linux (embedded) |
| DVR: Pentaplex |
Simultaneous View, Record, Playback, Backup & Remote Monitoring |
| DVR: Number of Channels |
4 Channel |
| DVR: Inputs/Outputs |
Video IN: 4/8x 1Vp-p, CVBS, 75ohms, BNC/DIN
Video OUT: 2 x BNC
VGA OUT: Yes
Audio IN: 4 Line in(RCA), ADPCM(4&8 ch)
Audio OUT: 2 line out(RCA), ADPCM(4&8 ch)
USB Port: 2 at the back
PTZ control: RS-485 Pelco D & P Protocol |
| DVR: Live Display |
4 ch: 1,4 |
| DVR: Live Display Speed |
120 (4 ch) NTSC
100 (4 ch)PAL |
| DVR: OSD |
ON/OFF |
| DVR: System Navigation |
USB Mouse, IR Remote Controller, Front Panel |
| DVR: Motion Area Setting |
Adjustable grid (10 x15) NTSC
Adjustable grid (12 x15) PAL |
| DVR: Sensitivity levels |
8 |
| DVR: Firmware Upgrade |
Via USB device |
| DVR: User Authority |
By user group |
| DVR: Time Synchronization |
Auto time sync by NTP server |
| DVR: Video Compression |
H.264 |
| DVR: Audio Compression |
ADPCM |
| DVR: Recording Resolution |
NTSC: 360x240 (CIF), 720x240 (HD1), 720x480 (D1)
PAL: 360x288 (CIF), 720x288 (HD1), 720x576 (D1) |
| DVR: Recording Speed |
4 ch: 120/100 (NTSC/PAL) @ CIF, 60/50(NTSC/PAL) @ HD1, 30/25 (NTSC/PAL) @ D1 |
| DVR: Recording Resolution Setting |
Per camera for different resolutions (CIF/2CIF/D1) |
| DVR: Recording Quality Control |
3 levels |
| DVR: Image Size |
768-1536 Kbyte (D1), 512-768 Kbyte (HD1), 384-512 Kbyte (CIF) |
| DVR: Recording Schedule |
By hour, by day, by recording mode, by alarm, by ch |
| DVR: Pre Recording |
Max. 10 Secs |
| DVR: Post Recording |
Max. 5 Minutes |
| DVR: Reliability |
Watch-Dog, Auto-recovery after power failure |
| DVR: Covert Video |
Yes |
| Wireless Camera: Imaging Sensor Type |
CMOS |
| Wireless Camera: Picture Total Pixels |
640 x 480pxl (NTSC) |
| Wireless Camera: Minimum Illumination |
0 Lux (IR on) |
| Wireless Camera: Night Vision Distance |
60ft / 18m |
| Wireless Camera: Lens |
5.1mm, F2.8 |
| Wireless Camera: View Angle |
Diagonal 48deg. |
| Wireless Camera: Consumption Current |
200mA (Max.) |
| Wireless Camera: Power Supply |
12V DC |
| Wireless Camera: Environment Rating |
P66 |
| Wireless Receiver: Resolution Supported |
640 x 480 @ 12fps or 320 x 240 @ 25fps |
| Wireless Receiver: Receiving Sensitivity |
-81dBm |
| Wireless Receiver: Consumption Current |
200mA (Max.) |
| Wireless Receiver: Power Supply |
12V DC |
| Transmission Frequency |
ISM 2,400-2,480 MHz |
| Transmission Power |
16dBm |
| Unobstructed Effective Range |
450ft / 137m Outdoor / 150ft / 46m Indoor |
| Spread Spectrum |
FHSS |
| Modulation Mode |
GFSK |
| Operating Temperature |
14 to 122deg. Fahrenheit / - 10 to +50deg. Celsius |
| Operating Humidity |
30-90% RH |
| Playback Channel |
1,4 (4 ch) |
| Playback Speed |
Variable Max 16x |
| Playback Players |
Backup Player |
| Search |
By time & event |
| Log Search |
Up to 10,000 lines for user login/out, configuration changes, remote access, connects/disconnects |
| Audio Play |
Yes |
| Storage |
Up to 1 HDD's (SATA) |
| Maximum Capacity |
Up to 2TB |
| Backup Media |
USB Flash Drive & HDD |
| Backup File Format |
H.264 file (AVI generator included) |
| Easy Connect |
Lorex Auto Port Forward Wizard |
| Supported Operating Systems |
Windows XP, Vista, 7
Mac OSX Snow Leopard 10.6 |
| Browsers |
Internet Explorer & Safari 5.0 |
| Email notification |
Text with snapshot |
| Instant Smart Phone Compatibility |
Instant Smart Phone Compatibility on iPhone, BlackBerry (supported model numbers: 9700, 9000), Android (version 1.5 & above), Window Mobile (6.0, 6.5), Symbian 3rd & 5th generation phones. |
| DDNS |
Lorex DDNS |
| System Configuration |
Full setup configuration over network |
| Ports |
Programmable by User |
| Network Protocol |
LAN, DHCP, Dynamic IP, DDNS |
| Network Interface |
10/100-Base-TX, RJ-45 |
| Network Speed Control |
48Kb - 8MB/sec. |
| Dimensions (W x D x H) |
Wireless Camera: 75mm x 120mm x 220mm / 3.0" x 4.7" x 8.7" (with antenna)
Wireless Receiver: 18mm x 93mm x 170mm / 0.7" x 3.7" x 6.7" (with antenna attached) |
| Weight |
Wireless Camera: 0.3kg / 0.6lbs
Wireless Receiver: 0.1kg / 0.2lbs |
