Lexicon PCM96SUR-B Specifications

  • Digital Audio I/O: Connectors

    6, XLR AES/EBU

  • FireWire Ports: Format

    FireWire (400Mb)

  • FireWire Ports: Word Size

    24 bits

  • Sample Rates: Internal

    44.1kHz, 48kHz, 88.2kHz, 96kHz

  • Sample Rates: Accuracy

    within +/-50ppm

  • Sample Rates: External

    44.1kHz, 48kHz, 88.2kHz, 96kHz

  • Sample Rates: Lock Range

    +/-2% of nominal

  • Synchronization: TTL Word Clock Input

    75 Ohm, BNC

  • Clock Jitter: Intrinsic

    Exceeds AES3 Amendment 1

  • Clock Jitter: Gain

    Exceeds AES3 Amendment 1

  • Control Interface: MIDI

    In/Out/Thru

  • Memory Card

    Compact Flash Type I Can hold up to 2048 user presets

  • Internal non-volatile Flash

    Can hold 1024 user presets.

  • Operating Temperature

    15Deg. to 35Deg. C

  • Storage Temperature

    -30Deg. to 70Deg. C

  • Humidity Temperature

    75% relative humidity max

  • Rack Units

    1U

  • Computer System Requirements

    Hardware
    Macintosh Power PC G5 1.8 GHz or any Intel
    Mac OS X 10.4.11 or higher
    Standard 10/100 Ethernet
    Firewire 400 (800 works with adapter)
    1 GB RAM
    150 MB free HD space
    CD-ROM drive
    Software
    Nuendo 4
    Cubase 4
    Digital Performer 8
    ProTools LE 7.3.1
    ProTools HD 7.3, 7.4 & 8.0
    Logic 8.0

  • Software Compatibility

    Mac OS X 10.4.x
    Mac OS X 10.5.x
    Mac OS X 10.6.x

  • Dimensions (W x H x D)

    19.0" x 1.75" x 16" / 483mm x 44.5mm x 406.4mm

  • Weight

    14.25 lbs / 6.46 kg

About Lexicon PCM96SUR-B

The Lexicon PCM96SUR-B is a parallel stereo and surround hardware reverb/effects processor that builds on the success of the PCM96, while once again providing a blend of both heritage and innovation. The processor delivers 50 legendary Lexicon reverbs, delays and modulation effects, as well as new pitch algorithms and a new Surround Room.

The addition of multi-mode filters at several spots in the audio flow provides new capabilities to Lexicon's traditional reverbs by allowing more exact shaping of the reverb, while still maintaining the distinctive Lexicon sound. All reverbs also have an "Infinite" switch that allows the reverb to run forever, a useful feature for creating unusual backgrounds and sound effects for post.

For Mac users, the unit can function as a control-only insert, or FireWire streaming audio plug-in inside any VST, Audio Units or RTAS software. With 6 channels of digital input/output, as well as MIDI, Ethernet and FireWire connectivity, the PCM96 Surround easily fits into a variety of recording and post production sound environments.

Lexicon PCM96SUR-B Features

  • Parallel stereo and surround reverb processor built on a rich heritage of processing that includes the 480L and 960L, along with the PCM series, but designed for the modern studio environment
  • 6 channel digital I/O
  • Includes 50 legendary Lexicon reverbs, delays and modulation effects
  • Surround algorithm, used to generate a vast array of room-related effects for music and post
  • Pitch algorithms
  • Over 2,200 factory presets, including recognizable classics from Lexicon's immense library of sounds
  • Seamless automation and control via Ethernet or FireWire
  • Hardware Plug-In capability inside Mac VST, Audio Units or RTAS production software
  • 32-bit floating point processing
  • Sample rates up to 96kHz
  • External BNC Wordclock input
  • MIDI In, Out and Thru
  • Compact Flash Card compatibility for additional storage

Key Features

  • 6 channel digital I/O
  • Pitch algorithms
  • 32-bit floating point processing
  • Sample rates up to 96kHz
  • External BNC Wordclock input
  • MIDI In, Out and Thru

What's in the box:

  • Lexicon PCM96SUR-B Stereo and Surround Reverb/Effects Processor
  • AC Power Cable
  • Ethernet Cable
  • Software CD-ROM
  • Lexicon Warranty
