Manhattan LCD HD071A2 7.1" HD Professional LCD Monitor with Sony Plate, 1024x600 WXGA Resolution, 400 Nits Brightness, 500:1 Contrast Ratio

Manhattan LCD
SKU: MHD071A2S MFR: HD071A2-S
Manhattan LCD HD071A2: Picture 1 thumbnail Manhattan LCD HD071A2: Picture 2 thumbnail Manhattan LCD HD071A2: Picture 3 thumbnail Manhattan LCD HD071A2: Picture 4 thumbnail Manhattan LCD HD071A2: Picture 5 thumbnail

About Manhattan LCD HD071A2

The Manhattan HD071A2-S 7.1" HD Professional LCD Monitor with Sony plate is designed for field monitoring. This wide screen LCD monitor is full HD compatible with multiple inputs. This monitor has the more advanced Pixelworks chipset it has features such as an Advanced Color Control, True Anamorphic 16:9 aspect ratio, 1:1 Pixel Mapping & is also firmware upgradeable. The panel is 1024 X 600 resolution, matte finish great for outdoors. Sunhood and battery options available.

Manhattan LCD HD071A2 Specifications

LCD Size
7.1"
Contrast ratio
500:1
Brightness
400 Nits
Response Time
25 ms, full on/full off
Viewing Angle (L/R/U/D)
140 / 110 degrees
Controls
Brightness - Contrast - Saturation - Red Green Blue Channel Levels
Fit All - 1:1 (Pixel Mapping) - Normal - Zoom - Anamorphic (16:9) - Wide - Auto
Picture in Picture - On Screen Display - Multi Language - Freeze Frame
Infrared Remote Control - Full Access to OSD
Inputs
HDMI (HDCP) - 2 Inputs, Supports 1080p, 1080i, 720p, 576p, 576i, 480p, 480i
VGA - 1 Input, Supports 640x480/800x600/1024x768/1280x720/1280x768/1280x1024/
1366x768/1920x1080
Component: 1 Input, Supports 1080p, 1080i, 720p, 576p, 576i, 480p, 480i
CVBS (Composite): 1 Input, Support 480i
Power
12v DC, <20 Watts
Tekkeon MP3450 Rechargeable Battery
5 Hour Run Time (Optional)
Power Connector
5.5mm X 2.1mm Barrel Connector
Battery Plate for Sony
2 Hour Run Time
Dimensions (W x H x D)
7.9" x 5.5" x 1.6" (20 x 14 x 4 cm)
Weight
1.5 lbs (0.7 kg)
