| Enclosure Type |
Desktop |
| Data Link Protocol |
Ethernet, Fast Ethernet, IEEE 802.11b, IEEE 802.11g |
| Frequency Band |
2.4 GHz |
| Data Transfer Rate |
54 Mbps |
| Network / Transport Protocol |
TCP/IP, PPTP, L2TP, IPSec |
| Routing Protocol |
RIP-1, RIP-2, static IP routing |
| Remote Management Protocol |
SNMP 1, SNMP 3, SNMP 2c, HTTP |
| Encryption Algorithm |
AES, 128-bit WEP, 64-bit WEP, TKIP, WPA, WPA2, WPA-PSK |
| Built-in Devices |
LED panel |
| Status Indicators |
Power, active, transmit, receive |
| Line Coding Format |
8 QAM, 32 QAM, 128 QAM, DBPSK, DQPSK, CCK, 64 QAM, 256 QAM, 16 QAM |
| Protocols & Specifications |
DOCSIS 2.0 |
| Interfaces |
1 x 10Base-T/100Base-TX - RJ-45 WAN : 1 x input - F connector |
| Antenna |
Internal integrated |
| Antenna Qty |
2 |
| Power Device |
Power adapter - external |
| Voltage Required |
AC 120/230 V ( 50/60 Hz ) |
| Power Consumption Operational |
9 Watt |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.11b, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11e |
| System Requirements |
UNIX, Apple MacOS 9.0 or later, Microsoft Windows Vista / 2000 / XP |
| Dimensions (W x D x H) |
5.7 in x 1.5 in x 5.7 in / 14.4 x 3.81 x 14.4 cm |
| Weight |
14.8 oz / 419.5 g |
