| Magnification |
3x - 9x |
| Objective / Field of View |
40mm / 31.5' (9.6m) @ 3x at 100 yds.(100m), 10.5' (3.2m) @ 9x at 100 yds.(100m) |
| Main (Center) Tube Diameter |
1.0" |
| Objective Tube Diameter |
1-7/8" |
| Eyepiece Tube Diameter |
1-9/16" |
| Lens Coatings |
Fully Multi Coated Optics, up to 21 Layers |
| Reticle |
BDC, Bullet Drop Compensator |
| Reticle Image Plane (Magnifying) |
Not Specified by Manufacturer |
| Exterior Finish |
Matte Black |
| Windage & Elevation Adjustments (MOA) |
1/4" Per Click |
| Maximum Adjustment |
60 MOA W & E |
| Exit Pupil |
13.3mm @ 3x, 4.4mm @ 9x |
| Eye Relief |
4.0" / 101.6mm @ 3x, 4.0" / 101.6mm @ 9x |
| Parallax Correction Control |
100 Yards |
| Diopter Adjustment |
-2 / +1.5 |
| Material |
Aluminum Alloy |
| Nitrogen Filled |
Argon Gas Purged |
| Waterproof / Fogproof |
Yes |
| Length |
12-3/16", (309.5mm) |
| Mounting Length |
5-9/16" |
| Weight |
13.6 oz., 385.6g |
| Special Features |
Long Eye Relief
Assembled in the USA.
Large, Finger Adjustable Windage & Elevation Controls
All Models Packed with the Added Protection of a Scopecoat Cover |
