| Magnification |
2x - 10x |
| Objective / Field of View |
40mm / 47.5' (14.5m) @ 2x at 100 yds.(100m), 9.4' (2.9m) @ 10x at 100 yds.(100m) |
| Main (Center) Tube Diameter |
1.0" |
| Objective Tube Diameter |
1-7/8" |
| Eyepiece Tube Diameter |
1-9/16" |
| Lens Coatings |
Fully Multi Coated Optics, up to 21 Layers |
| Reticle |
MinoPlex |
| Reticle Image Plane (Magnifying) |
Not Specified by Manufacturer |
| Exterior Finish |
Matte Black |
| Windage & Elevation Adjustments (MOA) |
1/4" Per Click |
| Maximum Adjustment |
72 MOA W & E |
| Exit Pupil |
20.0mm @ 2x, 4.0mm @ 10x |
| Eye Relief |
4.0" / 101.6mm @ 2x, 4.0" / 101.6mm @ 10x |
| Parallax Correction Control |
100 Yards |
| Diopter Adjustment |
-2 / +1.5 |
| Material |
Aluminum Alloy |
| Nitrogen Filled |
Argon Gas Purged |
| Waterproof / Fogproof |
Yes |
| Length |
12-3/16", (309.5mm) |
| Mounting Length |
5-9/16" |
| Weight |
12.0 oz., 340.2g |
| Special Features |
Long Eye Relief
Assembled in the USA.
Large, Finger Adjustable Windage & Elevation Controls
All Models Packed with the Added Protection of a Scopecoat Cover |
