Nady HM-1 Specifications

System
  • Type of System

    Dual Channel VHF

  • RF Carrier Frequency Range

    2 channels between 171.905 - 215.200MHz

  • Approx. Working Range

    Up to 250 ft. typical (depending on site conditions)
    Up to 500+ feet optimum line-of-sight

  • Overall Frequency Response

    25Hz - 20kHz, +/-3dB

  • Total Harmonic Distortion (THD)

    < 0.3 %

  • Frequency Stability

    +/- 0.005%, crystal controlled

  • Modulation

    FM (F3E), +/-20kHz max

Receiver

Jump to...
  • Type of Outputs

    Dual balanced XLR and unbalanced adjustable 1/4" audio out jacks (Ch A & B mixed)
    2.1mm barrel-type DC input jack

  • Power Requirements

    12V @ 400mA, nominal, AC/DC adapter supplied

  • Display

    Power ON, Dual 5-LED RF & AF level displays(Ch A/B)

  • Antenna Type

    11.2" (28.5 cm), dual telescopic

  • Dimensions

    1.75 x 7.5 x 8.1" (4.4 x 19 x 20.7cm)

  • Weight

    1.6 lbs (0.73kg)

WLT Bodypack

Jump to...
  • Type of Transmitter

    Nady WLT Bodypack

  • Type of Microphone

    LM-14O Lavalier Microphone

  • Polar Pattern

    Omnidirectional

  • Battery Type/Approx. Life

    Battery: 9V Alkaline
    Battery Life: Up to 15 hours

  • Mute Switch

    Off/On Switch

  • Display

    Low-battery LED

  • Dimensions

    4.1 x 2.4 x 0.8" (10.4 x 6.1 x 2.0cm)

  • Weight

    3.6 oz (101g)

  • Element

    Dynamic (UM-4)

  • Polar Pattern

    Cardioid (Unidirectional)

  • Frequency Response

    100 Hz to 15 kHz

  • Sensitivity

    -78 dB +/-3 dB (@1 kHz, 74 dB SPL)

  • Impedance

    800 Ohm +/-30% @ 1 kHz

  • Cable Length

    52" (1300 mm)

  • Dimensions

    5.66" (144mm) nominal at widest point
    3.74" (95mm) flexible boom, 0.19" (4.40mm) diameter

  • Weight

    1.65 oz (46.20g) (With cable)

0 Accessories for Nady Dual Channel VHF HM-1 Uni Dynamic Headset Wireles System with Encore Duet Receiver, 2x WLT Headset TX & 2x HM-1 Mic

About Nady HM-1

The Nady Dual Channel VHF HM-1 Uni Dynamic Headset Wireless System is an ideal choice for musicians, presenters, fitness instructors, and other performers who need a hands-free microphone system. The system features two channels, allowing you to connect two microphones simultaneously, making it perfect for duets or interviews. The included HM-1 Uni Dynamic Headset Microphone is comfortable and lightweight, ensuring that you can wear it for extended periods without discomfort. The microphone is also unidirectional, which means it picks up sound from one direction and rejects noise from other directions, ensuring that your voice is heard loud and clear. The VHF wireless system operates on a stable frequency range, providing reliable performance with minimal interference. The Nady Dual Channel VHF HM-1 Uni Dynamic Headset Wireless System is easy to set up and use, making it a great choice for beginners and professionals alike.

Nady HM-1 Features

  • Loaded with top professional operating features
  • Available on selected frequencies in the VHF high-band (171-216 MHz) for interference-free, long-range performance
  • Half-rack receiver design with retractable front panel antenna(s)
  • RF and AF 5-LED displays for monitoring incoming signal strength and audio level
  • Balanced XLR and unbalanced adjustable 1/4" jack outputs (Encore Duet: Dual XLR and single mixed 1/4" outputs)
  • Unique snap-out panel locking tabs for single receiver or dual receiver (side-by-side) optional rack mounting
  • Nady's proprietary DigiTRU Diversity digital processing circuitry to eliminate dropouts and maximize operating range (Encore II)
  • Noiseless transmitter ON/OFF switching
  • This Version Encore Duet VHF wireless system

Key Features

  • Loaded with top professional operating features
  • Available on selected frequencies in the VHF high-band
  • Half-rack receiver design with retractable front panel antenna(s)
  • RF and AF 5-LED displays
  • Balanced XLR & unbalanced adjustable 1/4" jack outputs
  • Balanced XLR and unbalanced 1/4 output jacks

What's in the box:

  • VHF Dual Channel Encore Duet Receiver
  • AC-E1X Power Supply
  • 2x HM-1 Unidirectional Dynamics
  • 2x WLT Bodypack Headset Transmitters
  • 9 Volt Battery
  • 6' Connecting Cord
  • Nady 1 Year Limited Warranty
