| Viewable Image Size |
19" |
| Aspect Ratio |
5:4 |
| Native Resolution |
1280 x 1024 |
| Pixel Pitch |
0.29mm |
| Pixels Per Inch |
86@ native resolution |
| Backlight Type |
CCFL |
| Brightness (typical) |
250cd/m2 |
| Contrast Ratio (typical) |
1500:1 |
| Viewing Angle (typical) |
170deg. Vert., 176deg. Hor. (85U/85D/88L/88R) @ CR>5 |
| Response Time (typical) |
25ms |
| Displayable Colors |
More than 16.7 million |
| Synchronization Range: Horizontal |
31.5-81.1 kHz (Analog/Digital) |
| Synchronization Range: Vertical |
56-75 Hz |
| Input Signal: Video |
Analog RGB 0.7 Vp-p/75 Ohms |
| Input Signal: Sync |
Separate Sync: TTL Level (Positive/Negative) Composite Sync: TTL Level (Positive/Negative) Composite Sync on Green: (0.3Vp-p negative 0.7Vp-p positive) |
| Input Connectors |
DVI-D, VGA 15-pin D-sub |
| Power Consumption (typical) |
On: 35W Power Savings Mode: 2W |
| VESA Hole Configuration |
100 x 100mm |
| Operating Temperature |
41-95deg.F / 5-35deg.C |
| Operating Humidity |
20-80% |
| Operating Altitude |
4572 ft. / 1394m |
| Storage Temperature |
14-140deg.F / -10-60deg.C |
| Storage Humidity |
10-85% |
| Storage Altitude |
40,000 ft. / 12,192m |
| Environmental Compliance |
EPEAT: Silver RoHS: Yes |
| Dimensions (WxHxD) |
With Stand: 16.1 x 15.1-19.4 x 8.7 in. / 408 x 383.5-493 x 220mm Without Stand: 16.1 x 13.3 x 2.6 in. / 408 x 338 x 66mm |
| Weight |
With Stand: 15.4 lbs. / 7 kg Without Stand: 9.7 lbs. / 4.4 kg |
