NEC

NEC Two 21" Color 3-Megapixel Medical Diagnostic Monitors with Graphics Card, 2048x1536 Native Resolution, 12ms Response Time

SKU: NCMDC3MPBNDL MFR: MDC3MP-BNDL
Usually ships in 7-10 Business Days.
Your card will only be charged once item ships.
Why Adorama?
Easy Returns, Fast Shipping, Trusted for over 35 years.

Need help? Call 800-223-2500 212-741-0052

Our Price

$8,090.70
Free Shipping
Qty:

Add to Wishlist

About the NEC Two 21"" Color Filter

Designed for the demanding needs of radiology and PACS, the Radiology Grayscale Display Bundle features two 21.3" NEC MultiSync MD213MC 3MP displays and a graphics card. The high-bright displays boast high resolution and the flexibility of color displays with image performance rivaling that of grayscale displays.

NEC Two 21"" Color Filter Includes

  • NEC Two 21" Color 3-Megapixel Medical Diagnostic Monitors
  • MDA-V5800D Graphics Card
  • Power Cord
  • DVI Cable
  • Setup Sheet
  • CD-ROM (GammaCompMD Software)
  • Stand
  • Cable Cover
  • NEC 5 Years Parts & Labor Limited Warranty

NEC Two 21"" Color Filter Features

  • UA-SFT liquid crystal technology offers high brightness without compromising contrast or viewing angles, making the image quality outstanding for color or grayscale images
  • Out-of-the-box calibration to the DICOM grayscale display function for luminance
  • Integrated tri-stimulus (three-color) sensor receives more light information than standard (brightness only) sensors and, therefore, is extremely accurate and stable
  • ColorComp digital uniformity correction reduces screen uniformity errors and compensates for differences in color/grayscale and luminance across the entire screen
  • GammaComp MD software ensures consistent image quality, while providing a simple interface for conformance to the DICOM standard and an easy-to-use QA environment for medical imaging
  • 12-bit RGB lookup tables (LUTs) for gamma provide for more finely detailed, high-definition rendering of color images and crisper display of even the most delicate shadings and color differences
  • Brightness level and contrast ratio rivals that of grayscale displays

NEC Two 21"" Color Filter Specifications

Viewable Image Size 21.3"
Color Type Color
Native Resolution 2048 x 1536
Pixel Pitch 0.21mm
Pixels Per Inch 120@ native resolution
Brightness (typical) 400 cd/m2 calibrated / 800 cd/m2 max
Contrast Ratio (typical) 750:1
Viewing Angle 176deg. Vert., 176deg. Hor. (88U/88D/88L/88R) @ CR>10
Response Time 12ms
Lookup Table 12-bit
Displayable Colors 1024 shades of gray from a palette of 4096
Sensors Tri-stimulus front
Synchronization Range: Horizontal 31.5-93.8/95.4 kHz (Analog/Digital)
Synchronization Range: Vertical 30-85 Hz
Input Signal: Video Analog RGB 0.7 Vp-p/75 Ohms
Input Signal: Sync Separate Sync: TTL Level (Positive/Negative); Composite Sync: TTL Level (Positive/Negative); Composite Sync on Green: (0.3Vp-p negative 0.7Vp-p positive)
Input/Output Terminals Digital: DVI-D, DVI-I
Power Consumption (typical) On: 105W
Power Savings Mode: 2W
VESA Hole Configuration 100 x 100mm
Operating Temperature 41-95deg.F / 5-35deg.C
Operating Humidity 30-80%
Operating Altitude 9843 ft. / 3000m
Storage Temperature 14-140deg.F / -10-60deg.C
Storage Humidity 10-85%
Storage Altitude 40,000 ft. / 12,192m
Dimensions (WxHxD) With Stand: 18.4 x 17.1-23 x 12 in. / 467 x 434.3-584 x 304mm
Without Stand: 18.4 x 14.2 x 4.4 in. / 467 x 361 x 111mm
Weight With Stand: 23.5 lbs. / 10.7 kg
Without Stand: 16.5 lbs. / 7.5 kg
