| Display Technology |
0.63" LCD |
| Light Output (Lumens) |
2600 normal / Eco = approx. 70% of normal mode |
| Resolution |
Native: XGA 1024 x 768 Maximum: UXGA 1600 x 1200 |
| Contrast Ratio (up to) |
600:1 |
| Lamp Type |
230W AC / 170W eco |
| Lamp Life (up to) |
4000 hours normal / 5000 hours eco |
| Screen Size (diagonal) |
60 to 110" |
| Throw Ratio |
0.74 to 1 |
| Projection Distance |
2.9 to 5.6 ft. / 0.9 to 1.7m |
| Projector Angle |
29.1deg. tele / 29.4deg. wide |
| Lens |
Zoom: 1.2 Focus: Manual F number, fnumber: F=2.3, f=9.7mm |
| Keystone Correction |
Automatic or manual +/- 20deg. |
| Scan Rate |
Horizontal: 15-100 kHz Vertical: 50-120 Hz |
| Supported Video Standards |
NTSC 4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM |
| SD/HD Video Signal Compatibility |
480p, 576i, 576p, 720p, 1080i |
| PC Signal Compatibility |
SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, UXGA |
| Macintosh Compatibility |
Yes |
| Input/Output Terminals |
RGB1(analog): VGA 15-pin D-sub, Component video using ADP-CV 1E RGB2(analog): DVI-I w/ HDCP Video 1: RCA Video 2: S-Video Audio 1: 1/8 in. stereo Monitor out: VGA 15-pin D-sub Audio out: Yes (variable) |
| Audio |
7W speaker |
| External Control |
RS-232, IR, Wired LAN |
| Sync Compatibility |
Separate Sync / Composite Sync / Sync on G |
| Networking |
RJ-45 Monitoring |
| Power Requirements |
100-240V AC, 50/60 Hz |
| Input Current |
3.8A/1.5A |
| Power Consumption |
312W / 237W / NA / 0.6W (Normal/ECO Mode/Standby/Standby Power Saving) |
| Operating Temperature |
41-95deg.F / 5-35deg.C |
| Humidity |
20-80% non-condensing |
| Storage |
-14-122deg.F / -10-50deg.C |
| Fan Noise |
35 dB normal / 29 dB eco |
| Regulations |
UL60950-1, CSA60950-1, FCC Part 15 Class B, ICES-03 Class B, NOM-001-SCFI-1993 |
| Installation Orientation |
Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear |
| Dimensions (W x D x H) |
12.1 x 11.9 x 5.4 in. / 308 x 302.2 x 137.16mm |
| Weight |
7.3 lbs. / 3.3 kg |
