| Display System |
0.79" / 2.01 cm Micro Lens Array (MLA) LCD |
| Native Resolution |
XGA - 1024 x 768 |
| Supported Resolutions |
VGA SVGA SXGA SXGA+ UXGA WUXGA - 1920 x 1200 |
| Format |
NTSC 4.43 PAL 60, M, N SECAM |
| HDTV Compatibility |
480i 480p 576i 576p 720p 1080i 1080p |
| Pixels |
786432 |
| Brightness |
5000 Lumens |
| Contrast Ratio |
2000:1 |
| Scan |
Horizontal: 15 - 108 kHz Vertical: 48 - 120 Hz |
| Lens |
F 1.7 - 2.2 (f = 24.4 - 32.5 mm) |
| Lens Shift |
None |
| Zoom Ratio |
1.7x |
| Throw Distance |
2.5 - 68.5' (0.76 - 20.88 m) |
| Throw Ratio |
1.5 - 3:1 |
| Projection Size |
25 - 500" (635.00 - 12700.00 mm) |
| Keystone Correction |
Vertical: ± 30deg. Horizontal: ± 40deg. |
| Ceiling Mountable |
Yes |
| Rear Screen Projection |
Yes |
| Projection Tilt Option |
Yes |
| Built-in Speaker |
10W |
| Inputs/Outputs |
2x 15-pin VGA Video (Input) 1x HDMI Audio/Video (Input) 1x DisplayPort Video (Input) 1x RCA Stereo (L/R) Audio (Input) 1x S-Video Video (Input) 1x 1/8" (3.5 mm) Mini Audio (Input) 1x 15-pin VGA Video (Output) 1x RS-232C Control/Service (Input) 1x Ethernet Control/Service (Input) 1x 5-BNC Video 1x 1/8" (3.5 mm) Mini Audio (Output) 1x IR Control |
| Watts |
330W Eco Mode: 264W |
| Life |
Normal Mode: 3000 Hours Eco Mode: 4000 Hours |
| Fan Noise |
Eco Mode: 31 dB Normal Mode: 38 dB |
| Remote Control |
Yes |
| Power Requirements |
100-240 VAC, 50/60 Hz |
| Power Consumption |
Normal Mode: 464W Eco Mode: 372W Standby Mode: 16W |
| Temperature |
Operating: 41 to 104 deg.F (5 to 40 deg.C) Humidity: 20 - 80% |
| Dimensions (WxHxD) |
19.7x14.4x6.5" / 50.04x36.58x16.51 cm |
| Weight |
17 lbs / 7.71 kg |
