| Display Technology |
DLP (0.55" DMD) |
| Light Output (Lumens) |
3000 normal / Eco = approx. 87% of normal mode |
| Resolution |
Native: XGA 1024 x 768 Maximum: UXGA 1600 x 1200 |
| Contrast Ratio (up to) |
2000:1 |
| Lamp Type |
280W AC |
| Lamp Life (up to) |
2500 hours normal / 3000 hours eco |
| Screen Size (diagonal) |
63 to 85" |
| Throw Ratio |
0.377 to 1 |
| Projection Distance |
1.58 to 2.13 ft. / 0.48 to 0.65m |
| Projector Angle |
55.3deg. |
| Lens |
Zoom: 1 to 1.1 Focus: Manual F number, fnumber: F=2.71 |
| Keystone Correction |
Automatic or manual +/- 15deg. |
| Scan Rate |
Horizontal: 15-91.1 kHz Vertical: 50-120 Hz |
| Supported Video Standards |
NTSC, NTSC4.43, PAL, PAL-M, PAL-N, PAL 60, SECAM |
| SD/HD Video Signal Compatibility |
480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| PC Signal Compatibility |
VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, UXGA |
| Macintosh Compatibility |
Yes |
| Input/Output Terminals |
RGB1(analog): VGA 15-pin D-sub, Component video using ADP-CV 1E RGB2(analog): VGA 15-pin D-sub, Component video using ADP-CV 1E RGB3(digital): HDMI Video 1: RCA Video 2: S-Video Audio 1: 1/8 in. stereo Monitor out: VGA 15-pin D-sub Audio out: Yes (variable) |
| Audio |
10W speaker |
| External Control |
RS-232, IR, Wired LAN, USB |
| Sync Compatibility |
Separate Sync / Composite Sync / Sync on G |
| Networking |
RJ-45 Monitoring |
| Power Requirements |
100-240V AC, 50/60 Hz |
| Input Current |
3.5A/1.5A |
| Power Consumption |
360W / 315W / 3W / <0.5W (Normal/ECO Mode/Standby/Standby Power Saving) |
| Installation Orientation |
Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear |
| Fan Noise |
36 dB normal / 32 dB eco |
| Regulations |
USA UL 60950-1 FCC Class B, Canada CSA 60950-1 (C-UL) |
| Operating Temperature |
41-104deg.F / 5-40deg.C |
| Humidity |
20-80% non-condensing |
| Storage |
-4-122deg.F / -20-50deg.C |
| Dimensions (W x D x H) |
16.8" x 7.9" x 16" / 426.72 x 200.66 x 406.4 mm |
| Weight |
14.3 lbs. / 6.5 kg |
