NEC SB-L008WU DVI Daisy Chain Board for Large-Screen LCD Displays


Our Price

Buy more and save
Quantity Discount

The quantity discount will be reflected in your shopping cart

Availability: In Stock & Ready to Ship

Free Expedited Shipping

See all shipping options

NEC SB-L008WU: Picture 1 regular $91.33

About NEC SB-L008WU

The NEC SB-L008WU is an add-on accessory module for use with NEC MultiSync 20 and M series large screen displays. With 1 DVI input and 1 DVI output, this module allows the DVI signal received by the monitor to continue on (loop-through) to a second monitor. When installed in multiple monitors, this module will allow up to 9 displays to receive the same DVI signal from a single DVI source. This eliminates the need for an external DVI splitter, amplifier and power supply along with the cost, hassle and tangled wiring associated with that distribution method.

Consequently, this module is a must for video banners ribbons and walls in addition to back-to-back installations in environments such as transportation, public information and digital signage networks.

NEC SB-L008WU Features

  • Fully integrated seamless design: Internal solution provides for clean, hidden integration that eliminates the need for external equipment and power supply
  • Full HD resolution: The board is capable of supporting crystal-clear, digital video transmissions up to 1920 x 1080 in resolution
  • DVI output: Gives users a fast and easy way to simultaneously transmit video content from a single player to up to nine screens in close proximity. This reduces the cost of using splitters or connecting monitors to multiple sources, making it ideal for digital signage configurations
  • Landscape and portrait orientations: Provides versatility for various digital signage applications

NEC SB-L008WU Specifications

NEC M Series: 40" M40-AV
40" M40-2-AV
40" M40B-AV
46" M46-AV
46" M46-2-AV
46" M46B-AV
NEC MultiSync 20 Series: 40" LCD4020-2-AV
46" LCD4620-2-AV
52" LCD5220-AV
65" LCD6520L-BK-AV
65" LCD6520P-BK-AV
Input Signal (DVI - no HDCP)
Compliant with DVI 1.0
1x DVI-D 24-pin connector
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60,
1920 x 1080 @ 60Hz
Output Signal
DVI:1x DVI-D 24-pin connector
Loop-through signal
Non DDC2B loop
TMDS:1x M40/46 option slot interface connector
Loop-through signal
Daisy Chain Connection (max)
9 units
Power Supply
+6VDC@500mA (from internal option slot interface)
Power Consumption
Operating Temperature
5 - 40deg.C / 41 - 104deg.F
Operating Humidity
20- 80% (without condensation)
Storage Temperature
-20 - 60deg.C / -4 - 140deg.F
Storage Humidity
10 - 90% (without condensation)
Dimensions (W x H x D)
6.1 x 1.6 x 10.9 in. / 154.94 x 40.64 x 276.8mm
2.1 lbs. / 0.95 kg
