| Magnification |
3.5x - 15x |
| Objective / Field of View |
56mm / 27.6' (8.4m) @ 3.5x at 100 yds.(100m), 7.3' (2.2m) @ 15x at 100 yds.(100m) |
| Main (Center) Tube Diameter |
30mm |
| Objective Tube Diameter |
65mm |
| Eyepiece Tube Diameter |
43mm |
| Lens Coatings |
Broadband Multi-coated |
| Reticle |
Illuminated HV.5 |
| Reticle Image Plane (Magnifying) |
Second, Non-Magnifying |
| Twilight Performance |
Not Specified by Manufacturer |
| Exterior Finish |
Matte Black |
| Windage & Elevation Adjustments (MOA) |
.250 MOA Elevation & Windage |
| Maximum Adjustment |
110 MOA E & 80 MOA W |
| Exit Pupil |
14.5mm at 3.5x / 4.0mm at 15x |
| Eye Relief |
3.87" / 97.0mm @ 3.5x, 3.87" / 97.0mm @ 15x |
| Parallax Correction Control |
50 yards to Infinity |
| Diopter Adjustment |
+ / - 5 |
| Battery |
CR-2032 |
| Battery Life |
About 200 Hours Depending on Intensity |
| Material |
6061-T6 Aircraft Grade Aluminum Alloy |
| Nitrogen Filled |
Yes |
| Waterproof / Fogproof |
Yes |
| Length |
14.8", (375.9mm) |
| Mounting Length |
5.8" |
| Weight |
31.0 oz., 878.8g |
| Special Features |
Reticle Image in the Second Focal Plane. Zero Stop Adjustments |
