| Magnification |
5.5x - 22x |
| Objective / Field of View |
56mm / 17.5' (5.3m) @ 5.5x at 100 yds.(100m), 4.7' (1.4m) @ 22x at 100 yds.(100m) |
| Main (Center) Tube Diameter |
30mm |
| Objective Tube Diameter |
65mm |
| Eyepiece Tube Diameter |
43mm |
| Lens Coatings |
Broadband Multi-coated |
| Reticle |
Illuminated HVM Reticle |
| Reticle Image Plane (Magnifying) |
Second, Non-Magnifying |
| Twilight Performance |
Not Specified by Manufacturer |
| Exterior Finish |
Matte Black |
| Windage & Elevation Adjustments (MOA) |
.25 MOA Elevation & Windage with Zero Stops |
| Maximum Adjustment |
100 MOA E & 60 MOA W |
| Exit Pupil |
10.2mm at 5.5x / 2.5mm at 22x |
| Eye Relief |
3.9" / 99.0mm @ 5.5x, 3.9" / 99.0mm @ 22x |
| Parallax Correction Control |
50 yards to Infinity |
| Diopter Adjustment |
+ / - 5 |
| Battery |
CR-2032 |
| Battery Life |
About 200 Hours Depending on Intensity |
| Material |
6061-T6 Aircraft Grade Aluminum Alloy |
| Nitrogen Filled |
Yes |
| Waterproof / Fogproof |
Yes |
| Length |
15.2", (386.1mm) |
| Mounting Length |
6.6" |
| Weight |
32.0 oz., 907.2g |
| Special Features |
Reticle Image in the Second Focal Plane, .25 MOA Zero Stop Adjustments |
