| Magnification |
2.5x - 10x |
| Objective / Field of View |
32mm / 44.0' (13.4m) @ 2.5x at 100 yds.(100m), 11.0' (3.4m) @ 10x at 100 yds.(100m) |
| Main (Center) Tube Diameter |
30mm |
| Objective Tube Diameter |
40mm |
| Eyepiece Tube Diameter |
40mm |
| Lens Coatings |
Broadband Multi-coated |
| Reticle |
Illuminated HV Reticle |
| Reticle Image Plane (Magnifying) |
Second, Non-Magnifying |
| Twilight Performance |
Not Specified by Manufacturer |
| Exterior Finish |
Matte Black |
| Windage & Elevation Adjustments (MOA) |
.25 MOA Elevation & Windage |
| Maximum Adjustment |
100 MOA E & 100 MOA W |
| Exit Pupil |
13.3mm at 2.5x / 3.3mm at 10x |
| Eye Relief |
3.7" / 95.0mm @ 2.5x, 3.7" / 95.0mm @ 10x |
| Parallax Correction Control |
Pre-Set at Factory to 125 yards. |
| Diopter Adjustment |
+ / - 5 |
| Battery |
CR-2032 |
| Battery Life |
About 200 Hours Depending on Intensity |
| Material |
6061-T6 Aircraft Grade Aluminum Alloy |
| Nitrogen Filled |
Yes |
| Waterproof / Fogproof |
Yes |
| Length |
12.0", (304.8mm) |
| Mounting Length |
5.7" |
| Weight |
19.0 oz., 538.6g |
| Special Features |
Reticle Image in the Second Focal Plane. |
