The Novoflex QPLVR-SLANT is designed especially for fisheye lenses with a diagonal image angle of 180deg.. The camera is to be mounted on the panorama system horizontally at an angle of 60deg. and it can also be tilted vertically at up to 15deg.. With this slanted camera position, complete spherical panoramas with impressive pictorial effect can be achieved with only three or four overlapping exposures.
It is especially simple to make these photographs with the aid of a monopod. The VR-System Slant is meant for all photographers who wish to produce high-grade spherical panoramas quickly and efficiently for internet applications, such as, for example, virtual tours.
|Recommended camera-/lens combinations||Cameras with APS-C sensor size (1.5-1.6 crop) as well as Canon cameras from the 1D series (1.3 crop): Sigma 8mm / 3.5 EX DG Fisheye, Peleng 8mm / 3.5 Fisheye, Canon EF 8-15mm / 4 L USM Fisheye
Cameras with full frame sensor: Tokina AT-X 10-17mm / 3.5-4.5 DX Fisheye, Sigma 10mm / 2.8 EX DC Fisheye HSM, Nikkor AF 10.5mm / 2.8 G ED DX Fisheye, Samyang 8mm / 3.5 Fisheye, Canon EF 8-15mm / 4 L USM Fisheye
|Tripod sockets||1/4" and 3/8"|
|Dimensions||155 x 175 x 75 mm (61.8 x 67.8 x 3 in)|
|Weight||575 g (20.28 oz)|
